Dynacord PROMATRIX System Reference Manual page 121

6. Appendix
6.1 PROMATRIX Hardware Configuration
6.1.1 DCS 400
When configuring and initially operating the DCS 400 system, please proceed as follows:
1. Cabling
è Use the supplied flat-wire cable for connecting the relay modules DCS 408, DCS 409 in the desired order to
the control module DCS 401. Mixed installation of relay modules is possible; numbering the relays is type-
specific and has to be performed according to their sequence.
example:
Sequence
1
2
3
4
5
6
...
è Use the supplied flat-wire cable for connecting the logic input module DCS 412 to the control module DCS
401. Numbering the logic inputs has to be performed according to their sequence.
example:
Sequence
1
2
3
...
è Use the supplied flat-wire cable for connecting the analog input / output modules DCS 416 to the control
module DCS 401. Numbering the analog inputs and outputs has to be performed according to their sequence.
example:
Sequence
1
2
è Connect the control module DCS 401 via RJ-45 cable to the REMOTE CONTROL socket on the DPM 4000.
PROMATRIX System User Handbook 1.1
Module Line relay No.
DCS 408 1 - 5
DCS 408 6 - 10
DCS 409
DCS 408 11 - 15
DCS 409
DCS 408 16 - 20
... ...
Module
DCS 412
DCS 412
DCS 412
...
Module Analog input No.
DCS 416 1 - 8
DCS 416 9 - 16
Control relay No.
1 - 5
6 - 10
...
Logic input No.
1 - 12
13 - 24
25 - 36
...
Analog output No.
1 - 8
9 - 16
