Figure 30: Retrieving MLT3 Status from RC Application

8) Setting a new parameter
a. All parameters may be set by using a button, text box, or dropdown.
b. Multiple parameters may be changed at the same time.
c. The frequency is entered in 'Hz'
d. The parameter settings feature 2 tabs – 'RF' and 'Advanced'
e. Set all parameters you wish to change.
f. Press the 'Apply to Device' button for the FCDF to send the changes to the MLT3.
When the 'time bar' reaches 100% the changes will have taken effect.
g. You may verify changes by press the 'Control' button.
9) Saving setting to a preset.
a. You may set and recall presets and store them for later use.
b. Press 'Save Preset' to save parameters. You may verify the preset by pressing the
'Preset' tab.
10) Retrieving a preset
a. Press the 'Load Presets'
b. Press the 'Apply to Device'
c. Wait for the 'Time Bar' to complete.
M55-ML3-UG, Rev A
Operators Manual
Operation
Press the 'Control' button to
populate DF status
Timeline bar. The DF
parameters will load and
populate when complete
