5.2.9 Priorities
The PROMATRIX system allows setting 10 priority levels (highest priority = 10, lowest priority = 1) that include
announcements, as well as alarm and gong signals, and vocal message reproduction. A higher prioritized event
principally interrupts any other event with a lower priority setting. For events with equal priority the earlier
launched signal is continued; has priority over the latter.
Priority level
10
7 - 9
6 - 7
(manual / time-controlled)
2 - 8
2 - 6 Message from a paging
console without / with pre-
1
5.2.10 DPC 4350 Paging Station Extension
The DPC 4350 paging station extension provides selection keys only. It is employed whenever a higher amount
than 50 lines need to be accessed or when an installation's requirement of group and special function keys
exceeds the existing amount of selection keys. The DPC 4350 can be easily combined with any other paging
station model. The following list shows the amounts of maximally accessible lines for various combinations:
Combination
DPC 4106 + DPC 4350
DPC 4510 + DPC 4350
DPC 4520 + DPC 4350
DPC 4530 + DPC 4350
DPC 4550 + DPC 4350
The extension unit is directly connected to the extension interface of the main paging station using the supplied 8-
pole RJ-45 cable and plugging it into the EXT-socket. A single paging station then consists of two devices that
report to a common address. Therefore the central unit recognizes them as one single microphone terminal with
an increased amount of selection keys. Also from the viewpoint of the user the two devices act as only one paging
station; i.e. the selection keys of the main and the slave paging station provide equal access to their assigned
areas, groups and special functions.
Note: During the configuration of the system using the PROMATRIX Designer software, it is important
that the main paging station's EXT-socket is configured for the connection of a DPC 4350
extension.
The extension unit can only be operated together with DPC 45.. or DPC 40.. Series paging console
models!
PROMATRIX System User Handbook 1.1
Assigned
Directing station
Alarm signal
Gong signal
Recorded message
gong signal
Program
Description
Highest priority; can ignite any type of events and interrupt
all other signals.
Can only be interrupted from the directing station; but
interrupts all other signals that have not been launched from
the directing terminal.
Interrupts all signals that are not coming from the directing
terminal. Time-controlled gong signals can be delayed/pre-
delayed by a pre-defined period of time.
These priorities can be freely assigned to text messages
during the configuration procedure.
These priorities can be freely assigned to any 'normal'
paging console. A pre-gong signal has the priority of the
launching microphone terminal.
Background music always has the lowest priority level.
Maximum amount of lines
50
60
70
80
100
