DEVICE DESCRIPTIONS
5.3 DPA 4000 PROMATRIX Power Amplifier
5.3.1 Characteristics
The PROMATRIX system includes four DPA 4000 Series power amplifiers, offering common features as listed
:
below
• 4 models:
• floating 100 V power outputs (internally configurable to 70 V / 50 V or 4 Ω)
• outputs are protected against idling and short-circuit
• mains operation at 115 / 230 V AC and 24 V DC (emergency power supply)
• mains and battery remote on/off
• electronically balanced inputs, transformers are optionally available
• input level controls
• monitor outputs
• temperature-controlled operation
• pilot tone and ground fault surveillance (optionally available)
• fault indication and fault messaging via floating READY-contact
• remote control module for DPA 4120 / DPA 4140 (optionally available)
Note: Detailed description of individual characteristics, features, functions, and specifications of these
power amps are provided in the corresponding owner's manual supplied with the appliance.
5-50
DPA 4410 4 x 100 W
DPA 4411 4 x 100 W Remote Control
DPA 4120 1 x 200 W
DPA 4140 1 x 400 W
