6. CONTROL PORT OPERATION-HDSL2

The screens illustrated in
apply to an HDSL2 circuit deployed with the ADTRAN
HDSL2 technology. The circuit includes an H2TU-C
and an H2TU-R. Other configurations are possible (for
example, other vendor's equipment) and their displays
will vary slightly from those shown in this section.
Circuit ID:
8
Figure 5 through Figure 26
Adtran HDSL2 Main Menu
1. HDSL2 Unit Information
2. Provisioning
3. Span Status
4. Loopbacks and Test
5. Performance History
6. Scratch Pad, Ckt ID, Time/Date
7. Terminal Modes
8. Alarm History
9. Event History
10. System PM/Screen Report
11. Clear PM and Alarm Histories
12. Troubleshooting
13. Virtual Terminal Control
If subscreens do not work properly,
press CTRL-T to move to manual update mode.
Selection:
Figure 5. HDSL2 Main Menu
Issue 1, December 2003
First displayed is the ADTRAN HDSL2
(Figure 5), from which the various OAM&P
(Operation, Administrative, Maintenance, and Provi-
sioning) screens may be accessed. To display a
particular screen from the menu, press the number key
associated with the screen title and then press the
key.
