5.5.9 DCS 416R ANALOG I/O-MODULE
The module is meant for insertion on the rear of the DCS 400 base unit providing connection facilities for analog
control lines and potentiometers, with their levels are used for controlling volume controls or other continuous
parameters. Additionally, the control outputs provide analog voltages for controlling external devices that are
equipped with analog inputs.
• 8 analog inputs.
• Voltages of 0 to 10V or a potentiometer to each input.
• Plug-in binding post for reference voltage 10V.
• 8 analog outputs 0...10V DC.
• Plug-in screw-flange binding posts for all inputs and outputs.
• Maximally 2 DCS 416R / DCS 416 modules can be cascaded.
Always equip slots 1-10 of a DCS 400 base unit in ascending order (from the left to the right) leaving no empty
slots in-between.
Combining modules of different type is possible.
Exception: Slot 1 (the slot all the way on the left) always needs to be equipped with a DCS 401R control module
or a DCS 405R extension module.
Mounting the module and establishing the connections are solely admissible when performed in accordance to
VDE 0100 and EN 60065 regulations.
Specifications
:
Operating voltage
Operating current (max.)
Operating temperature range
Dimensions (W x H x D)
Weight
Inputs:
Voltage range (min. .. max.)
Impedance range ext. (min. .. max.)
Maximum input voltage
Output level:
Voltage range (min. .. max.)
Output impedance
Maximum load
Reference voltage source:
Output voltage
Maximum output current
Resolution Input and
Output signals
5-84
Installation Notes
24V DC, - 10 / +30%
160 mA
+5° C .. +40°C
37.5 x 80.6 x 245 mm
170 g
0 V .. 10 V DC
0...10 Kohm
50 V DC
0 V..10 V DC
47 Ohm
2 kOhm
10 V DC
30 mA
8 Bit
