5. Insert the left and right arms into the shoulder pieces lining up the servo horn with the cut +
shape on each shoulder.
*Ensure the
arms are inserted pointing down.
6. After fixing the arms to the shoulder parts,
unplug the servo motors from the control board and turn the power switch off.
34 / 61
