vCam-6 User Handbook
(English Edition)
Version 1.1
P/N:4.04.000087

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the vCam-6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vivax Metrotech vCam-6

Summary of Contents for Vivax Metrotech vCam-6

  • Page 1 User Handbook (English Edition) Version 1.1 P/N:4.04.000087...

  • Page 3: Table Of Contents

    Reels.................................2 2.1.3 Camera Heads..............................2 Firmware Revision Location............................3 Request for Service................................3 Distributors and Service Centers..........................4 Introduction....................................5 The vCam-6 Inspection Camera System........................5 Standard Equipment - Control Module........................5 vCam-6 Control Module Overview..........................6 vCam Series Cable Reels Overview..........................8 3.4.1 Standard Equipment - Reels........................8 3.4.2 Type-CP Standard Reel..........................9...
  • Page 4 4.2.12 The About Screen............................21 4.2.13 Video Out...............................22 Video Recording and Picture Image Capture........................23 Overview..................................23 Main File Menu ................................23 5.2.1 File List Sub-Menu............................24 5.2.2 File Option Sub-Menu..........................25 5.2.3 Media Select Sub-Menu..........................25 Video Recording and Playback Controls.........................26 5.3.1 Making a Video Recording......................27 5.3.2 JPEG Image Picture Capture........................28 Play Videos and View Pictures in the Control Module..................28...
  • Page 5 8.1.6 Deployment of the Pushrod Cable......................49 Camera Heads and Terminations............................52 Parts of the Camera Heads............................52 9.1.1 Camera Head Options..........................53 Spring Termination Parts............................54 9.2.1 Type-CP Termination Spring Kits......................54 9.2.2 Spring................................54 9.2.3 Coiled Cable Assembly..........................55 9.2.4 Lanyard Set..............................56 9.2.5 Termination Parts List..........................56 Removing the Camera Head –...
  • Page 6 Troubleshooting..................................79...

  • Page 7: General Safety Instructions

    General Safety Instructions General Safety Instructions Health and Safety This equipment is primarily used for the inspection of sewer pipes by professionals operating in the sewer and plumbing industry. Maintained by professionals familiar with the health risks of maintaining equipment that has been in a sewer. Such professionals will be protected by their own company’s recommendations and work practices.

  • Page 8: Service & Support

    Always quote your camera system’s model number, serial number and software revision number when requesting product support. 2.1.1 Control Module The vCam-6 Control Module model number and serial numbers is found on the back of the unit. Serial Number 2.1.2 Reels The serial numbers for the vCam series reels are found on the label affixed to the frame located at the center of the frame on the opposite of the locking and friction brakes.

  • Page 9: Firmware Revision Location

    Service & Support The camera skid must be removed to view the serial number of the camera head. The serial numbers for all camera heads are etched into the camera base across the length of the camera or in the recessed area of the camera housing. Serial Number Firmware Revision Location The “About”...

  • Page 10: Distributors And Service Centers

    Service & Support Distributors and Service Centers Worldwide Sales Offices and Service Centers World Headquarters, United State of America Central/South America and the Caribbean Vivax-Metrotech Corporation Ventas para América Latina 3251 Olcott Street, 3251 Olcott Street, Santa Clara, CA 95054, USA Santa Clara, CA 95054, USA Website : www.vivax-metrotech.com T/Free...

  • Page 11: Introduction

    Introduction Introduction The vCam-6 Inspection Camera System The vCam-6 Inspection System consist of three major components: vCam-6 Control Module, vCam Series Reels, and Camera Heads. Standard Equipment - Control Module Along with the vCam-6 Control Module, the following accessories are included: Soft Carry Pouch To hold all the accessories.

  • Page 12: Vcam-6 Control Module Overview

    Control Module Overview The vCam-6 control module allows for the viewing, recording and playback of Audio Video Interleave (AVI) format video as well as image capturing of Joint Photographic Experts Group (JPEG) pictures. Audio and text commentary can be added to the videos and text commentary can be added to the captured pictures.
  • Page 13 Introduction Use this key to forward through the currently playing video. Press up to three times Forward Video Playback again to increase the forward speed. Use this key to end a video recording session or to stop a video being played in the Stop Recording control module.

  • Page 14: Vcam Series Cable Reels Overview

    Standard Equipment - Reels Both the Type-CP and MX reels include pushrod with an installed termination spring assembly. The vCam-6 control module can be mounted and locked on top of the larger Type-CP reel which allows for viewing at a comfortable height.

  • Page 15: Type-Cp Standard Reel

    Type-CP Standard Reel Mounting Blocks For mounting and locking the vCam-6 control module in place. Helps control the deployment and retrieval of the pushrod cable by keeping it in a Cable Guide Assembly localized area.

  • Page 16: Mx Mini Reel

    Introduction The sonde locate signal emits from this cup. This locate signal can be picked up on Sonde the surface by a utility or sonde locator with matching frequency. Spring Termination Attaches to the pushrod and gives flexibility to lead the pushrod through bends in the Assembly pipe.

  • Page 17: Initial Control Module Setup

    Initial Control Module Setup Initial Control Module Setup Initial Control Module Setup 4.1.1 Installing the Fuse Install the 10 Amp - 250 Volt fuse in the fuse compartment on the back of the control module. The control module will operate without a fuse when using AC power, but the battery will not charge, and the unit will turn off when the AC power is removed.

  • Page 18: The Interconnect Cable

    About Control Module Settings The initial setup of the vCam-6 control module is done with the keyboard. A USB or wireless mouse can also be used. All the settings selected are saved into the control module’s memory and will remain until changed. Note that the settings will be lost if the unit is reset to factory defaults, running certain firmware updates or by formatting the hard drive.

  • Page 19: Keyboard Keys Used In The Setup Menu

    Initial Control Module Setup 4.2.1 Keyboard Keys used in the Setup Menu Directional Arrows: Pressing the directional up and down arrow keys moves through the list of options in the Setup menu. As the up / down arrow keys are moved, the selection is highlighted in yellow. Stop on the desired option then press Enter or use the right arrow key to see the choices within the selected menu option.

  • Page 20: Setting The Default Storage

    Initial Control Module Setup WARNING The control module must reboot to make this change. 4.2.3 Setting the Default Storage Setting the Default Storage selects which drive (SD, Hard Drive or USB) will be used as the default. If the hard drive is selected all video recordings and pictures will be saved to this drive.

  • Page 21: Setting The Distance Counter

    Initial Control Module Setup 4.2.4 Setting the Distance Counter The distance counter sets the unit of measurement to be used. The choices are imperial (feet) or metric (meters). The distance of pushrod deployed will be shown on the main screen above the status bar and will appear in videos and pictures when this feature is activated by using the F2 Info key.

  • Page 22: Setting The Sonde Frequency

    Initial Control Module Setup Default Storage Format Date: Format MM/DD/YYYY Distance Counter Date/Time DD/MM/YYYY Sonde 33k/512/640 YYYY/MM/DD Wi-Fi Time: Video Out 12 hour 24 hour Language Settings Restore Date: 09 / 15 / 2017 Reel Settings Time: 13 : 50 : 45 Update About File...

  • Page 23: Setting The Reel Type

    Initial Control Module Setup Default Storage Format WiFi : Setup IP Address: 192.168.1.108 Distance Counter Date/Time WiFi: Setup WiFi: Sonde 33k/512/640 Router SSID： IP Address: 192.168.1.108 Wi-Fi Video Out Router SSID： vCam62017 Change Language Router SSID Restore Cancel Factory Setup Only Reel Settings Password: Update...

  • Page 24: Restore The Factory Default Settings

    Initial Control Module Setup 4.2.9 Restore the Factory Default Settings Restoring the default settings will erase all the settings on the control module and return it to the factory default. This will not erase any videos or images on the hard drive. Press the F10 Menu twice to bring up the Setup menu.
  • Page 25 Initial Control Module Setup Extract the firmware update files and copy the .bin and or .soc file to a SD or USB device. The files must be on the root drive of the drive or card, i.e. the files must not be compressed or in a folder on the device. Plug the SD or USB device into the control module.
  • Page 26 Initial Control Module Setup Default Storage Format Distance Counter Date/Time Update Firmware Startup Screen Sonde 33k/512/640 Wi-Fi Video Out Language *.bin file *.soc file Restore Reel Settings Update About File setup Use the up and down arrow keys to highlight and select the .bin or .soc file and press Enter. Default Storage Format Distance Counter...

  • Page 27: 4.2.11 Update The Control Module Start Screen

    Initial Control Module Setup UPGRADE FINISHED Upgrade success, system will restart, click “OK” to continue. File File setup setup 11. Repeat these steps if both the .bin and .soc file need to be updated. 12. Verify that the firmware update was successful by checking the firmware version in the About section of the setup menu. 4.2.11 Update the Control Module Start Screen This option allows the personalization of the second start screen seen when the control module is starting.

  • Page 28: Video Out

    Initial Control Module Setup Default Storage Format Distance Counter Date/Time Sonde 33k/512/640 Message Wi-Fi Video Out Version:vCam6_DVR_T005 Language vCam6_MCU_6.03 Restore Release date:2017.09.15 10:37:35 Reel Settings Video format:D1 NTSC Update About File Setup Use the left arrow key or ESC key to return to the Setup menu. 4.2.13 Video Out When using the video out socket with certain LACP Observation Software, changing the video out setup may be needed.

  • Page 29: Video Recording And Picture Image Capture

    To accomplish these items, we must understand the menu system, file system and navigation in them. Main File Menu The vCam-6 control module uses a cascading menu system which primarily uses the left , right , up...

  • Page 30: File List Sub-Menu

    Video Recording and Picture Image Capture 5.2.1 File List Sub-Menu The file list sub-menu shows the list of files, videos and or pictures, which are on the hard drive. Contents of a SD or USB device can also be viewed if they are currently plugged into the control module. In the video file list sub-menu pausing on a video file will start a preview window, the file preview dialog box will also show the length of the video and its size in MB.

  • Page 31: File Option Sub-Menu

    Video Recording and Picture Image Capture 5.2.2 File Option Sub-Menu The File Option sub menu shows the options available for files selected in the previous file list sub menu. The File Options sub-menu consist of: Play Video or View Picture – The Play option will start playing the recorded video or view an image file.

  • Page 32: Video Recording And Playback Controls

    Video Recording and Picture Image Capture Left and Right arrow The Left and Right arrow keys move through the file sub-menus. keys The Up and Down arrow keys scroll the list of video and picture files in the Up and Down arrow file list sub-menu, scrolls the choices in the file option sub-menu and scrolls keys the options in the media select sub-menu.

  • Page 33: Making A Video Recording

    Video Recording and Picture Image Capture Use this key to start a recording. A red flashing recording icon will appear on the bottom Start Recording left section of the status bar on the screen and the elapsed recording time will appear bottom center.

  • Page 34: Jpeg Image Picture Capture

    Video Recording and Picture Image Capture 5.3.2 JPEG Image Picture Capture Pictures will be saved to the default drive you selected in the initial control module setup screen. If no other drive is selected the pictures will be saved on the internal hard drive. Press the Picture Capture key on the top panel keypad.

  • Page 35: Renaming A Video Or Jpeg Image File

    Video Recording and Picture Image Capture 5.4.2 Renaming a Video or JPEG Image File Video and picture files on the control module can be re-named from the default date format used. File name can be up to 20 alpha numeric characters. !@#$%^&*() and . are characters that cannot be used to rename a file. After the file is renamed the location of the file is still at the same location in the file list as originally placed by the default date format file name.

  • Page 36: Copy, Move Or Delete Videos And Pictures

    Video Recording and Picture Image Capture 5.4.3 Copy, Move or Delete Videos and Pictures In the File Option sub-menu files can be copied or moved to an SD or USB device, or they can be deleted from the hard drive. Plug an SD or USB device into the appropriate slot in the control module to copy or move files.

  • Page 37: File Format Of Sd Cards And Usb Devices

    File Format of SD Cards and USB Devices The vCam-5 and vCam-6 control modules will recognize USB thumb drives and SD cards that are formatted in the FAT32 or NTFS file system and a maximum size of 64GB for SD cards and 128GB for USB thumb drives. If other file formats are used the control module will show an error message of “Not enough space on disk”...

  • Page 38: Troubleshooting Video Playback

    Video Recording and Picture Image Capture Troubleshooting Video Playback If a video file can be played in the vCam control module it will be able to be played in a laptop or personal computer. If files cannot be played in the control module it is possible the video file has become corrupt. When files can be played in the control module but not in a PC the follow should be checked in this order.
  • Page 39 Video Recording and Picture Image Capture If Windows Media Player is not shown on the list of available programs, select “Choose Default Program” in the bottom right corner. Select “Windows Media Player” here. Method Two In Windows 10 go to SETTINGS and select Apps. Now select Default Apps.
  • Page 40 Video Recording and Picture Image Capture Scroll down and select Video Player, click on the Plus icon or other icon which may be shown. Select Windows Media Player. Now Windows Media Player is the video default player. ™ Page 34 of 81...
  • Page 41 Video Recording and Picture Image Capture Method Three In windows Default Apps in windows SETTINGS click on Choose default apps by file type. Scroll through the list of file extensions on the left looking for “avi Video Clip” Note that in the below illustration Movies and TV is selected as the current default app for avi file types. With this configuration when double clicking on a avi extension, the app Movies &...

  • Page 42: Getting Codecs

    Video Recording and Picture Image Capture Click on the Plus symbol or icon of the program to open up the pop up list of app choices for this type of file. Getting Codecs The video and audio tracks in a file have been "encoded" or "coded” and must be “decoded” in the right way in order to play the file back.

  • Page 43: Corrupt Video Files

    Video Recording and Picture Image Capture 5.10 Corrupt Video Files A file typically becomes corrupted when a problem occurs during the recording session, saving of the file, or copying or moving of the video file. If your control module loses power or crashes as you copy or move a file, there's a good possibility that the file will become corrupted.

  • Page 44: Features Available During Recording

    Features Available During Recording Features Available During Recording During a video recording the following options are operational and usable: • Wi-Fi (see section 7, Wi-Fi and Ethernet) Sonde (see section 11, Locating Sondes and Pushrod) • Audio Commenting (see section 6.1, Voice Over) •...

  • Page 45: Display And Backlight Settings

    Features Available During Recording Display and Backlight Settings At any time pressing the F9 Display key will bring up the color settings/backlight sub-menu. From this menu the color settings for the LCD can be made, touchscreen function turned on or off and the backlight turned on or off. Use the up and down arrow keys to move between the color settings selections.

  • Page 46: Text Writer

    Features Available During Recording Text Writer 6.7.1 Introduction to the Text Writer The Text Writer function allows users to add descriptive text and comments to recorded videos and pictures. The user can customize the text description being shown on the videos and pictures. The Text Writer has 20 pages with 14 lines and 30 characters per line per page to be saved and later recalled for use.
  • Page 47 Features Available During Recording Change Background F4 – Text Background – Use the F4 key to add a background color and toggle Colors through the background colors of black, white, and grey. F5 – Recall Page – Use the F5 Recall key to retrieve a saved page of text from memory.

  • Page 48: Text Writer Components

    Third party observation software (PACP and LACP) can be used with the control module through the USB Data Port and Video Out composite socket. 6.7.3 Text Writer Components LCD Detail VCAM-6 “LIVE VIEW” INTERFACE STREAM LIVE VIDEO TO PC RECORD DIRECT TO PC HDD VIEW & DOWNLOAD PIC & VIDEO Page1 Main viewing screen of the control module.

  • Page 49: Digital Zoom

    Features Available During Recording 6.9. Digital Zoom Use the zoom feature while viewing live video, recorded video or jpeg captures. Press the Zoom button on top panel keypad to activate the zoom feature and bring up the red zoom control box on the screen.

  • Page 50: Wi-Fi

    Wi-Fi Connection for Apps The vCam-6 Control Module has built in Wi-Fi that broadcasts an SSID (secure network name) and uses DHCP (the protocol that assigns an IP address needed to connect to the control module) to assign IP addresses to a tablet or smartphone.

  • Page 51: Cable Reels

    Cable Reels Cable Reels Cable Reel Overview 8.1.1 Pushrod Cable The Pushrod Cable used on both reels is constructed of a fiberglass rod surrounded by wire conductors and a Kevlar braid, all of which are coated with a thick polypropylene jacket. Because of the harsh environment the pushrod is used in, care should be taken to keep it in good operating condition.

  • Page 52: Mounting The Control Module

    Cable Reels Correct Incorrect 8.1.3 Mounting the Control Module Line up the four pins on the control module bottom to the slots in the reels mounting blocks. Lower the control module into the mounting blocks. Push the control module backward until locked into place. Unspool enough of the interconnect cable from the reel to allow its plug to reach the socket on the control module.
  • Page 53 Cable Reels Plug the interconnect cable into the control modules bottom socket. This is a keyed plug and socket so be sure to line up the red dot on the interconnect cable plug to the same red dot on the interconnect socket on the control module.

  • Page 54: Remove The Control Module

    Cable Reels 8.1.4 Remove the Control Module Press and hold down the locking tab to release the locking mechanism. With the locking tab held down use an upward and forward motion at the same time to lift the control module out of the mounting brackets. 8.1.5 Distance Counter Accuracy For best results from the distance counter follow these instructions starting with the control module turned off.

  • Page 55: Deployment Of The Pushrod Cable

    Cable Reels Attach the interconnect cable to the control module. Power on the control module. When the control module starts it will see the position of the sonde as “zero”. Also check section 4.2.8 of this manual regarding “Setting the Reel Type”. 8.1.6 Deployment of the Pushrod Cable WARNING...
  • Page 56 Cable Reels Before deploying the pushrod, you should: Remove standing water from the pipe before inspecting. Inspection cameras are used to inspect pipes and the images will be much better if the camera head is not underwater. Remove debris and objects from the pipe first. The camera is made to inspect the insides of pipes and not to clean them or unblock them.
  • Page 57 Cable Reels When accessing a “Tee” entry use a string to bend lift the camera head and point it in the desired direction in the Tee. Be extra careful in Tee entries not to fold the camera back on itself; this could cause the camera to get stuck in the pipe. Be sure to use the correct model camera in the correct size pipe.

  • Page 58: Camera Heads And Terminations

    Camera Heads and Terminations Camera Heads and Terminations Parts of the Camera Heads D34 and D46 Series Cameras for Type-CP Standard Reel Camera Head Face Sapphire glass lens Polycarbonate LED cover Camera Head Body Camera Base Threads Skid Screw Groves Main Housing Camera Head Rear Alignment Key...

  • Page 59: Camera Head Options

    The vCam-6 is an HD format control module and will record in full 1080p high definition when used with the HD version D34-HD and D46-HD camera heads. The vCam-6 will also work with older analog D34-M, D34-C, or D46-CP camera heads.

  • Page 60: Spring Termination Parts

    Camera Heads and Terminations Camera Head Options for Mini MX Reel Camera Heads Fits Reels Description Pipe Size Range D18-MX NTSC (USA) 2 to 4 inches MX Mini Reel D18-MX D18-MX PAL (Europe) 50 to 100mm Non-Leveling 18mm / 0.76” diameter D26-MX NTSC (USA) 2 to 4 inches MX Mini Reel...

  • Page 61: Coiled Cable Assembly

    Camera Heads and Terminations Type-CP Standard Termination Spring Pushrod End Open Coils Camera End Lead Spring Coil MX Mini Termination Spring Assembly Camera End with Circular Circuit Board Spring Assembly with Coiled Cable and Lanyard Pushrod End with Push Pins 9.2.3 Coiled Cable Assembly The coiled cable assembly is the electrical connection between the pushrod and camera head.

  • Page 62: Lanyard Set

    Camera Heads and Terminations Connector Base Detail Lanyard Slots O-Rings Keyed 4-Pin Camera Socket 9.2.4 Lanyard Set The stainless-steel set of lanyards within the spring attach the base of the termination by the pushrod to the camera head. These lanyards prevent the spring from over-extending when retrieving the camera. Steel Lanyard Wire Rope Retaining Ball...

  • Page 63: Removing The Camera Head - D34 And D46 Series Cameras

    Camera Heads and Terminations Spring Kit, 12mm Short (33mm dia. x 7” / Kit includes a Spring, Coiled Cord Assembly and pair 18cm long spring) of Steel Lanyards All-in-one assembly consisting of spring, coiled cable MX Spring Assembly and lanyard preassembled Contact a local Vivax-Metrotech distributor or local office for ordering information, applications, compatibility and pricing.

  • Page 64: Removing The Standard Reel's Termination Spring And Coiled Cable

    Camera Heads and Terminations Firmly grasp the connector base and carefully pull it out of the camera base. Clean off any grease and debris from the o–rings at the base of the camera and connection plug if needed. Store the camera head in a clean dry place to prevent corrosion to any camera parts and prevent the pins from being damaged.

  • Page 65: Installing The Standard Reel's Coiled Cable And Termination Spring

    Camera Heads and Terminations Un-screw the floating camera nut from the termination base. Firmly grasp the connector base and pull it out of the termination base. Clean off any grease and debris from the o–rings at the base of the camera and connection plug if needed. Store the camera head in a clean dry place to prevent corrosion to any camera parts and prevent the pins from being damaged.

  • Page 66: Pre-Checking The Termination Spring

    Camera Heads and Terminations Check the Coiled Cable for: Jacketing – Check that the jacket of the cable does not have any cuts or abrasions. When connected to a control module • wiggle the cable at the base of the connections to check for hidden breaks in the cable. Connectors –...
  • Page 67 Camera Heads and Terminations Clean the threads in the termination base then apply a liberal bead of silicone grease to the base female threads. Feed the two lanyards through the floating camera nut and insert into the lanyard slots. Make sure that the lanyards are straight and not tangled in the coiled cable.
  • Page 68 Camera Heads and Terminations Feed the opposite end of the lanyards through the floating camera nut and insert into the opposite connector bases lanyard slots. Make sure that the lanyards are straight and not tangled in the coiled cable. Pull the knurled camera nut up and over the lanyards. Wrap a piece of electrical tape around the floating camera nut securing the nut with lanyards to connector.

  • Page 69: Pre-Checking The Camera Head Before Installing

    Camera Heads and Terminations 12. Pull enough of the coiled cable to work with to attach a camera head. 9.6.2 Pre-checking the Camera Head Before Installing If the occasion should arise where a camera head must be re-installed or replaced, pre-check these items before the camera is fully installed.

  • Page 70: Installing The D34 And D46 Series Camera Heads

    Camera Heads and Terminations Sapphire Glass Lens The Sapphire Glass camera lens is the center clear glass section of the camera face. Visually check the outside radius for chips and cracks. Visually check the surface of the glass for scratches. If you suspect that any cracks or chips may let moisture in, or if you suspect that scratches on the lens may affect the video quality, contact the factory or your local dealer.

  • Page 71: Removing And Installing The D18-Mx And D26-Mx Camera Heads Onto The Mx Mini Reel

    Camera Heads and Terminations Use a nylon cable tie to compress some of the coils in the spring. This will give you a few inches of space to work in while attaching the camera. Line up the keyway on the 4-pin male and female socket and plug and press the coiled cable connector into the camera head.

  • Page 72: Removing And Installing The Mx Spring Assembly

    Camera Heads and Terminations Removal: Grasp the spring assembly close to the base of the camera head. Use the other hand to turn the camera head counter-clockwise. Turn until the camera is removed. Installing: Remove any excess dirt that might come into contact with the gold pins or green circuit board. Check that the O-ring is in good condition.

  • Page 73: 10. Camera Skids

    Camera Skids 10. Camera Skids 10.1 Camera Skids Camera skids are devices that attach to the camera head to 1) keep the camera head off the floor of the pipe, to help avoid pushing up debris and dirt on which will end up on the cameras lens blocking your view, 2) allow the camera LED lighting to function better by keeping the lights more centered in the pipe allowing a more even spread of light on the pipe walls and ahead and 3) provide protection to the camera head by giving a shoveling effect which allows the camera head to be lifted over offsets and objects which helps prevent the camera head from making direct contact with them.

  • Page 74: 10.2.2 Guide Skid Installation

    Camera Skids NOTE Do not over tighten the setscrews. This may result in striping the screw threads or damage to the camera housing. Apply a layer of electrical tape over the screw holes on the installed skid. This will help keep debris and soil out of the screw slots making it easier to remove.

  • Page 75: 10.2.3 Removable Rubber Guard Skids

    Camera Skids NOTE Do not over tighten the setscrews. This may result in damage to the camera housing. 10.2.3 Removable Rubber Guard Skids Some of the vCam series skids will come with a removable rubber front guard. The removable rubber front is meant to protect the camera it should make direct contact with objects such as offsets.

  • Page 76: 10.2.5 Type-B Skid Installation

    Camera Skids 10.2.5 Type-B Skid Installation Tools needed: Hex Key to remove standard skid and 8mm Hex Key to secure into. Use a hex key or screwdriver to remove the standard skid from the D46 series camera. If using a D34 series camera leave the standard skid on to act as an adapter to take up the empty space in the Type-B skid.

  • Page 77: 10.2.7 Type-B Light Kit Installation

    Camera Skids 10.2.7 Type-B Light Kit Installation Remove battery caps and on/off switch. Insert three fresh AA alkaline batteries, positive end first into battery tubes. Replace the battery caps and on/off switch. Align light kit battery tubes with light kit grooves on skid. Apply even pressure to push the light kit into place.

  • Page 78: 11. Locating Sondes And Pushrod

    Locating Sondes and Pushrod 11. Locating Sondes and Pushrod 11.1 Introduction All vCam series reels include a locatable sonde located at the base of the spring termination assembly. The controls for the sonde are located on the front panel of the control module. The newer version Type-CP reel (purchased after April of 2014) and all MX reels include the option to trace the entire length of pushrod.

  • Page 79: Vm-540 Sonde And Camera Locator

    Locating Sondes and Pushrod Turn on the utility locator transmitter and select a frequency. We recommend using a higher frequency such as 33 kHz, 65 kHz or 83 kHz. Ensure that the transmitter has a good ground. The better the ground the better the locator will perform. Use the utility locator in the line mode, not sonde mode to trace the path of the pushrod underground.
  • Page 80 Locating Sondes and Pushrod Power Mode Operation Switch on the receiver by pressing the On/Off pushbutton. Allow the unit a few seconds to switch on. The frequency selected is shown on the display. If this is not the desired locate frequency (i.e. 50 or 60 Hz) change as instructed below.
  • Page 81 Locating Sondes and Pushrod Sonde Locating with the VM-540 Power up the Sonde and securely attach it to a suitable duct rod for the application. Insert the Sonde and position it to the pipe or duct leaving it still visible. Hold the locator above the Sonde at ground level.
  • Page 82 Locating Sondes and Pushrod Moving back and forth across the Sonde will not detect ghost signals. Now push the Sonde a few feet into the pipe. Stop and re-locate the Sonde. The direction of the Sonde can be confirmed by holding the locator vertically and rotating it on its axis until the largest signal is detected.

  • Page 83: 12. Accessories

    Accessories 12. Accessories 12.1 Skid Range Model Description & Diameter Picture Available for cameras D18-MX Standard Standard Skid, comes with the camera D18-MX D26-MX Standard Standard Skid, comes with the camera D26-MX D34-C, D34-M Standard Standard Skid, comes with the camera D34-C or D34-M D34 HD Standard Standard Skid, comes with the camera...

  • Page 84: Camera And Sonde Locators

    Type-C vCam-6 Mounting Handle Assembly Replacing the original handle of the older Type-C reel with this version allows the newer vCam-6 control module to mount atop the older Type-C reel. (control module and reel not included) Contact a local Vivax-Metrotech distributor or local office for ordering information, applications, compatibility and pricing.
  • Page 85 Troubleshooting 13. Troubleshooting PROBLEM: No power, unit will not turn on: CHECK: Check to see that the fuse is installed, blown or damaged in any way. If the fuse is not installed, then the unit will not charge your battery. Try using mains current and not battery to turn on the unit.
  • Page 86 Troubleshooting PROBLEM: Distance counter not accurate: CHECK: In the menu settings for reels check: Check if the distance counter setting is set to Meters or Feet. Check the type of reel used setting is correct. Check that the friction brake is not slowing down the cage so much that it jerks in and out. PROBLEM: Distance counter no counting: CHECK: Check the condition of the Interconnect Cable between the control module and reel.
  • Page 87 Troubleshooting PROBLEM: Error messages for USB and SD cards, not enough free space or not found. CHECK: Check that the USB devise is a minimum of 8GB in size and not bigger than 128GB in size. Check that the USB device was formatted in FAT32 or NTSC file format. ™...
  • Page 88 Notes: Disclaimer: Product and accessory specification and availability information is subject to change without prior notice. Vivax-Metrotech Corporation 3251 Olcott Street, Santa Clara, CA 95054, USA Toll Free: (800) 446-3392 Phone: +1 (408) 734-1400 Website: www.vivax-metrotech.com ™...
