- Page 1 EmoTouch II AF for the installer Assemblyinstruction Made in Germany IPX4 Druck Nr. 29344221 en - 24.12...
-
Page 2: Table Of Contents
English Table of Contents Scope of Delivery ....................4 Optional connections: ..................4 Technical data ......................5 General Safety Regulations ..................6 Assembly ........................7 Power element ......................7 Connect the Control Line ..................7 Control element ......................9 Assembly ......................9 Laying the control line ..................9 Electrical connection .....................11 Connecting the sauna heater ................11 Connecting the sauna lamp ................12 Connecting a fan .....................12... - Page 3 Operation / basic settings ..................19 Connecting for the first time ..................19 Call up the installer/operator menu ...............21 Locking ......................22 Deactivate bench sensor .................22 Humidity sensor ....................23 Brightness of display ..................23 Link color light options with heater ..............23 The Help-Menu ....................24 The technology menu ...................25 Hysteresis .......................26 Fans ........................26...
-
Page 4: Scope Of Delivery
Scope of Delivery (subject to changes) 1. Power switchgear 2. Control unit with protective housing 3. Control line ca. 2 m 4. Circuit board for heater sensor with over-temperature protection, KTY-sensor and sensor housing, two mounting screws 3 x 25 mm and sensor cable ca. 2,0 m long, white and red. 5. -
Page 5: Technical Data
Technical data Nominal voltage: 400 V 3 N AC 50 cycles Switching capacity: max. 9 kW ohmic load (AC1-operation) Climate operation: 6 kW + 3 kW for evaporator unit, upgradable by connecting power switchgears Limitation of heating time: 6 hrs, 12 hrs or no limitation of heating time Display: Touch-display Type of protection:... -
Page 6: General Safety Regulations
General Safety Regulations • Caution! The unit may not be instal- led in closed cabinets or in an enclo- sed timber cladding! • The electrical installation may only be per- formed by an authorized electrician. • You must comply with the regulations of your utility company as well as the stan- dard VDE-guidelines (DIN VDE 0100). -
Page 7: Assembly
Assembly Power element The power switchgear may only be installed Connect the Control Line outside the cabin. It is advisable to select the outside wall of the cabin or the cabin ceiling for the installation. If ductwork is provided for the A 2 m long control line to connect power electrical installations then the position of the element and control unit are provided in the... - Page 8 Fasten the bottom section of the housing fi rmly to the cabin wall or cabin ceiling by inserting the screws into the bottom lower boreholes (Fig. 5). Wall or ceiling 19 cm Fig. 3 Fig. 4 Mounting holes Upper mounting hole Feed-through for: Feed- Mains supply...
-
Page 9: Control Element
Control element Laying the control line Assembly The control line may only be laid between The control element may only be mounted the insulation and the outside wall of the ca- outside the cabin. It is advisable to select the bin (Fig. - Page 10 If the plug has to be removed again then it must be unlocked as shown in Fig. 8a. Fig. 8a Finally, push the protective housing into the wall opening as shown in Fig. 9, then push the control element into the protective housing and fasten it to the cabin wall with the 4 supplied screws 4 x 20.
-
Page 11: Electrical Connection
Electrical connection Connecting the sauna he- ater The electrical connection may only be done by a certifi ed electrician in compli- ance with the guidelines of the local utility Install the sauna heater and the vaporizer company and the VDE. in front of the air intake according to the manufacturer’s installation instructions. -
Page 12: Connecting The Sauna Lamp
Connecting the sauna lamp Connecting the remote but- Only ohm resistive load, we recommend to use special bulbs Details can be found in the remote button like baking oven bulbs.Other bul- assembly instructions. bs, like energy-saving-lamps can destroy the control unit. Connecting a GSM module The sauna lamp must be weatherproof pro- tected (IPx4) and resistant to the ambient... -
Page 13: Installation Diagram
Installation diagram EmoLux = alternativ oder Emotec max. 3 kW oder 400 V 3 N AC 50 Hz Terminal arrangement on the circuit board. (Power unit) 500 mA T Jumper S1 FAN LIGHT WM Nr. 2 Nr. 1 TEMP.- Ub E G L1 L2 L3 W WB TEMP.-SENSOR... -
Page 14: Sensor Connection
Sensor connection 142°C Ub G E Nr. 2 Nr. 1 TEMP.- Ub E G TEMP.-SENSOR LIMITER H-SENSOR Connection of the vaporizer max. 100 W max. 100 W S1 FAN LIGHT WM L1 L2 L3 W WB 400 V 3 N AC 50 Hz 3 kW P max. -
Page 15: Connection Of Sauna Heaters ≤ 9 Kw
Connection of sauna heaters ≤ 9 kW max. 100 W max. 100 W S1 FAN LIGHT WM L1 L2 L3 W WB 400 V 3 N AC 50 Hz P max. 9 kW Connection of sauna heaters > 9 kW max. -
Page 16: Connecting The Sensor Lines
Connecting the sensor lines 2. Drill a hole to lead the cable through, pre- ferably through the middle of one of the ou should not install sensor and power sup- wooden boards. ply lines together, or lead them through the 3. -
Page 17: Installing The Optional Bench Sensor
Installing the optional bench sensor If there is a problem with the bench sensor, a fault message will appear: E 103 = Interruption bench sensor Installation location: The bench sensor is fi xed to the ceiling of the rear reclining bench as described for the installation of the heater E 104 = Short-circuit bench sensor sensor. -
Page 18: Connecting The Vaporizer
Connecting the vaporizer Fitting of the humidity sensor (optional) To connect the vaporizer, use silicon connecting lines 4 x 1,5 mm2 as well. The humidity sensor is fi tted in the centre of the sidewall facing away from the oven at a height of approximately Warning: When connecting the 150 cm. -
Page 19: Operation / Basic Settings
Connecting for the fi rst time Once the installation is completed, turn the power on. Depending on the length of storage of the unit the EOS-Logo appears briefl y and the unit switches to standby mode, or you are prompted by the display to make a few basic adjustments. - Page 20 Changing the setting of the type of sauna heater is a job for the installer. The EOS-logo briefl y appears and the unit switches to standby mode. The enclosed operating instructions (Print No. 29343840) show you how to operate the unit.
-
Page 21: Call Up The Installer/Operator Menu
Call up the installer / operator menu Touch the symbol on the bottom right-hand side for ca. 3 seconds; the unit changes to the installer menu. > 3 seconds 20 0 : 3 Call up the installer/operator menu In the operator menu you can activate/deactivate the components or set the values which should only be changed by instructed personnel (janitor, pool staff) in normal use of the sauna. -
Page 22: Locking
The following displays appear: 20 0 : 3 Locking Select by: • Select from the operator menu • Select help from the menu. All setting options can be blocked (e.g. for hotel or commercial operations) with this function. The user can only switch the lighting and sauna on and off. Unlocked Locked Deactivate bench sensor... -
Page 23: Humidity Sensor
Humidity sensor Select by: • Select from the operator menu • Select help from the menu. Humidity sensor deactivated Humidity sensor activated Brightness of display Select by: • Select from the operator menu • Select help from the menu. You may adjust the brightness of the display to the individual situation or desires. 30 - 100% Link color light options with heater Select by:... -
Page 24: The Help-Menu
The Help-Menu By touching the button in the “Operator Menu” display you will get to the Help Menu. All relevant and changeable parameters are shown and its functions described briefl y. Depending on the unit design, some para- meters may not be available and are there- First, select the desired language. -
Page 25: The Technology Menu
The technology menu In the technology menu you can activate/deactivate the components or set the values which should only be changed by a service technician in normal use of the sauna. Enter the code 2486 in order to enter the technology menu. 20 0 : 3 If correctly entered, an acoustic signal sounds. -
Page 26: Hysteresis
Hysteresis Select by: • Select from the technology menu • Select help from the menu. The switch hysteresis defi nes the temperature difference between disconnect at target-temperature and reconnect for reheating when cooled off in °C. Factory set to 5 °C. 1 - 10 Fans Select by:... -
Page 27: Switching From Finnish Heater To Climate Heater Or Vice-Versa
Switching from Finnish heater to climate heater or vice-versa Select by: • Select from the technology menu • Select help from the menu. During the fi rst general settings you chose the heater type used. If a different heater than the one selected was installed, the control is adjusted here. Finnish heater (heater without vaporizer) Climate heater (heater with vaporizer) Do not mix up this setting with the various adjustable operating modes when... -
Page 28: Reheating Time
Reheating Sauna time After turning off the humidity operation the Select by: heater operates to the “reheating tempera- • Select from the technology menu ture” for the duration of the “reheating time” • Select help from the menu. for the fi nal drying time. Reheating time Select by: The sauna time func-... - Page 29 Service interval time Remaining time until next service. If the number is negative, the number of hours exceeding the service time is displa- yed. 20 0 : 3 If the set service interval time is exceeded, the word "service" fl ashes in red on the dis- Service play for approximately 15 seconds when the unit is switched on.
-
Page 30: The Help-Menu
The Help-Menu By touching the button in the “Technology Menu” display you will get to the Help Menu. All relevant and changeable parameters are First, select the desired language. shown and its functions described briefl y. Depending on the unit design, some para- meters may not be available and are there- fore not shown. -
Page 31: Error Message
Error Message In order to show you an immediate diagnosis when a possible error occurs, the following errors may be defi ned on the display through the error code. Error code Error description Remedy E 100 Temperature sensor fault (no Check the lines or sensors signal) The respective sensor has approx. -
Page 32: Other Error Possibilities Without Display And Their Causes
Other error possibilities without display and their causes No display on the display - no background lighting Check the switch position on the unit switch. Check the mains connection! 230 V AC must be applied to all 3 phases L1, L2 and L3. Check the fuses! Cabinet light does not work: Check the miniature fuse on the plate... -
Page 33: The Switch-Off
The Switch-off Switch-off You will fi nd the unit switch on the top side of = unit is tur- the power control unit. You can disconnect ned on the electronics from the mains using this switch in case of a fault. In case of faults push the unit switch on the = unit is tur- left side of the rocker to the fi... -
Page 34: Service Address
Service Address: Outside of Germany please contact your EOS Saunatechnik GmbH specialist dealer in case of warranty claims. Adolf-Weiß-Straße 43 Direct warranty processing with our service 35759 Driedorf-Mademühlen, Germany department is in this case not possible. -
Page 35: Handling Procedures For Return Shipments (Rma) - Details For All Returns
Handling procedures for return shipments (RMA) - Details for all returns ! Dear customer we hope that you will rejoice in the ordered articles. Just in case that you are not entirely contented as an exeption, please follow the procedures specifi ed below.This enabling us to ensure a quick and smooth handling of the return shipment.
