'UPGRADE' MODE PROGRAMMING
As standard, the M80II is programmed to operate from the supplied remote controls.
When installed as an 'upgrade' the M80II is configured differently so it operates only from the vehicles
remote controls.
The Mongoose remotes are used for programming – please leave them in the vehicle.
Changes in configuration are;
a. The Automatic Engine Disable (AED) is off. Most vehicles have a factory immobiliser.
b. Wire numbers 1-(Disarm#2), 4-(Arm) & 13-(Disarm) are enabled (they are disabled when
the M80II is used with the Mongoose remotes)
Wire number 7 changes from 'CH2 output' to 'Boot bypass'.
c.
To change M80II to UPGRADE mode, change program No. 6 (AED) to OFF
Once programmed to 'upgrade' mode, the following 3 wires are enabled;
Wire description
ARM
DISARM
DISARM #2
Programme #4
controls input
type
INSTALLATION, WIRING & PROGRAMMING

CONTROL INPUTS

Connect to vehicle's lock motor wire (Pulses positive when locked)
Connect to vehicle's unlock motor wire (Pulses positive when unlocked)
1) LIGHT FLASH - Prog #4 ON (Default)
Connect to vehicles positive Indicator flash wire
Connect to unlock signal wire from driver's door
(Pluses negative from key barrel when key is used)
Function
OR
2) DISARM DEFEAT - Prog #4 OFF
