- Page 1 PLEASE VISIT OUR WEBSITE AT: www.sunjoydirect.com OR TOLL FREE AT: 1-866-578-6569 MONDAY-FRIDAY 11:30 AM TO 8:30 PM PACIFIC STANDARD TIME MONDAY-FRIDAY 8:30 AM TO 4:30 PM EASTERN STANDARD TIME SUNJOY INDUSTRIES GROUP LIMITED 619 Slack Street Steubenville, Ohio 43952 USA...
- Page 2 ASSEMBLY INSTRUCTIONS ITEM# L-GZ806PAL-A SKU# 147079 10’ X 12’ BALI WICKER GAZEBO WARNING: 1. Assembly Instructions must be followed. 2. Gazebo must be secured / anchored when fully assembled. SAFETY INFORMATION: Please read and understand this entire manual before attempting to assemble or install the product.
- Page 3 CARE AND MAINTENANCE: 1. This item is intended for decorative and sunshade purposes only, and is not designed to withstand severe weather, including high winds, sustained tropical downpours, and snow. In order to avoid damage in such instances, remove any accumulated water and the roof immediately. Disassemble the item in the reverse order of the assembly steps if necessary prior to a severe storm.
- Page 4 Parts List Post Long Cross beam Short Cross beam Slanting bar Middle beam Knob Corner connector (big top frame) Big top frame bar (long side) Big top frame bar (short side) ...
- Page 5 Fig.1: Spread the crossbeam (B & C) to straight till fix by the elastic buckling. Fig.2: Insert the crossbeam (B & C) into card slot of the post (A), fix them by ...
- Page 6 Fig.5: Insert the big top frame bar (H & I) to the big top corner connector (G). Fig.6: Insert the slanting bar (D) to the big top corner connector (G). ...
- Page 7 Fig.11: Screw the center hook (L) to the middle of the small top beam (J). Fig.12: Attach the small canopy (P) to the small top along the small top slanting bar (K), aligning the corners and stretching it to fit.
- Page 8 Fig.14: Spread the large canopy (Q) along the slanting bar (D), aligning the corners and stretching it to fit, then stick inner valance together. Fig.15: Hang the wall (S) on the outside of mosquito netting bar (N & O) by plastic ring (GG), and hang the mosquito netting (R) on the inside of mosquito netting bar (N &...
