Sun Microsystems Enterprise 10000 System Upgrade Instructions page 8

FIGURE 2
9. Tighten the captive connector screws to a final torque of 0.68 Nm (6.0 inch pounds)
in the pattern noted in
10. Replace the system board cover and secure with Phillips screws tightening to a
torque of 1.0 Nm (8.9 inch pounds),
11. See "Installing a System Board" on page 7 to confirm the event monitoring
daemon is running prior to installing the system board.
6 Sun Enterprise 10000 336-Mhz Processor Module Upgrade Instructions • July 1998
2
3
Tightening Pattern for the Processor Module
FIGURE 2
3 5
4
2
5
1
.
1
4
