Summary of Contents for Stealth Products HMO500
- Page 1 Head Support Hardware USER MANUAL HMO500 Stealth’s User Manual and Maintenance Guide for the HMO500 Headrest Hardware...
- Page 2 Customer Satisfaction Stealth Products strives for 100% customer satisfaction. Your complete satisfaction is important. Please contact us with feedback or suggested changes that will help improve the quality and usability of our products. You may reach us at: Stealth Products, LLC...
- Page 3 Important Information Important Information! All persons responsible for fitting, adjustment, and daily use of the devices discussed in these instructions must be familiar with and understand all safety aspects of the devices mentioned. In order for our products to be used successfully, you must: ...
-
Page 4: Introduction
Ordering Documentation You can download additional copies of this user manual on the Stealth website: https://stlpro.site/stealth-docs and search: HMO500 in the search bar at the top of the page. -
Page 5: Warranty
Warranty Our products are designed, manufactured, and produced to the highest of standards. If any defect in material or workmanship is found, Stealth Products will repair or replace the product at our discretion. Any implied warranty, including the implied warranties of merchantability and fitness for a particular purpose, shall not extend beyond the duration of this warranty. -
Page 6: Table Of Contents
Table of Content 1.0 Customer Satisfaction ................i 2.0 Important Information ................ii 3.0 Introduction .................... iii 4.0 Warranty ....................iv 5.0 Table of Contents ..................v 6.0 Warning Labels ..................vi 6.1 Warning Labels ..................... vi 6.2 Limited Liability ..................... vi 6.3 Testing ........................ -
Page 7: Warning Labels
SAFETY necessary. Limited Liability Stealth Products, LLC accepts no liability for personal injury or damage to property that may arise from the failure of the user or other persons to follow the recommendations, warnings, and instructions in this manual. Testing Initial setup and driving should be done in an open area free of obstacles until the user is fully capable of driving safely. -
Page 8: Design And Function
Design and Function Intended Use The HMO500 is a lightweight, multi-mount mounting bracket for use with Stealth’s headrests. This hardware is designed to provide multi-axis positioning of the head support, increasing the ability to properly accommodate asymmetrical head positioning. Features The HMO500 hardware: ... -
Page 9: Features
The height of the HMO500 can be adjusted by turning the handle on the vertical bar counter clockwise. A total of 6” of height adjustment is available on the vertical bar. -
Page 10: Depth Adjustment
Features Depth Adjustment The depth of the horizontal bar can be adjusted up to 4”. Loosen the M5 screw on the side of the bar clamp, which holds the horizontal bar in place. By loosening the screw, depth adjustment can be made. ... -
Page 11: Installation Instructions
Torque Wrench CAUTION Use the proper tools to install and adjust the HMO500 hardware. The use of improper tools may cause damage to the device. Installation Plan Set up an installation plan before installing or making any adjustments to the hardware. -
Page 12: Installation
Only use screws provided in the package with the hardware. CAUTION WARNING Discontinue use if any product’s function becomes compromised, loose, shows signs of excessive wear, missing parts, or does not function as intended. NOTICE Refer to the HMO500 installation manual for torque specifications regarding the hardware. - Page 13 Installation Instructions The pictures below feature the HMO hardware installed on headrests using the three and four-point hole patterns. *Headrests not included.
-
Page 14: First Time Use
Explain to the client the possible problems and how to address them. Conditions of Use 10.3 The HMO500 headrest hardware is intended for use as installed by the dealer, in accordance to the installation and instructions in this manual. ... -
Page 15: Maintenance
Maintenance 11.0 Care and Maintenance 11.1 We recommend that the hardware be checked for wear and function on a periodic basis and replaced, if necessary, by a wheelchair professional. Discontinue use after identifying loose or broken components. Check and tighten all screws according to the installation instructions. ... - Page 16 Stealth Products, LLC. • info@stealthproducts.com • www.stealthproducts.com +1(800) 965-9229 | +1(512) 715-9995 | 104 John Kelly Drive, Burnet TX 78611 P17D428 Revision Date 2019-12-17...
