AXIOMTEK tBOX400-510-FL Quick Installation Manual

Hide thumbs Also See for tBOX400-510-FL:

Step 5

Install the DDR module with caution and put the

thermal pad on the DDR module again. Then screw

the DDR cover to finish the installation.

9416N400000E

Version A1 January 2019

Printed in Taiwan

tBOX400-510-FL Quick Installation Guide

Packing List

System Unit x 1

Quick Installation Guide x 1

DCD x 1 (for Drivers)

Foot Pad x 4

Screw Pack x 1

Note: Please contact your local distributor if any of the above-mentioned

items is missing or damaged. DO NOT apply power to the board if any

component is damaged.

9416N400000E

Version A1 January 2019

Printed in Taiwan

HDD Mylar x 4

SATA Drive Key x 2

DRAM Thermal Pad x 4

Wall Mount Bracket x 2
