AXIOMTEK tBOX322-882-FL Quick Installation Manual

Step 3 Slide CFast card into slot cautiously
Step 4 Fasten screws of HDD/CFast bracket
Installing the HDMI bracket
Step 1 Fasten the bracket at the position as shown.
Step 2 Connect HDMI cable and tied on bracket by cable tie as
shown.
4 9416N322000E
©
Copyright 2014 Axiomtek Co., Ltd.
Version A1 Oct 2014
Printed in Taiwan
tBOX322-882-FL Quick Installation Guide
Checklist
 tBOX322-882-FL System Unit x 1
 Quick Installation Guide x 1
 Screws Pack x 1
 Wallmount Bracket x 1
 HDMI bracket x1
 Optional Mini Card Module
 Optional M12 power cable
 Optional remote switch cable
Note: Please contact your local vendors if any damaged or missing items. DO
NOT apply power to the board if there is any damaged component.
Dimensions
9416N322000E
©
Copyright 2014 Axiomtek Co., Ltd.
Version A1 Oct 2014
Printed in Taiwan
 CD x 1 (for Driver & Manual)
 Foot Pad x4
 DIO & Serial connector
 Key x2
 Cable tie x2
 Optional HDD/SSD
 Optional CFast Card
 Optional M12 LAN cable(s)
