ASSEMBLY INSTRUCTIONS
ITEM# L-GZ798PST-E

IMPORTANT

Thank you very much for choosing Sunjoy Group.
Please take time to read these instructions thoroughly and follow each step carefully for safe and easy
operation. Keep this manual for future reference.
We would like to hear from you with any comments or suggestions. You can call us toll-free
at
1-866-578-6569
anytime 24 hours / 7 days a week. For further assistance , please write to us at
customer.care@sunjoygroup.com
Production Number: xxxxxxxxxx

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L-GZ798PST-E and is the answer not in the manual?

Questions and answers

Related Manuals for Sunjoy L-GZ798PST-E

Summary of Contents for Sunjoy L-GZ798PST-E

  • Page 1 ASSEMBLY INSTRUCTIONS ITEM# L-GZ798PST-E IMPORTANT Thank you very much for choosing Sunjoy Group. Please take time to read these instructions thoroughly and follow each step carefully for safe and easy operation. Keep this manual for future reference. We would like to hear from you with any comments or suggestions. You can call us toll-free 1-866-578-6569 anytime 24 hours / 7 days a week.
  • Page 2 SAFETY INFORMATION: Please read and understand this entire manual before attempting to assemble or install the product. When installing and assembling the item, it is recommended two or more adults are involved. This product is intended for outdoor use only and should be placed on flat, horizontal ground.
  • Page 3 Parts List Part NO. QTY CS NO. Image Description P11149B01106 Corner Panel P11064C01106 Long Cross Beam 1 P11065C01106 Long Cross Beam 2 P11066C01106 Short Cross Beam 1 P11067C01106 Short Cross Beam 2 P10308B01106 Oblique Beam P10480A01106 Long Middle Beam P10481A01106 Short Middle Beam P10482A01106 Bottom Long Middle Beam...
  • Page 4 CS NO. Part NO. QTY Image Description P00152B06011 Small Canopy P00332B01903 Mosquito netting P90804A07001 Knob Hardware Pack 1 Fig.1: Spread the Corner Panel (A) on the ground Fig.2: Insert Long & Short Cross Beam 2(C&E) into Long & Short Cross Beam 1(B&D), tighten with Knob (S).
  • Page 5 Hardware Pack 2 Fig.4: Insert the Oblique Beam (F) into Bottom Oblique Beam (J1&J2) Fig.5: Insert the Big Roof Connector (K) into another side of the Oblique Beam (F) Fig.6: Insert the assembled Bottom Oblique Beam (J1&J2) into the Corner Panel (A) Fig.7: Insert the Middle Beam （G1&G2 ）into the Bottom Middle Beam (H&I) Fig.8: Insert the Long Middle Beam (G1) and Short Middle Beam (G2) into the big Roof Connector (K), attached the Hook (L) on the big Roof Connector (K)
  • Page 6 Hardware Pack 3 CS NO. Part NO. Description Image 52 PCS Plastic Ring P90701B07007 Φ6X180MM“7”Stake 16 PCS P12406C01001 Fig.13: Spread Large Canopy (P) to the roof along the Bottom Oblique Beam (J1&J2), aligning the corners and stretching it to fit. Fig.14: Place Corner Shelves (O) onto Corner Panels (A) as desired.
  • Page 7 Care & Maintenance: Our steel components for garden accessories and furniture are treated with rust inhibiting paint that protects it from rusting. However, due to the nature of steel, surface oxidation (rusting) will occur once these protective coatings are scratched. This is not a defect and thus not covered by the warranty. To minimize this condition, we recommend care when assembling &...
