- Page 1 Mounting Hardware Installation Manual GAT461M Multi Joystick Mount Compatible with GAT400 Series...
-
Page 2: Customer Satisfaction
Customer Satisfaction Stealth Commitment Stealth Products strives for 100% customer satisfaction. Your complete satisfaction is important. Please contact us with feedback or suggested changes that will help improve the quality and usability of our products. You may reach us at:... -
Page 3: Warning Labels
SAFETY necessary. Limited Liability Stealth Products, LLC accepts no liability for personal injury or damage to property that may arise from the failure of the user or other persons to follow the recommendations, warnings, and instructions in this manual. Stealth Products does not hold responsibility of final integration of final assembly of product to end user. -
Page 4: Table Of Contents
Table of Contents 1.0 Customer Satisfaction ................i 1.1 Stealth Commitment ..................... i 2.0 Warnings ....................ii 2.1 Warning Labels .......................ii 2.2 Limited Liability .......................ii 2.3 Testing ........................ii 3.0 Table of Contents.................. iii 4.0 Parts and Accessories ................1 4.1 Mounting Hardware Parts ................1 4.2 Tools ........................ -
Page 5: Parts And Accessories
Parts and Accessories Mounting Hardware Parts GAT461M includes: GAT400 Series Mount reference (not included) Tools Required (Not included) GAT461M Block Multi Joystick GAT400 Series M5 x 0.8 x 25mm Bar Plug 5/32 Allen (Hex Key) 4mm Allen (Hex Key) 1. Not included... -
Page 6: Installation Instructions
Installation Instructions CAUTION DO NOT OVER TIGHTEN SCREWS. This could cause wearing of screws or joystick threads, causing the client to lose efficient control. Installing Joystick Step 1. Remove bar plug (C2) from Gatlin arm (C1). Loosen clamping screw (1). Slide block (A) into the arm(C1). -
Page 7: Angle Adjustment
Installation Instructions Angle Adjustment Step 1: Loosen screw (1). Step 2: Rotate block (A) in a 360° range to the desired angle. Tighten screw (1) again. Horizontal Alignment Step 1: Loosen clamp screw (1). Step 2: Slide block (A) towards the desired direction on the arm (C1). -
Page 8: Maintenance
Maintenance SAFETY For joystick maintenance guidelines refer to the device’s user manual. Maintenance Check every 6 months that screws are tight. Gently tighten any screws that may have become loose. Maintain that the hardware is clean and free of dust. Cleaning ... -
Page 9: Warranty
Warranty Our products are designed, manufactured, and produced to the highest of standards. If any defect in material or workmanship is found, Stealth Products will repair or replace the product at our discretion. Any implied warranty, including the implied warranties of merchantability and fitness for a particular purpose, shall not extend beyond the duration of this warranty. - Page 10 NOTES...
- Page 11 NOTES...
- Page 12 Stealth Products, LLC. • info@stealthproducts.com • www.stealthproducts.com +1(800) 965-9229 | +1(512) 715-9995 | 104 John Kelly Drive, Burnet TX 78611 P120D201 Revision Date 2019-12-17...
