ADTRAN T200 Installation And Maintenance Practice page 14

The Scratch Pad,
Circuit ID and Time/Date Screen
(Figure 16) allows three main functions:
• Setting/updating system date and time
• Logging the circuit ID
• Logging pertinent work notes
The time should be entered using military time (for
example, enter 3:15 p.m. as "151500"). The date should
Circuit ID:
Current Scratch Pad:
New Scratch Pad =
New Circuit ID =
14
Press ESC to return to previous menu
New Date = / / (MM/DD/YY)
New Time = : : (HH:MM:SS)
Press TAB to skip to next entry field.
Figure 16. Scratch Pad, Circuit ID, Time/Data Screen
Issue 1, December 2003
be entered as MMDDYY (for example, enter January
02, 2003, as "010203").
The Circuit ID field may contain up to 25 characters.
The Scratch Pad is a user-defined field that can contain
any alphanumeric characters up to 50 characters in
length.
10/29/03 09:29:45
61223024L2-5A
