the five control pages, and selection can be made on-the-fly between them. It is only required to log into the
aggregated page once, and each instance may be selected without added security logins.
The aggregated page defaults to show the instance #1 options. The currently selected instance can be changed by
selecting the menu (hamburger) button in the upper left corner of the page. A slide-out menu will appear allowing
you to select which of the five instances are "in focus" on the browser.
FIgure 13 web InterFAce logIn

INSTANCE PAGES AND GLOBAL SETTINGS

MultiRack provides five audio codec instances, but shares elements like passwords, USB devices and network
interfaces. This can be confusing for configuration, since configuring some elements of MultiRack for one instance
may have impact on the others.
For this reason the web configuration pages for MultiRack are divided into "Instance Config Pages" and a "Global
Config Page". Most settings that affect MultiRack globally are contained in the Global Page, while instance-specific
settings are mostly contained in the Instance Config pages. Due to system architecture there are exceptions, and
these are called out with a warning within the interface.
Individual Instance pages and Global Settings are selected via the main menu button ("Hamburger" button in upper
right or left corner) as shown in Figure 13. If you select an Instance page, there is a legend on the top banner to
remind you which instance you are addressing, which is underlined in Figure 13.

INTERFACE PAGE SECTIONS

There are two parts to the primary interface screen (Figure 14):
• Main Audio Meter (1): This meter displays audio levelling for active connections to the MultiRack. This
meter is not available in the console interface (KVM).
