DEVICE DESCRIPTIONS
5.5.3 DCS 405R EXTENSION MODULE
The module needs to be inserted on the rear of the DCS 400 base unit. It is meant to provide connection to
another base unit and / or other DCS 400 boards.
In the DCS 400 base unit – the first unit installed – the DCS 405R extension module always needs to be installed
in the first empty slot (the slot right of any other modules installed).
In the DCS 400 extension unit – the second unit installed – the DCS 405R extension module always needs to be
installed in slot 1 (the slot all the way on the left).
Mounting the module and establishing the connections are solely admissible when performed in accordance to
VDE 0100 and EN 60065 regulations.
Specifications
:
Operating temperature range
Dimensions (W x H x D)
Weight
5-72
Installation Notes
+5° C .. +40° C
37.5 x 80.6 x 245 mm
115 g
