Appendix A Remote Control Commands

8.7. Remote Control

8.7.1.

Remote Control Commands

Command String Nomenclature
NU Literal
<tt> Address of target (0x01 – 0xFF)
<ss> Address of source (0x00 – 0xFF)
<##> Packet length (Range: Command Length + Data Length)
<cc> Command (0x00-0xFF)
<dd> Data (Hex Format)
<CS> (1's complement of <tt> to end of data)
<CR> Carriage Return
<LF> Line Feed
Notes
1. The device sends this packet and will not respond to it.
2. Command NOT Implemented Yet.
3. Factory use only.
4. Unless command 0x6F is used, you must wait 5 seconds between each set
command.
Wait for a response to each command before sending the next command.
PR Command
I Set/Response
Factory Parameters
NOTE: Internal
Factory uses to align
the I/Q modulator.
M55-ML3-UG, Rev A
R/W
RW NU<tt><ss><##><60><dd>...<dd><CS><CR><LF>
3
00 – RF loop control
2.<dd>: lower power loop mode
00 – open loop
loop
3.<dd><dd>: low power open loop
attenuation in mdB
4.<dd><dd>: low power closed loop power
in mdB
5.<dd>: high power loop mode
00 – open loop
loop
6.<dd><dd>: high power open loop
attenuation in mdB
7.<dd><dd>: high power closed loop power
in mdB
Operators Manual
Command String
1.<dd>: Factory Parameter Type
01 – closed
01 – closed
Operation
