Sunjoy L-GZ375PST 8'x8' Marcel Gazebo
Owner's Manual
IMPORTANT
Thank you very much for choosing Sunjoy Group.
Please take time to read these instructions thoroughly and follow each step carefully for safe and easy
operation. Keep this manual for future reference.
We would like to hear from you with any comments or suggestions. You can call us toll-free at
1-866-578-6569
from 8:00 a.m. EST to 8:00 p.m. PST. You can also send the email to
amazon@sunjoygroup.com
or visit
www.sunjoyonline.com
to get tech. assistance or to place your
replacement part order form.
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L-GZ375PST and is the answer not in the manual?

Questions and answers

Related Manuals for Sunjoy L-GZ375PST

Summary of Contents for Sunjoy L-GZ375PST

  • Page 1 Sunjoy L-GZ375PST 8′x8′ Marcel Gazebo Owner’s Manual IMPORTANT Thank you very much for choosing Sunjoy Group. Please take time to read these instructions thoroughly and follow each step carefully for safe and easy operation. Keep this manual for future reference.
  • Page 2 Cautions: 1. Keep all children and pets away from assembly area. Children and pets should be supervised when they are in the area of gazebo construction. 2. The area for assembly should not be less than 6 feet from any obstruction such as fence, garage, house, overhanging branches, laundry line or electrical wires.
  • Page 3 Parts List Top connector Long angle beam 4PCS Short angle beam 4PCS Girder 4PCS Horizontal beam 1 4PCS Horizontal beam 2 4PCS Connector 4PCS Post 4PCS Post foot 4PCS Arc connector 4PCS Hook Small canopy Big canopy Mosquito netting Page 3...
  • Page 4 Step 1 Fig.4 Fig.5 Fig.6 Fig.3 Fig.1 Fig.2 Fig.1 Fig.2 Fig.3 DD EE Fig.6 Fig.4 Fig.5 Fig.1: Insert one side of horizontal beam 1(E) into horizontal beam 2 (F) (Fig.1) Repeat on all sides. Fig.2: Insert another side of horizontal beam 1(E) and horizontal beam 2 (F) into the hole of connector (G) (Fig.2).
  • Page 5 Step 2 Fig.7 Fig.9 Fig.10 Fig.8 Fig.8 Fig.9 AA DD Fig.10 Fig.7: Finish covering small canopy (L), install big canopy (Q) on the structure but do not fully cover (Fig.7). Fig.8: Attach post foot (I) and post (H) and tighten them by using bolt (AA), flat washer (DD). Repeat on all posts. Fig.9: Lift assembled roof (G) up, fix connector (G) and post (H) with bolt (AA), flat washer (DD).
  • Page 6 Step 3 Fig.13 Fig.11 Fig.12 Fig.14 Fig.12 Fig.14 Fig.11 E(F) (HH) Fig.11: Use mosquito netting hooks (HH) to hang mosquito netting (N) onto horizontal beam 1 (E) and horizontal beam 2 (F). (Fig.11) Fig.12: Make sure the Velcro tie of the mosquito netting (N) is properly attached to the pole (H) (Fig.12). Fig.13: Spread big canopy (M) over the entire structure, and slide into each corner (Fig.13).
  • Page 7 Care & Maintenance: Our steel components for garden accessories and furniture are treated with rust inhibiting paint that protects it from rusting. However, due to the nature of steel, surface oxidation (rusting) will occur once these protective coatings are scratched. This is not a defect and thus not covered by the warranty. To minimize this condition, we recommend care when assembling &...
