6.

Specifications

6.1. Frequency Bands and RF Performance

Base Model Number
23MLT3-23
24MLT3-20
33MLT3-23
23/33MLT3-23
55MLT3-23
23/55MLT3-23
64MLT3-20

6.2. Modulation Modes

Modulation
Carriers
Constellation
Code Rate
Guard Interval
Bandwidth

6.3. MPEG Encoder

Video Coding
Video Input
Video Formats
Audio
SDI
HDMI
Audio Coding
Audio Sample Rate
M55-ML3-UG, Rev A
Frequency (GHz)
2.0 - 2.5
2.4-2.483
3.1 – 3.5
2.0-2.5/3.1-3.5
5.1- 6.0
2.0-2.5/5.1 – 6.0
6.4 - 7.1
DVB-T
LMST
2K
QPSK, 16QAM
1/2, 2/3, 3/4, 5/6, 7/8
1/32, 1/16, 1/8, 1/4
5, 6, 7, & 8 MHz
MPEG-4 Part 10/H.264
HD-SDI
HDMI
720p 24/25/50/59.94/60
1080i 24/25/50/59.94/60
Embedded
Embedded
MPEG1 (Layer II)
48 KHz
Operators Manual
Power
Power Out
Consumption
(mW)
200
100
200
200
200
200
100
Specifications
Watts
7
7
7
7
7
7
