APPENDIX
6.3 NRS 90226 Adapter Printed Board Assembly
Adapter printed board assembly for connecting RJ45 lines and single conductors to be used with
paging consoles, I/O-lines (slot 5), remote lines (DCS), and monitoring.
characteristics: 2 x RJ-45 sockets, 8-pole binding post.
6-4
PROMATRIX System User Handbook 1.1
