Dreamline DUET Installation Instructions Manual

Tub door and shower backwalls kit
Hide thumbs

Advertisement

Quick Links

Download this manual
QWALL-TUB Kit
Duet Tub Door &
B
K
I
Tub Door
S
IT
AND
NSTALLATION
HOWER
ACKWALLS
I
NSTRUCTIONS
IMPORTANT
DreamLine
reserves the right to alter, modify or redesign products at any time
TM
without prior notice. For the latest up-to-date technical drawings, manuals or any
other details please refer to the
support.BathAuthority.com
web page.
STEP 1: Install Shower Backwalls
Shower Backwalls Installation Instructions
STEP 2: Install Shower Door
Shower Door Installation Instructions
Please read these instructions carefully before installing. If you have any questions regarding
installation, please call our technical support specialists Monday through Friday 9:00 AM – 5:00
1-866-731-2244,
1-866-227-1533
PM EST at Phone:
Fax:
or e-mail our technical support
support@BathAuthority.com.
group at
DreamLine Shower Kit
www.BathAuthority.com
For more information on
please visit

Advertisement

loading
Need help?

Need help?

Do you have a question about the DUET and is the answer not in the manual?

Questions and answers

Related Manuals for Dreamline DUET

Summary of Contents for Dreamline DUET

  • Page 1 QWALL-TUB Kit Duet Tub Door & Tub Door NSTALLATION HOWER ACKWALLS NSTRUCTIONS IMPORTANT DreamLine reserves the right to alter, modify or redesign products at any time without prior notice. For the latest up-to-date technical drawings, manuals or any other details please refer to the support.BathAuthority.com...
  • Page 2 DUET HOWER NSTALLATION NSTRUCTIONS IMPORTANT DreamLine reserves the right to alter, modify or redesign products at any time without prior notice. For the latest up-to-date technical drawings, manuals or any other details please refer to the support.bathauthority.com web page. Please carefully read the instructions before installing. If you have any questions regarding installation, please call our technical support specialists Monday through Friday 9:00 AM –...

  • Page 3: Tools Required

    2. Please note that you should consult your local building codes with questions on installation compliance standards. Building and plumbing codes may vary by location, and DreamLine is not responsible for code compliance standards for your project. 3. Please insure that prior to the installation the installation surface is leveled and solid and will be able to support the total weight of the unit.
  • Page 4 Before discarding the carton, check for small hardware bags that tend to fall to the bottom of the box. If any parts are damaged or missing, please contact DreamLine for replacement.
  • Page 5 Shower Door Installation 1. Measure the distance between two walls. This distance is marked as “W”. See Fig. 1 for details. 2. The Upper guide rail (01) and the Bottom guide rail (04) has been precut for the installation between the walls with a distance a) 48”...
  • Page 6 3. Secure Upper guide rail (01) and Bottom guide rail (04) to the Glass profiles (03) with the Flat head screws ST4.2x25 (09). See Fig. 3 and Fig. 4 for details. Rev 1.1...
  • Page 7 Push the Wall profiles (02) all the way over the Glass profiles (03) at both sides. Make sure the flange of the wall profile faces inside the shower. See Fig. 5 and Fig. 6 for details. Rev 1.1...
  • Page 8 Move finished frame designated position and push it against the walls. If your top and bottom wall opening measurements are different or if walls out-of-plumb, make adjustment by slightly pulling the Wall profiles out of the Glass Profiles. Use the level to adjust the frame in the vertical position.
  • Page 9 Apply silicone along the wall profile and around the holes on the wall. Also apply silicone under the bottom guide rail. Place the shower frame back in to the designated position and secure it to the walls using Round head screws ST4.2×30 (09). See Fig.
  • Page 10 PLEASE NOTE: • On the outside Glass door (A) the Handle and the Rollers should face out. • On the inside Glass door (B) the Handle and the Rollers should face inside. See Fig. 11 and Fig. 12 for details. .
  • Page 11 One by one suspend both Glass doors onto the Upper guide rail as shown on Fig.13. Tilt the Glass door (A) a little to make the glass slide into the channel of guide rail. Suspend the Glass door (B) to the guide rail the same way. See Fig.
  • Page 12 10. Slide both Glass Doors to the right. Insert the Left guide block (13) into the channel on the left side of the Guide rail and secure it using the Round head screw ST4.2 × 16 (08). Cover the screw head with Decorative cover (10). See fig.
  • Page 13 12. Fasten the Rubber stopper (14) inside the groove of the Wall profile using the Round head screw ST4.2×16 (08). See Fig. 17 for details. . 17 13. Do the final adjustments of the assembled unit in the Wall profiles. Ø...
  • Page 14 14. Apply the sealant along the profiles and guide rails; on the seams between the bottom guide rail and the profiles as well as along the shower base or threshold. See Fig. 19 for details. caulk . 19 Product Maintenance To insure long lasting life for your acrylic back walls, wipe them off after each use with a soft cloth.
  • Page 15 QWALL TUB CRYLIC NSTALLATION NSTRUCTIONS IMPORTANT DreamLine reserves the right to alter, modify or redesign products at any time without prior notice. For the latest up-to-date technical drawings, manuals or any other details please refer to the support.BathAuthority.com web page.
  • Page 16 2. Please note that you should consult your local building codes with questions on installation compliance standards. Building and plumbing codes may vary by location, and DreamLine is not responsible for code compliance standards for your project. 3. This acrylic wall system is specially designed to be installed over any solid surface. If you are installing the acrylic walls over the existing tiles, remove all loose tiles before the installation.
  • Page 17 Before discarding the carton, check for small hardware bags that tend to fall to the bottom of the box. If any parts are damaged or missing, please contact DreamLine for replacement.
  • Page 18 Back Panel Installation Instruction 1. Measure the distance of the back wall of the tub (corner to corner) The distance is “W” See Fig. 1 for details. 2. Divide the W measurement by 2 (W/2). Place a mark on the back wall and draw a vertical line from top to bottom.
  • Page 19 3. Measure the side walls from the corner to the front point where the Side panel (01) is going to end. This distance is “D”. See Fig. 3 for details. D - 1” 1” 4. Verify on which side of your tub wall the fixtures will be installed.
  • Page 20 Attach the Center cover (05) vertically at the center point along the line and mark the Ø5/16” drilling holes through predrilled holes on the Center cover. Drill the holes using Ø5/16” drill bit and insert the Wall Anchors (06). See Fig. 6 and Fig. 7 for details. Rev 1.1...
  • Page 21 6. Attach the Corner cover (04) to the corner of the wall and mark drilling holes through the predrilled holes on the Corner cover. Drill the holes using Ø5/16” drill bit and insert the Wall Ø5/16” Anchors (06). See Fig. 8 and Fig. 9 for details Rev 1.1...
  • Page 22 7. Determine the position of both Back panels (02). W/2-1” NOTE: a) Narrow side of the Back panel W/2-1” cannot be trimmed and should face the center of the Back wall. b) Wide side of the Back panel can be trimmed to the size of the wall and should face the corner.
  • Page 23 8. Place the Back panel (02) on a flat piece of plywood or a particle board. Cut the side end of the Back panel by making a few deep scratches with a sharp industrial knife using a T-Square tool or a handheld jig saw.
  • Page 24 9. Mount the Center cover (05) to the center of the back wall using Countersunk screws ST4.2×30 (07). Do not tighten the screws. Leave the Center cover loose on the wall. See Fig. 13 for details. . 13 10. Apply the sealant to the back of the left Back panel (02).
  • Page 25 11. Slide the right edge of the left Back panel (02) all the way behind the Center cover (05) and push the Back panel against the wall. You can adjust the position of the Back panel before the sealant sets. Apply equal pressure to the whole surface of the Back panel from top to bottom.
  • Page 26 13. Align both Back panels at the top and tighten the screws on the Center cover (05) to secure this assembly in place. See Fig. 17 and Fig. 18 for details. . 17 . 18 Rev 1.1...
  • Page 27 14. Determine the position of both Side panels (01). D -1” D -1” NOTE: a) Narrow side of the Side panel cannot be trimmed and should face the corner of the side wall. b) Wide side of the Side panel can be trimmed size your...
  • Page 28 D -1” D -1” . 21 16. Place the marks on the Side panel (01) which is going to the side wall with the fixtures according to the taken measurements in Fig. 4. Drill the holes in the Side panel. Mind using the proper diameter saw bit or a handheld jig saw.
  • Page 29 . 23 17. Apply the sealant to the back surface of the Side panel (01). Apply the sealant around the drilled holes and to the whole back side of the Side panel. See Fig. 24 for details. . 24 Rev 1.1...
  • Page 30 18. Slide the edge of the Side panel (01) behind the Corner cover (04) and push the Side panel against the wall. Align the top of the Side panel with the Back panel before sealant sets. Apply equal pressure to the whole surface of the Side panel from top to bottom.
  • Page 31 19. Apply the sealant to the back surface of the Side panel (01) for another side wall installation. See Fig. 27 for details. . 27 20. Repeat Step 18 to install the second Side panel. See Fig. 28 and Fig. 29 for details.
  • Page 32 . 29 21. Fasten tight the Corner covers (04) and the Center cover (05) to secure the Side panels (01) and the Back panels (02) in place. See Fig. 28 for details. . 28 Rev 1.1...
  • Page 33 22. Use decorative plugs to cover the screw holes in the Corner covers (04) and the Center cover (05). See Fig. 29 for details. . 29 23. Apply caulk along the top edge of panels along connection of the bottom edges of the panels with the tub.
  • Page 34 Tub Glass Shelves Installation Instruction 24. Find the desirable height for the Glass shelves (09) and mark the locations on the wall. NOTE: The Glass shelves can be installed either two in one corner, or one in each. See Fig. 31 for details. .
  • Page 35 10. Mount the Glass brackets (10) to the wall using the Countersunk screws ST4.2×30. NOTE: padded set screw of the Glass bracket should be facing down. Slide the upper Glass shelf (09) into the Glass brackets and tighten the set screws at the bottom of the brackets. Then slide the bottom Glass shelf in place.

  • Page 36: Product Maintenance

    Product maintenance To insure long lasting life for your acrylic back walls, wipe them off after each use with a soft cloth. To clean the acrylic back walls use non-abrasive sprays or cream based cleaners. Never use abrasive cleansers, metal brushes or scrapers that could scratch or dull the surface. Acrylic cleaning procedure: Acrylic should be cleaned with warm water and a clean, nonabrasive cloth.
  • Page 37 ™  EXCLUSIVE LIMITED WARRANTY AS OF MAY 6, 2013   DREAMLINE This warranty extends only to the original owner/end‐user for household use only and is not transferable to a subsequent owner. This warranty extends for a designated period of time, so  long  as  it  remains  in  use  in  its  original  place  of  installation.  This  warranty  applies  only  to  DreamLine  products  purchased  from  an  authorized  dealer  in  United  States  or  Canada.  Proof  of  purchase (original sales receipt) from the original consumer purchase must be provided with all warranty claims.  IN NO EVENT SHALL THE LIABILITY OF DREAMLINE EXCEED THE PURCHASE PRICE OF THE UNIT.  DreamLine products must be installed by a fully insured and licensed professional. Installation of DreamLine product by anyone other than fully insured licensed professionals shall VOID THE  WARRANTY. DreamLine recommends that such licensed professionals have experience in the installation of bathroom products. Installation of certain products, including, without limitation, ...
  • Page 38 TEL: 866-731-8378 – 215-957-1411 FAX: 866-227-9245 – 215-893-1780 WWW. UTHORITY.COM For more information on DreamLine Tub Back Wall please visit www.BathAuthority.com Rev 1.1...
