ADTRAN T200 Installation And Maintenance Practice page 10

The
Span Status Screen
access to status information for each HDSL2 receiver in
the circuit. The Legend selection provides a description
of the messages that are used on the
.
Screens
CIRCUIT ID:
CIRCUIT ID:
MARGIN(CUR/MIN/MAX): 08/00/10
LINE CODE:
ES-P/ES-L:
SES-P/SES-L:
UAS-P/UAS-L:
10
(Figure 8) provides quick
Span Status
Press ESC to return to previous menu
Span Status Screen
______
|H2TUC |
<------| |
| |
NET | |<--------->|
| |09dB
------>| |
DSX-1 |______|
1. Legend
2. Detailed Status
Selection:
Figure 8. Span Status Screen
Press ESC to return to previous menu
Detailed HDSL2 and T1 Status
HDSL2 RECEIVER DATA
H2TU-C
--------
ATTEN(CUR/MAX): 29/93
ES 15MIN: 010
SES 15MIN: 000
UAS 15MIN: 041
T1 RECEIVER DATA
DSX-1
------
FRAMING: AUTO
B8ZS
000/001
000/001
000/000
ALARMS: NONE
Figure 9. Detail Status Screen
Issue 1, December 2003
The
Detailed Status
the
Span Status Menu
status for each receiver point. From this screen, all
registers can be zeroed (which requires confirmation),
and min/max can be reset.
ATTEN
<-29dB-> ______
|H2TUR |
| |------>
| |
| CUST
10dB| |
MARGIN | |<------
|______| DS1
H2TU-R
--------
11/00/12
29/29
000
000
814
DS1
-------
AUTO
B8ZS
000/008
000/008
822/000
NONE
screen (Figure 9), accessed from
, displays the HDSL2 and T1
10/29/03 09:29:45
10/29/03 09:29:45
1. Zero Registers
2. Restart Min/Max
Selection:
61223024L2-5A
