Functional characteristics

Power-saving mode (Standby)

Display
5.3 Power-saving mode (Standby)
You can activate the power-saving mode by either pressing the push-button > see 4 chapter for a pro-
longed time or by setting a parameter in the machine configuration menu (time-controlled power-saving
mode ) > see 5.6 chapter.
When power-saving mode is activated, the machine displays show the horizontal digit in the
centre of the display only.
Pressing any operating element (e.g. turning a rotary knob) deactivates power-saving mode and the ma-
chine is ready for welding again.
5.4

Access control

The machine control can be locked to secure it against unauthorised or unintentional adjustment. The ac-
cess block has the following effect:
•
The parameters and their settings in the machine configuration menu, Expert menu and operation se-
quence can only be viewed but not changed.
•
Welding procedure and welding current polarity cannot be changed.
The parameters for setting the access block are configured in the machine configuration
menu > see 5.6 chapter.
Enabling access block
•
Assign the access code for the access block: Select parameter
999).
•
Enable access block: Set parameter
The access block activation is indicated by the "Access block active" signal light > see 4 chapter.
Disabling access block
•
Enter the access code for the access block: Select parameter
number code (0–999).
•
Disable access block: Set parameter
access block is to enter the selected number code.
5.5

Voltage reducing device

Only machine variants with the (VRD/SVRD/AUS/RU) code are equipped with a voltage reduction device
(VRD). The VRD is used for increased safety, especially in hazardous environments such as shipbuilding,
pipe construction or mining.
A VRD is mandatory in some countries and required by many on-site safety instructions for power
sources.
The VRD > see 4 chapter signal light is illuminated when the voltage reduction device is operating without
fault and the output voltage is reduced to a value specified in the relevant standard (see technical data).
44
Setting/selection
Hotstart current
Hotstart time
to access block enabled
to access block disabled
and select a number code (0–
.
and enter the previously selected
. The only way to disable the
