OPERATION INSTRUCTIONS
2.2.2 DPA 4000 Power Amplifier
Especially designed for it, the DPA 4000 Series power amplifiers optimally match the PROMATRIX system. Thus
guaranteeing trouble-free installation and operation.
The power amplifiers are "stand alone" devices, offering the opportunity for them to be operated together with
several other pieces of equipment, as long as all valid specifications and applicable instructions for the installation
are being observed.
2.2.3 DPC 4000 Paging Stations
Especially designed for it, the DPC 4000 Series paging stations optimally match the PROMATRIX system. Thus
guaranteeing trouble-free installation and operation.
The paging stations cannot be used as "stand alone" devices. At least a DPM 4000, a 24 V power supply plus all
necessary cabling is needed to build-up a minimal installation.
Configuration and operation is accomplished through the DPM 4000 central unit.
2.2.4 DCS 400 Control System
The DCS 400 control system – consisting of a DCS 401 control module, a DCS 408 relay module 100V, a DCS
409 control-relay module, DCS 412 logic input module and DCS 416 analog I/O module – cannot be used as a
"stand alone" system. At least a DPM 4000, a 24 V power supply plus all necessary cabling is needed to build-up
a minimal installation.
According to their technical specifications, it is possible to incorporate the modules of the DCS 400 system as
follows:
-
DCS 401:
-
DCS 408:
-
DCS 409:
-
DCS 412:
-
DCS 416:
-
DCS 420:
Configuration and operation is accomplished through the DPM 4000 central unit.
2.2.5 DPP 4000 Power Supply Units
Especially designed for it, the DPP 4000 Series power supply units optimally match the PROMATRIX system,
guaranteeing trouble-free installation and operation.
The power supplies are "stand alone" units, which offers the possibility to utilize them to feed other equipment
with 24 V supply voltage, as long as all valid specifications and applicable instructions for the installation are
being observed.
2-4
control module for all other DCS 400 modules
query of 2 rotary encoders
5 floating switches for 100 V loudspeaker lines
5 floating switches for control signals (DC voltages, 24 V)
or for audio signals at line level
query and monitoring of 12 floating control voltages
(logic signals up to ±31 V)
8 analog inputs for the query of control voltages (0 – 10 V)
8 analog outputs to output control voltages (0 – 10 V)
Monitor Manager with loudspeaker, headphones socket,
7-segment display, and metering instrument
PROMATRIX System User Handbook 1.1
