TKA2 Dimensions
(H x W x D):
25.375" x 19.375" x 0.3125" (644.6mm x 492.1mm x 7.9mm)
19.375" (492.1mm)
2.2" (55.9mm)
2.2" (55.9mm)
0.156"
( 3.96mm)
1.0" (25.4mm)
1.0" (25.4mm)
7.5" (190.5mm)
7.5" (190.5mm)
9.2" (233.7mm)
9.2" (233.7mm)
Trove2KA2 / Trove3KA3
- 5 -
