3.3.4

LED Indicators

Status\LED ACT( L1~L4)
LAN Linked Bright
100Mbps
1000Mbps
HDD Active
Power on
3.3.5

DC Power Input connector

The DC power input connector is M12 A-code Male 5Pin connector
Pin Signal
1
2
3 System GND
4 System GND
5 Chassis GND
3.3.6

M12 LAN Connector (LAN1~ LAN4)

The M12-8pin LAN Connector is A-Code type which can support 10/100/1000Mbps
Pin 10/100 Mbps
1 --
2 --
3 --
4 TX -
5 RX +
6 TX +
7 --
8 RX -
NOTE: The M12-8pin type LAN connector pin define may difference with other
Jumper Setting & Connector
LINK(L1~L4)
Blue LED
Yellow LED
VCC
VCC
1000 Mbps
MDI 2+
MDI 3+
MDI 3-
MDI 0-
MDI 1+
MDI 0+
MDI 2 -
MDI 1 -
tBOX321-870-FL Series User's Manual
HDD POWER
Flash
Bright
2
3 4
5
M12-A Code 8Pin/ Female
1
device.
