  • Page 1 » Kontron User's Guide « RTM806X Document Revision 1.0 April 2012 If it's embedded, it's Kontron.
  • Page 2 © 2011 Kontron, an International Corporation. All rights reserved. The information in this user's guide is provided for reference only. Kontron does not assume any liability arising out of the application or use of the information or products described herein. This user's guide may contain or reference information and products protected by copyrights or patents and does not convey any license under the patent rights of Kontron, nor the rights of others.
  • Page 3: Table Of Contents

    MMC Boot Block ............. . 9 RTM806X www.kontron.com...
  • Page 4 Glossary ............. . D-1 RTM806X www.kontron.com...
  • Page 5 Figure 2-1: Block Diagram ............. .7 RTM806X www.kontron.com...
  • Page 6 Table 2-6 Hot-Swap LED Description ........... . . 14 RTM806X www.kontron.com...
  • Page 7: Safety Instructions

    • Use extreme caution when installing or removing components. Refer to the installation instructions in this user's guide for precautions and procedures. If you have any questions, please contact Kontron Technical Support WARNING High voltages are present inside the chassis when the unit's power cord is plugged into an electrical outlet.
  • Page 8: Preventing Electrostatic Discharge

    Static electricity can harm system boards. Perform service at an ESD workstation and follow proper ESD procedure to reduce the risk of damage to components. Kontron strongly encourages you to follow proper ESD procedure, which can include wrist straps and smocks, when servicing equipment.
  • Page 9: Preface

    This user's guide is designed to be used as step-by-step instructions for installation, and as a reference for operation, troubleshooting, and upgrades. For the circuits, descriptions and tables indicated, Kontron assumes no responsibility as far as patents or other rights of third parties are concerned.
  • Page 10: Customer Comments

    Disclaimer: We have tried to identify all situations that may pose a warning or a caution condition in this user's guide. However, Kontron does not claim to have covered all situations that might require the use of a Caution or a Warning.
  • Page 11: Unpacking

    Unpacking Follow these recommendations while unpacking: •Remove all items from the box. If any items listed on the purchase order are missing, notify Kontron customer service immediately. •Inspect the product for damage. If there is damage, notify Kontron customer service immediately.
  • Page 12: Regulatory Compliance Statements

    Testing and reports when required are performed under the international IECEE CB Scheme. Please consult the "Kontron Safety Conformity Policy Guide" for more information. For Canada and USA input voltage must not exceed -60Vdc for safety compliance.
  • Page 13: Limited Warranty

    In the event of repair, refunding or replacement of any part, the ownership of the removed or replaced parts reverts to Kontron, and the remaining part of the original guarantee, or any new guarantee to cover the repaired or replaced items, will be transferred to cover the new or repaired items.
  • Page 14 Chapter 2 Board Features 1.1 Product Overview ..........2 1.2 What’s Included ..........2 1.3 Board Specifications .......... 2 1.4 Compliance ............3 1.5 Hot-Swap Capability .......... 4 1.6 Interfacing with the Environment ......4 www.kontron.com...
  • Page 15: Product Description

    Management Controller self test which can detect a failure in its code integrity and trigger an automatic rollback. • Hardware system monitor(sensors, alarm, events) through IPMI (voltages, temperatures), Supervisory power failure. Mechanical • 350.93 X 176.8 X 28.95 mm • 10W Typical without hard drive. Power Requirements • 65W Maximum with hard drives. RTM806X www.kontron.com...
  • Page 16: Compliance

    Board might not be 100% compliant to ATCA PICMG 3.0 Specification REQ 4.94 when a hard drive is present on the RTMHDD. The HDD might connect the Logic Ground and the Shelf Ground. By default the Logic Ground and the Shelf Ground are connected through a removable screw. RTM806X www.kontron.com...
  • Page 17: Hot-Swap Capability

    • FRU Data EEPROM size is 4Kbyte and it includes board identification and serial number. 1.6.1.4 Hot Swap As a Hot Swappable Intelligent Managed FRU, the RTM806X (FRU2) includes a Management Controller, the AdvancedTCA Hot Swap indicator (Blue LED), and the standard AdvancedTCA handle switch. RTM806X www.kontron.com...
  • Page 18 The BLUE LED is 100% off when a FRU is operational and unsafe for extraction. An always on(100%) indicates that a FRU can safely be extracted; transitional states are identified through blinking patterns. Additional details on the standard FRU Hot Swap sensor and the BLUE LED usage can be found in the AdvancedTCA specifications. RTM806X www.kontron.com...
  • Page 19 2.1 Block Diagram ..........7 2.2 USB 2.0 Interface ..........8 2.3 SAS ..............8 2.4 HD Hot-Swap Option .......... 9 2.5 SFP..............9 2.6 MMC Boot Block ..........9 2.7 Hardware Management Overview ......9 2.8 Face Plate Indicators.......... 14 www.kontron.com...
  • Page 20: Board Features

    2. Board Features Block Diagram Figure 2-1:Block Diagram RTM806X www.kontron.com...
  • Page 21: Usb 2.0 Interface

    The SAS connections are only offered through the RTM. The controller is located on the front board and sends the four signals from the PCH to the RTM through the RTM connectors. The SAS signals are accessible through: • Two HDD mounted on RTM806X • Two external links through the mini-SAS connector RTM806X www.kontron.com...
  • Page 22: Hd Hot-Swap Option

    HD Hot-Swap Option Kontron offers the possibility to add two Hot-Swap SAS hard drives on the RTM806X. Those hard drives are located on the lower part of the RTM806X. The Hotswap infrastructure includes a Hot-Swap LED, Hot-Swap handle, hard disk presence status and a thermal sensor. All of which are connected to the MMC. They are managed by the IPMC and presented as a regular managed FRU to management subsystem.
  • Page 23: Hardware Sensors

    SFP2 Status SFP2 Presence/Fault status USB1 OC USB1 Over Current Status USB2 OC USB2 Over Current Status Disk1 Bay Removable Disk 1 Bay Slot/Connector Status Disk2 Bay Removable Disk 2 Bay Slot/Connector Status Power State Board Power State RTM806X www.kontron.com...
  • Page 24: Field Replaceable Unit (Fru) Information

    Board Area Length *Calculated Language code 0x00 Manufacturing Date / Time *Based on mfg. date Board Manufacturer type/length *Calculated Board Manufacturer “Kontron” Board Product Name type/length *Calculated Board Product Name “RTM806X” Board Serial Number type/length *Calculated Board Serial Number Manufacturer S/N...
  • Page 25: Table 2-4 Product Information Area

    Field Description Value (hex) Format Version 0x01 Product Area Length *Calculated Language Code 0x00 Manufacturer Name type/length *Calculated Manufacturer Name “Kontron” Product Name type/length *Calculated Product Name “RTM806X” Product Part/Model Number type/length *Calculated Product Part/Model Number "T5707_XX"* Product Version type/length *Calculated Product Version “XX”...
  • Page 26: Mmc Firmware Code

    RTM HDD when it is safe to remove the RTM from the front board or the hard disk from the RTM. The on-board MMC drives this LED to indicate the hot-swap state. The following states are possible: RTM806X www.kontron.com...
  • Page 27: Face Plate Indicators

    The AdvancedTCA LED1 is red or amber and indicates an Out-of-Service (OOS) condition. During normal operation, the OOS LED is OFF. This LED is ON during firmware upgrade and is user configurable if needed by a customer application. RTM806X www.kontron.com...
  • Page 28: Healthy Led (Led2)

    RTM HDD 1 and 2 Hot Swap LED The Blue / Hot Swap LED indicates the hot swap status of the RTMDISK. The LED is ON when it is safe to remove the RTMDISK from the RTM. During normal operation, this LED is OFF. RTM806X www.kontron.com...
  • Page 29 Chapter 3 Board Features 3.1 RTM Hot Swap and Installation......17 3.2 RTM HDD Hot Swap and Installation ...... 18 www.kontron.com...
  • Page 30: Hot Swap And Installation

    3- Wait until the blue LED is fully ON, this mean that the hot swap sequence is ready for RTM removal. 4- Use the ejector to disengage the RTM from the CPU board. 5- Pull the RTM out of the chassis. RTM806X www.kontron.com...
  • Page 31: Rtm Hdd Hot Swap And Installation

    1- Make sure the RTM is secured in place, i.e. both thumbscrews are screwed into the chassis. 2- Pull out the handle to unlock the RTMHDD 3- Wait for the blue LED to turn solid on (100% on). 4- Pull out the RTMHDD using the handle. RTM806X www.kontron.com...
  • Page 32: Connector Pinouts

    A. Connector Pinouts Connectors and Headers Summary Connector Description SERIAL PORT Connector DUAL USB Connector J4-J5 SFP+ Connectors MINI-SAS Connector SAS HDD 1 SAS HDD 2 RTM Connector RTM Connector RTM806X www.kontron.com...
  • Page 33: Advancedtca I/O Rtm Connector (J30

    PE4_TX- PE4_TX+ PE5_RX+ PE5_RX- PE7_TX+ PE7_TX- ROW G ROW H ROW AB ROW CD ROW EF ROW GH FPGA_IO_1 RTM_EN# USB0_D+ USB0_D- JTAG_TRST FPGA_IO_2 RTML_CLK PROG RSVD_G5 JTAG_SEL SFP0_SCL SFP0_SDA SAS_1_RX+ SAS_1_RX- GBE_RX2+ GBE_RX2- PE6_RX- PE6_RX+ PE4_RX- PE4_RX+ RTM806X www.kontron.com...
  • Page 34: Serial Port(J1

    Serial Port(J1) Signal SFP+ Channel (J4 & J5) Signal Signal VeeT VeeR TX_Fault TX_Disable VeeR VccR MOD-ABS VccT Rate Select 0 VeeT RX_LOS Rate Select 1 VeeR VeeT RTM806X www.kontron.com...
  • Page 35: Dual Usb Port (J7

    Dual USB Port (J7) Signal DATA- DATA+ Hot Swap Hard Disk Module(J7 & J8) Signal Signal 3.3V_SUS_HD PortA_TX+ 3.3V PortA_TX- 3.3V_PRE SMB_SCL PortA_RX- HD_PRESENT# PortA_RX+ 5V_PRE PortB_TX+ PortB_TX- V_PUMP_R SMB_SDA PortB_RX- PortB_RX+ 12V_PRE RTM806X www.kontron.com...
  • Page 36: Software Update

    B. Software Update MMC Firmware Update Procedure To update the software of your board, it is recommended to use the update CD, please contact you local technical support department for the proper procedure to follow. RTM806X www.kontron.com...
  • Page 37: Getting Help

    Tel.: +49 (0) 8341 803 333 Fax: (450) 437-8053 Fax: +49 (0) 8341 803 339 If you have any questions about Kontron, our products, or services, visit our Web site at: www.kontron.com You also can contact us by E-mail at: North America: support@ca.kontron.com...
  • Page 38: When Returning A Unit

    • Clearly write or mark the RMA number on the outside of the package you are returning. • Ship prepaid. We take care of insuring incoming units. North America EMEA Kontron Canada, Inc. Kontron Modular Computers GmbH 4555, Ambroise-Lafortune Sudetenstrasse 7 Boisbriand, Québec 87600 Kaufbeuren...
  • Page 39: Glossary

    Intelligent Platform Management Bus Local IPMC Intelligent Platform Management Controller IPMI Intelligent Platform Management Interface IPMIFWU Intelligent Platform Management Interface FirmWare Update Light-Emitting Diode Module Management Controller. MMCs are linked to the IPMC. Not Connected Out Of Service RTM806X www.kontron.com...
  • Page 40 Random Access Memory RS-232 (Same as RS232). Recommended Standard 232. RS232 (Same as RS-232). Recommended Standard 232. Rear Transition Module Request To Send Serial Attached SCSI Small Form-factor Pluggable ShMC Shelf Management Controller Transmit Transmit Universal Serial Bus Power supply RTM806X www.kontron.com...
