The
screen
Troubleshooting
mation received from all facilities and equipment in the
circuit and presents them in both Real-Time and 7-Day
historical format.
Circuit ID:
For HELP based on detected problems, select Troubleshooting Guidance from the
list below. If further assistance is needed, contact ADTRAN Tech Support.
Hours: Normal 7am - 7pm CST
Emergency 7 days x 24 hours
Phone: 800.726.8663 / 888.873.HDSL
Fax: 256.963.6217
Circuit ID:
- Patch test set REC jack into H2TUC MON TX jack to verify integrity of
signal to the H2TUC from the network (verify test set in MON mode).
- If signal to H2TUC is missing, insert test set at DSX panel IN Jack connecting
toward H2TUC (to verify wiring between DSX and H2TUC shelf). Check H2TUC to
verify DSX-1 LOS alarm is cleared. This verifies TX(out) and RX(in) pairs are
not swapped.
- If signal from DSX OK, verify cross-connect wiring at DSX panel is turned over
(OUT to IN) and (IN to OUT).
-If DSX wiring OK, connect test set REC to the DSX MON, network side equipment,
to verify signal from network (verify test set to MON). If no signal,
troubleshoot office problems.
For Total Access cards verify the following:
- Provisioning>Network Source is configured correctly for Mux or DSX operation.
- Provisioning>Service State is not configured for OOS-Unassigned.
- Mux card is mapped correctly.
- Mux card is functioning correctly.
61223024L2-5A
(Figure
23) compiles infor-
Press ESC to return to previous menu
Troubleshooting
Selection:
Figure 23. Troubleshooting Screen
Press ESC to return to previous menu
DSX-1 Loss of Signal (Red Alarm)
Figure 24. Troubleshooting Guidance Screen
Issue 1, December 2003
The
Troubleshooting Guidance
option (accessed from the
analyzes this information and makes repair recommen-
dations.
10/29/03 09:29:45
1. Troubleshooting Guidance
2. General Information
10/29/03 09:29:45
screen
(Figure
24)
)
Troubleshooting screen
19
