Operating modes (functional sequences)

5.1.5.1

Explanation of symbols

Symbol
Meaning
Press torch trigger 1
Release torch trigger 1
Current
I
Time
t
Gas pre-flow
Ignition current
Start time
Up-slope time
Spot time
Main current (minimum to maximum current)
AMP
Secondary current
AMP%
Pulse current
Pulsed TIG welding: Slope time from main current (AMP) to secondary current (AMP%)
Pulsed TIG welding: Slope time from secondary current (AMP%) to main current (AMP%)
Down-slope time
End-crater current
End-crater time
Gas post-flow
Balance
Frequency
099-00T404-EW501
02.07.2020
Functional characteristics
