The Licensing page contains licensing information. To add new licenses, contact Vislink Customer
Service and provide the MAC Address from the information page. Customer Service will provide a
Key Number. Place the Key Number in the space provided and hit enter. Your product will now be
licensed.

8.5. Telemetry

The ML3's telemetry allows you to remote control and camera control using the Vislink
Focal point kit and the integrated 920Mhz Telemetry Radio.
8.5.1.

Equipment Required

The MLT3 Camera Control and/or Remote Control Operates with the Vislink Focal Point
Transceiver. The Transceiver options include:
•
Fiber Connector Type
SC/APC
o
LT/UPC
o
ST/UPC
o
SC/UPC
o
FC/UPC
o
•
Power Options
Wall Wart AC Mains
o
Gold Mount Battery
o
V-Clip Battery
o
Part Number
FCDT-ASSY-7101
FCDT-ASSY-7102
FCDT-ASSY-7103
FCDT-ASSY-7105
FCDT-ASSY-7106
FCDT-ASSY-7110
FCDT-ASSY-7111
FCDT-ASSY-7112
FCDT-ASSY-7115
FCDT-ASSY-7116
FCDT-ASSY-7117
FCDT-ASSY-7120
FCDT-ASSY-7122
FCDT-ASSY-7123
FCDT-ASSY-7124
M55-ML3-UG, Rev A

Table 5: Focal Point Telemetry Radio Selection

Focal Point Outdoor Unit SC/APC 410-490MHz/900MHz
Focal Point Outdoor Unit SC/APC 410-490MHz/900MHz &
IDX
Focal Point Outdoor Unit SC/APC 410-490MHz/900MHz &
A/B
Focal Point Outdoor Unit LC/UPC 410-490MHz/900MHz
Focal Point Outdoor Unit LC/UPC 410-490MHz/900MHz &
IDX
Focal Point Outdoor Unit ST/UPC 410-490MHz/900MHz
Focal Point Outdoor Unit ST/UPC 410-490MHz/900MHz &
IDX
Focal Point Outdoor Unit ST/UPC 410-490MHz/900MHz &
A/B
Focal Point Outdoor Unit SC/UPC 410-490Mhz/900MHz
Focal Point Outdoor Unit SC/UPC 410-490MHz/900MHz &
IDX
Focal Point Outdoor Unit SC/UPC 410-490MHz/900MHz &
A/B
Focal Point Outdoor Unit FC/UPC 410-490MHz/900MHz
Focal Point Outdoor Unit FC/UPC 410-490MHz &
A/B/900MHz
Focal Point Outdoor Unit SC/UPC 410-490MHz/900MHz
(Dual Serial)
Focal Point Outdoor Unit SC Serial to Fiber Connector
Description
