At each 24-hour interval, the performance data is trans-
ferred into the 24-hour performance data registers. This
unit stores up to 31 days of 24-hour interval data.
CIRCUIT ID:
1. Definitions
2. Reset Data
3. 15 Min Data
4. 60 Min Data
5. 24 Hr Data
6. Line Data
7. Path Data
8. H2TUC DSX-1
9. H2TUC LOOP
10. H2TUR LOOP
11. H2TUR DS1
CIRCUIT ID:
1. Definitions
2. Reset Data
3. 15 Min Data
4. 60 Min Data
5. 24 Hr Data
6. Line Data
7. Path Data
8. H2TUC DSX-1
9. H2TUC LOOP
10. H2TUR LOOP
11. H2TUR DS1
12
Press ESC to return to previous menu
Menu 60 Minute H2TUC DSX-1 Performance Data
01/01 00:00 1800
12/31 23:00 ----
12/31 22:00 ----
12/31 21:00 ----
12/31 20:00 ----
12/31 19:00 ----
12/31 18:00 ----
12/31 17:00 ----
12/31 16:00 ----
12/31 15:00 ----
12/31 14:00 ----
12/31 13:00 ----
Selection:
Figure 12. Performance History, Line Data
Press ESC to return to previous menu
Menu 24 Hour H2TUC DSX-1 Performance Data
ES-L
04497 04497 04496 00002
12/31 ----- ----- ----- -----
12/30 ----- ----- ----- -----
12/29 ----- ----- ----- -----
12/28 ----- ----- ----- -----
12/27 ----- ----- ----- -----
12/26 ----- ----- ----- -----
12/25 ----- ----- ----- -----
12/24 ----- ----- ----- -----
12/23 ----- ----- ----- -----
12/22 ----- ----- ----- -----
Selection:
Figure 13. Performance History, Line Data
Issue 1, December 2003
The user is prompted to select a module and interface to
view the corresponding performance data. Line (L) and
Path (P) related data can be viewed.
ES-L SES-L UAS-L PDVS-L B8ZS-L CV-L
0001 0001 0000 0002
1800 1800 0000
---- ---- ----
---- ---- ----
---- ---- ----
---- ---- ----
---- ---- ----
---- ---- ----
---- ---- ----
---- ---- ----
---- ---- ----
---- ---- ----
---- ---- ----
_ _ _
--8-->| |
| C |<-9--10->|
<-----|_ _ _|
SES-L UAS-L PDVS-L B8ZS-L CV-L
00460
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
_ _ _
--8-->| |
| C |<-9--10->|
<-----|_ _ _|
10/29/03 09:29:45
0427 00000
0000 00000
---- -----
---- -----
---- -----
---- -----
---- -----
---- -----
---- -----
---- -----
---- -----
---- -----
---- -----
_ _ _
| |---->
R |
|_ _ _|<-11-
10/29/03 09:29:45
0000000
-------
-------
-------
-------
-------
-------
-------
-------
-------
-------
_ _ _
| |---->
R |
|_ _ _|<-11-
61223024L2-5A
