ADTRAN T200 Installation And Maintenance Practice page 9

The
HDSL2 Unit Information Screen (
provides detailed product information on each
component in the HDSL2 circuit. This screen also
displays contact information for ADTRAN Technical
Support, Internet site and address.
Circuit ID:
--------------------- For Information or Technical Support ---------------------
Support Hours ( Normal 7am - 7pm CST, Emergency 7 days x 24 hours )
Phone: 800.726.8663 / 888.873.HDSL
--------------------------------------------------------------------------------
Circuit ID:
61223024L2-5A
Figure 6),
Press ESC to return to previous menu
ADTRAN
901 Explorer Boulevard
Huntsville, Alabama 35806-2807
ADTN H2TU-C
P/N: 1223001L2
S/N: 123456789
CLEI: T1L7JBMAAA
Manf: 10/01/2003
Ver: A04
Figure 6. HDSL2 Unit information Screen
Press ESC to return to previous menu
Provisioning
1. DSX-1 Line Buildout
2. DSX-1/DS1 Line Code
3. DSX-1/DS1 Framing
4. Forced Frame Conversion =
5. Smartjack Loopback
6. Loopback Timeout
7. Latching Loopback Mode
8. DS1 TX Level
9. Customer Loss Indicator =
10. PRM Setting
11. Loop Atten Alarm Thres
12. SNR Margin Alarm Thres
13. Remote Provisioning
D. Restore Factory Defaults
Selection:
Figure 7. Provisioning Screen
Issue 1, December 2003
The
Provisioning Scree
provisioning settings for the HDSL2 circuit. To change
a particular option setting, select the appropriate
number and a new menu will appear with a list of the
available settings. The
at the bottom of the list is helpful if a unit is to be re-
deployed.
Fax: 256.963.6217 Internet: www.adtran.com
ADTN H2TU-R
P/N: 1223024L2
S/N: 123456789
CLEI: T1L7TDHAAA
Manf: 10/01/2003
Ver: A01
= 0-133 ft.
= B8ZS
= ESF
Disabled
= Enabled
= 120 Min
= T1 (Disabled)
= 0 dB
AIS / CI
= AUTO
= 30dB
= 04dB
= Enabled
n (Figure 7) displays the current
D=Reset Factory Default
10/29/03 09:29:45
10/29/03 09:29:45
option
