PR Command
I Request Factory
Parameters
I Response
Configuration Data
NOTE
Internal Factory uses
to support system
tracker.
I Request
Configuration Data
Error Responses:
In the event of a communications error, the device will respond with an error byte in
the format:
<02><7F><xx>
Where error code byte xx indicates:
00 hex
55 hex
CC hex
AA hex
FF hex
M55-ML3-UG, Rev A
R/W
10 – Serial port mode
20 – Response upper/lower frequency plan
limit in kHz
26 – Response RF detector voltage (in mV)
W
00 – RF loop control
20 – Upper/Lower frequency plan limit in kHz
26 – RF detector voltage (voltage x 1000)
R NU<tt><ss><##><6E><dd..dd><CS><CR><LF>
<##> = 0 to request number of data lines available
<##> = 1+ to request specific data line.
1.<dd>: - Number of data lines available
(or) <dd..dd>: - Configuration data
W NU<tt><ss><02><EE><dd><CS><CR><LF>
1.<dd>: 00 – Get number of data lines available
Good data (no error, this is the normal response for commands)
Invalid Data
Internal error processing command
Remote commands locked out
Bad command packet received
Command String
00 – remote control 01 – debug mode
2.<dd><dd><dd><dd>: upper limit
3.<dd><dd><dd><dd>: lower limit
2.<dd><dd>: RF detector voltage
NU<tt><ss><02><E0><dd><CS><CR><LF>
1.<dd>: Factory Parameters Type
01..nn – Get specified data line
