Functional characteristics
TIG welding
5.1.9.5

Standard TIG torch (5-pole)

Standard torch with one torch trigger
Figure
Functions
Welding current on/off
Secondary current (latched operation)
Standard torch with two torch triggers
Figure
Functions
Welding current on/off
Secondary current
Secondary current (tapping function)
Welding current on/off
Secondary current (tapping function)
2
Up function
Down function
1
> see 5.1.9.1 chapter
2
> see 5.1.9.3 chapter
30
Operating ele-
ments
Operating ele-
ments
1
)/(latched operating mode)
1
)/(latched operating mode)
2
Explanation of symbols
BRT1 = torch trigger 1 (welding current on/off; secondary cur-
rent via tapping function)
Mode
Explanation of symbols
BRT1 = torch trigger 1
BRT2 = torch trigger 2
Operating ele-
ments
1
(ex works)
Mode Operating ele-
ments
1
(ex works)
3
