vCamMX-2+ Playback, Camera Lights and
On-screen Keyboard Controls
1
2
3
1
4
5
1
Use the buttons corresponding to the
top, right, bottom, and left arrows to
Keyboard
1
navigate the on-screen keyboard.
Navigation
Then, navigate to and press the Done
or Step Back key to save the changes.
Use this button while recording or
Pause and
2 playing a video to pause and resume
Resume
the video.
Lower
Lower the camera lights while viewing
3 Camera
or recording.
Lights
Rewind
4 Rewind the video during playback.
Stop the recording or playing the video.
5 Stop
Enter Press while in File Manager to play a
6
Button selected video.
Raise
Raise the camera lights while viewing
7 Camera
or recording.
Lights
Fast
8 Fast forward the playing video.
Forward
Control Box Buttons
On/Off Button
Distance reset
6
7
1
8
Microphone
Sonde
Record
Zoom
Playback and
Camera lights
Press and release to turn the unit on.
When on, this button will glow green.
Press and hold to turn the unit off.
Press this button to reset the distance
counter to zero. A confirmation
message will appear on the screen.
Press to turn on and off. The button will
glow red, and an icon will appear in the
status bar. The internal microphone is
located at the top center above the
screen.
Press to turn on and off. When on the
button glows green and the frequency
shows in the status bar. The frequency
will change with each button press and
then turn off.
Press to start a recording. While
recording , the button glows red, and
the record icon flashes in the status
bar. Press again to end the recording.
Press to take a JPEG picture. A
message will appear on the screen to
confirm the picture capture.
Press to enter the digital zoom mode.
Press up to three times for levels of
zoom. The zoom level will show in the
status bar.
Use the Left/Right Arrow section to
increase or lower the camera lights.
Use the Pause/Resume button to
pause and resume a recording or
playing video.
Use these buttons to navigate the
on-screen keyboard, using the center
Enter button to select letters or
numbers.
LCD Keypad Buttons
Press to return to the previous screen
or exit an operation.
Step Back / ESC
Press to make a selection while in
various menus.
Karat choice
keys
Press when required to complete an
action. Also, press to hide and show
the main menu bar while viewing or
recording.
Enter
Make a Video Recording or JPEG Picture
Press to start a recording. While
recording, the button glows red, and the
record icon flashes in the status bar.
Press again to end the recording.
Press to take a JPEG picture. A
message will appear on the screen to
confirm the picture capture.
Main On-Screen Menu
Press to enter the File Manager to
manage video and picture files.
Files
Press to access the LCD settings.
Display
Press to change the colors and
position of the OSD.
OSD
Press to enter the camera lights
submenu.
Lights
Press to enter the settings sub menu.
Setup
