Operating instructions
Inverter
These operating instructions must be read before commissioning.
Failure to do so may be dangerous.
Machine may only be operated by personnel familiar with the appropriate safety
regulations.
The machines bear the conformity mark and thus comply with the
• EC Low Voltage Directive (73/23/EEC)
• EC EMC Directive (89/336/EEC)
Geräte können entsprechend IEC 60974, EN 60974, VDE 0544 in Umgebung mit erhöhter
elektrischer Gefährdung eingesetzt werden.
ã ã ã ã 2002
STICK Welding Machines
from 250A to 350A, portable
inverter
STICK 250 H-2
inverter
STICK 350 CEL
inverter
STICK 350 CEL KLR
inverter
STICK 350 CEL PWS
Subject to alteration.
EWM HIGHTEC WELDING GmbH
Dr.-Günter - Henle - Straße 8; D-56271 Mündersbach
Phone: +49 (0)2680.181-0; Fax: +49 (0)2680.181-244
www.ewm.de
Internet:
; E-mail:
Item No.: 099-002029-EWM01
info@ewm.de
GB
Version: 07.08.02
Advertisement
Table of Contents
Related Manuals for EWM inverter STICK 250 H-2
Summary of Contents for EWM inverter STICK 250 H-2
-
Page 1: Operating Instructions
EWM HIGHTEC WELDING GmbH Dr.-Günter - Henle - Straße 8; D-56271 Mündersbach Phone: +49 (0)2680.181-0; Fax: +49 (0)2680.181-244 www.ewm.de info@ewm.de Internet: ; E-mail: Operating instructions Inverter STICK Welding Machines from 250A to 350A, portable inverter STICK 250 H-2 inverter STICK 350 CEL... - Page 2 / or unauthorized modifications, which changements autorisés, Veränderungen, unsachgemäßen have not been expressly allowed by EWM, réparations inadéquates Reparaturen und / oder unerlaubten this declaration will lose its validity. modifications prohibeés, qui n´ont pas été Umbauten, die nicht ausdrücklich von autorisés expressément par EWM, cette...
-
Page 3: Table Of Contents
Table of contents Page Safety instructions..........................S/1 For your safety..........................S/1 Transport and Installation ......................S/3 Ambient conditions ........................S/3 Notes on the use of these operating instructions ............... S/3 Technical data........................... 1/1 Area of application......................1/1 Description of the machine ..................... 2/1 Function specification for logic control................. -
Page 4: Safety Instructions
Safety instructions For Your Safety: Ignoring the following safety precautions can be fatal. Observe accident prevention regulations. Designed use This machine is manufactured according to the current state of the art and current regulations and standards. It is to be operated only for the designed use (see Chap. Commissioning/Area of application). - Page 5 Safety instructions Smoke and gases can lead to breathing difficulties and poisoning. · Do not breathe in smoke and gases. · Ensure that there is sufficient fresh air. · Keep solvent vapours away from the arc radiation area. Chlorinated hydrocarbon fumes can be converted into poisonous phosgene by ultraviolet radiation.
- Page 6 Safety instructions Interference by electrical and electromagnetic fields is possible e.g. from the welding machine or from the high-voltage pulses of the ignition unit. · As laid down in Electromagnetic Compatibility Standard EN 50199, the machines are intended for use in industrial areas; if they are operated e.g. in residential environments problems can occur in ensuring electromagnetic compatibility.
-
Page 7: Notes On The Use Of These Operating Instructions
Safety instructions Transport and set-up Machines may only be moved and operated in an upright position. Before moving, pull out mains plug and place on the machine. Secure high-pressure shielding gas cylinder with safety chain to prevent it from toppling over. -
Page 8: Technical Data
Technical data Inverter STICK 250 H-2 STICK 350 CEL STICK350CELPWS Welding current 5A - 250A 20A - 350A Welding voltage 20.2V -30V 20.2V -34V Max. welding voltage Duty cycle (40ºC) Max. welding current at 30%DC 350A 60%DC 250A 190A 100%DC 10min (60% DC ∧... -
Page 9: Description Of The Machine
Description of the machine Inverter Fig. 1: Front view of STICK 350 CEL PWS Item Symbol Description Carrying handle Main switch P P P P ole changeover switch (STICK 350 CEL PWS only) Position means : negative welding voltage potential ( ) at welding current socket positive welding voltage potential ( ) at welding current socket... -
Page 10: Logic Control
Function specification Logic control Fig. 1: Logic control Item Symbol Description Hotstart current Hotstart current I Hot infinitely adjustable from the minimum to the maximum welding current. The hotstart device makes it possible to ignite and re-ignite critical stick electrodes easily. Adjustable arcforcing Shortly before the electrode threatens to stick, the arcforcing device sets an increased current designed to prevent the electrode from sticking. -
Page 11: Function Sequence For Mma Welding
Function specification Antistick If the stick electrode sticks despite the arcforcing device, the machine automatically switches over to the minimum current within about 1 second to prevent the electrode overheating. If the antistick device has been triggered, check the welding current setting and correct if necessary. Functional sequence for MMA welding Hotstart-Strom Hauptstrom... -
Page 12: Remote Control
Function specification Remote control Only the remote controls described in these operating instructions should be connected! Plug the remote control into the remote control socket (chap. 2, H1) and lock it only when the machine is switched off. The remote control is detected automatically when the welding machine is switched on. See the operating instructions for the remote control for more detailed information. - Page 13 Function specification FR 30 KL cableless manual remote control Functions • The welding current I can be set to any value from the minimum to the maximum current regardless of the welding current selected on the machine. Commissioning: • The changeover switch on the welding machine must be in the ON position (cableless remote control active) Features •...
- Page 14 Quick start – the shortest way to welding (observe safety instructions) Preparations Setting Fault elimination • Plug in the mains plug. • Set welding current I Poor welding properties (Remember fuse!) • Incorrect polarity setting on the pole changeover switch. •...
-
Page 15: Commissioning
Commissioning Commissioning Area of application The machines are used exclusively for stick electrode direct current welding. 5.1.1 Proper usage These welding machines are suitable only for MMA direct current welding for rutile, basic and cellulose electrodes. Any other use is regarded as "improper" and no liability is assumed for any damage arising therefrom. -
Page 16: Maintenance And Care
Maintenance and care Under normal operating conditions, these welding machines are largely maintenance-free and require a minimum of care. However, a number of points should be observed to guarantee the fault-free operation of your welding machine. These include regular cleaning and checking, as described below, depending on the level of contamination in the environment and the amount of usage of the welding machine. -
Page 17: Repair Work
Maintenance and care 6.2.3 Measurement of insulation resistance Disconnect the machine from the mains. Remove the mains plug! Open the machine and clean carefully (as described above). Switch on mains switch. • Insulation resistance mains current circuit-casing Switch on mains switch. a) Step switch controlled machines: The machine must be opened. -
Page 18: Customer Checklist
Operating faults, causes and remedies Operating faults, causes and remedies All machines are subjected to strict manufacturing and final inspection procedures. If, despite this, something fails to work at any time, please check machine using the following process chart. If none of the fault elimination procedures described results in the correct functioning of the machine, please contact your authorised dealer. -
Page 19: Spare Parts List
Ersatzteilliste / Spare Parts List Ersatzteilliste / Spare Parts List Vorderseite / front side Abb. / picture 1 inverter inverter Pos. Bezeichnung Description STICK 250H-2 STICK 350 Halterung für Griffstange Holder for hand grip 074-000237-00000 Griffstange Hand grip 074-000237-00005 074-000237-00013 Hauptschalter EIN/AUS Mains switch ON/OFF 074-000279-00000... -
Page 20: Rear View
Ersatzteilliste / Spare Parts List Rückseite / rear view Abb. / picture 2 inverter inverter Pos. Bezeichnung Description STICK 250H-2 STICK 350 Kabelverschraubung Cable gland 094-003293-00000 Kabelverschraubung Mutter Cable gland nut 024-000205-00001 Netzkabel Mains cable 092-000661-00000 092-000662-00000 Gehäusedeckel Housing cover 094-002817-00002 094-002744-00003 Sicherungshalter mit Mutter... -
Page 21: Inverter
Ersatzteilliste / Spare Parts List inverter STICK 250H-2 8.3.1 Rechte Seite / right side Abb. / picture 3 Pos. Bezeichnung: Description: STICK 250H-2 Leiterplatte Schutzbeschaltung PCB contactor switching 040-000531-00000 PCB Schweißelektronik PCB welding electronic 040-000470-00001 PCB Inverter Steuersatz PCB inverter control stack 040-000290-00022 Sek. - Page 22 Ersatzteilliste / Spare Parts List 8.3.3 Linke Seite / left side Abb. / picture 5 Pos. Bezeichnung Description STICK 250H-2 Primärschalter Minus INV50/1000.6M Primary switch 080-000294-00000 Primärschalter Plus INV50/1000.6P Primary switch 080-000295-00000 Varistor Schutzbeschaltung für Varistor modules, protective circuit 072-000292-00000 Netzgleichrichter SB460/6 for mains rectifier Thyristor Dioden Modul MTD55-14A...
-
Page 23: Inverter
Ersatzteilliste / Spare Parts List inverter STICK 350 / 350CEL / 350CEL PWS 8.4.1 Rechte Seite / right side Abb. / picture 6 Pos. Bezeichnung Description STICK 350 Leiterplatte Schutzbeschaltung PCB contactor switching 040-000427-00001 DSB3/4.1 Sekundär Diodenkühler Secondary diode cooler 072-000417-00000 SDK6XMDDM 121-04 F02-01/1 Leiterplatte Schutzbeschaltung... - Page 24 Ersatzteilliste / Spare Parts List 8.4.2 Von oben / from the top side Abb. / picture 7 Pos. Bezeichnung Description STICK 350 Leiterplatte Treiberelektronik TRI4 PCB for the driver electronics 040-000503-00000 Leiterplatte Primärschalter 2DW7.5 PCB primary switch 042-000411-00000 Inverter Steuersatz Primärseite Inverter control stake primary side 040-000303-00000 DW7,5/380/1...
-
Page 25: Remote Control
Accessories Accessories Remote control 9.1.1 STICK 250 H-2 / 350 CEL / 350 CEL / 350 CEL KLR / 350 CEL PWS Designation Description Item No. FR30 Electric remote control with holding magnet, 5m 090-008005-00000 FR30 Electric remote control with holding magnet, 10m 090-008005-00010 FRF30 Electric remote control with holding magnet, 5m... -
Page 26: Circuit Diagrams
Schaltpläne / Circuit Diagrams Schaltpläne / Circuit Diagrams 10.1 STICK 250 H-2 10/1... -
Page 27: Stick 350 Cel
Schaltpläne / Circuit Diagrams 10.2 STICK 350 CEL 10/2... -
Page 28: Stick 350 Cel Klr
Schaltpläne / Circuit Diagrams 10.3 STICK 350 CEL KLR 10/3... -
Page 29: Stick 350 Cel Pws
Schaltpläne / Circuit Diagrams 10.4 STICK 350 CEL PWS 10/4...
