Dreamline Visions Installation Instructions Manual

Tub door and shower backwalls kit
Hide thumbs

Advertisement

Quick Links

Download this manual
QWALL-TUB Kit
Visions Tub Door &
B
K
I
Tub Door
S
IT
AND
NSTALLATION
HOWER
ACKWALLS
I
NSTRUCTIONS
IMPORTANT
DreamLine
reserves the right to alter, modify or redesign products at any time
TM
without prior notice. For the latest up-to-date technical drawings, manuals or any
other details please refer to the
support.BathAuthority.com
web page.
STEP 1: Install Shower Backwalls
Shower Backwalls Installation Instructions
STEP 2: Install Shower Door
Shower Door Installation Instructions
Please read these instructions carefully before installing. If you have any questions regarding
installation, please call our technical support specialists Monday through Friday 9:00 AM – 5:00
1-866-731-2244,
1-866-227-1533
PM EST at Phone:
Fax:
or e-mail our technical support
support@BathAuthority.com.
group at
DreamLine Shower Kit
www.BathAuthority.com
For more information on
please visit

Advertisement

loading
Need help?

Need help?

Do you have a question about the Visions and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dreamline Visions

Summary of Contents for Dreamline Visions

  • Page 1 QWALL-TUB Kit Visions Tub Door & Tub Door NSTALLATION HOWER ACKWALLS NSTRUCTIONS IMPORTANT DreamLine reserves the right to alter, modify or redesign products at any time without prior notice. For the latest up-to-date technical drawings, manuals or any other details please refer to the support.BathAuthority.com...
  • Page 2 & T HOWER NSTALLATION NSTRUCTIONS IMPORTANT DreamLine reserves the right to alter, modify or redesign products at any time without prior notice. For the latest up-to-date technical drawings, manuals or any other details please refer to the support.BathAuthority.com web page.

  • Page 3: Tools Required

    DreamLine will not replace any damaged products or missing parts free of charge after 3 business days or if the product has been installed. Feel free to contact DreamLine if you have any questions. 2. Please note that you should consult your local building codes with questions on installation compliance standards.
  • Page 4 Before discarding the carton, check for small hardware bags that tend to fall to the bottom of the box. If any parts are damaged or missing, please contact DreamLine for replacement.
  • Page 5 Shower Door Installation 1. Measure the distance between two walls. This distance is marked as “W”. See Fig. 1 for details. 2. Your Guide rails (03) have been precut for the installation between the walls with a distance of: 60” If W=60”, then it is unnecessary to cut the Guide rails and you can continue to Step 3.
  • Page 6 3. If the Guide rails (03) have been cut, you will need to reinstall the roller stoppers on each Guide rail on both 2” sides where it has been cut. Remove existing stopper. Mark the drilling hole with a distance of 2” from the cut off edge of the Guide rail. Drill the new hole using Ø...
  • Page 7 4. Fasten the bottom Guide rail (03) to the Glass profiles (01) with the Round head screws ST4.2x25 (11). See Fig. 5 for details. 5. Slide the Stationary glasses (05) fully into the groove of the Glass profiles (01), and then fasten it by the Glass holders (16) to the bottom Guide rail (03).
  • Page 8 6. Slightly tap the Single side strips (09) in between the Stationary glasses (05) and the Glass profiles (01) using wooden shim or other piece of wood. The strips should be inserted from the sides that will face inside the shower. ATTENTION: Do not use the screwdriver or other metal objects;...
  • Page 9 9. Move the finished frame to the designated position on the shower base, the bathtub or the threshold (depending on your installation); push it against the walls. If your top and bottom wall opening measurements are different or if the walls are out-of-plumb, make adjustment by slightly pulling the Wall profiles (02) out of the Glass Profiles (01).
  • Page 10 NOTE: Glass Door (04) comes with preinstalled Wheel assemblies (17). If not, please refer to (Fig. 11) for detailed installation. 12. Fasten the top and the bottom Wheel assemblies (17) to the Glass door (04). The top wheels can adjust the door level with the adjustable bolt and lock nut.
  • Page 11 14. Install the Handles (06) to the Glass doors (04). Press the anti-water strips (08) on the vertical edges of the Stationary glasses (05) and both vertical edges of the Glass doors. Press the Magnetic strips (07) on the vertical edges of both Glass doors for tight closing.
  • Page 12 16. Apply the sealant along the profiles and guide rails; on the seams between the bottom guide rail and the profiles as well as along the shower base or threshold. See Fig. 15 for details. Caulk . 15 Product Maintenance To insure long lasting life for your acrylic back walls, wipe them off after each use with a soft cloth.
  • Page 13 QWALL TUB CRYLIC NSTALLATION NSTRUCTIONS IMPORTANT DreamLine reserves the right to alter, modify or redesign products at any time without prior notice. For the latest up-to-date technical drawings, manuals or any other details please refer to the support.BathAuthority.com web page.
  • Page 14 2. Please note that you should consult your local building codes with questions on installation compliance standards. Building and plumbing codes may vary by location, and DreamLine is not responsible for code compliance standards for your project. 3. This acrylic wall system is specially designed to be installed over any solid surface. If you are installing the acrylic walls over the existing tiles, remove all loose tiles before the installation.

  • Page 15: Packing List

    Before discarding the carton, check for small hardware bags that tend to fall to the bottom of the box. If any parts are damaged or missing, please contact DreamLine for replacement.
  • Page 16 Back Panel Installation Instruction 1. Measure the distance of the back wall of the tub (corner to corner) The distance is “W” See Fig. 1 for details. 2. Divide the W measurement by 2 (W/2). Place a mark on the back wall and draw a vertical line from top to bottom.
  • Page 17 3. Measure the side walls from the corner to the front point where the Side panel (01) is going to end. This distance is “D”. See Fig. 3 for details. D - 1” 1” 4. Verify on which side of your tub wall the fixtures will be installed.
  • Page 18 Attach the Center cover (05) vertically at the center point along the line and mark the Ø5/16” drilling holes through predrilled holes on the Center cover. Drill the holes using Ø5/16” drill bit and insert the Wall Anchors (06). See Fig. 6 and Fig. 7 for details. Rev 1.1...
  • Page 19 6. Attach the Corner cover (04) to the corner of the wall and mark drilling holes through the predrilled holes on the Corner cover. Drill the holes using Ø5/16” drill bit and insert the Wall Ø5/16” Anchors (06). See Fig. 8 and Fig. 9 for details Rev 1.1...
  • Page 20 7. Determine the position of both Back panels (02). W/2-1” NOTE: a) Narrow side of the Back panel W/2-1” cannot be trimmed and should face the center of the Back wall. b) Wide side of the Back panel can be trimmed to the size of the wall and should face the corner.
  • Page 21 8. Place the Back panel (02) on a flat piece of plywood or a particle board. Cut the side end of the Back panel by making a few deep scratches with a sharp industrial knife using a T-Square tool or a handheld jig saw.
  • Page 22 9. Mount the Center cover (05) to the center of the back wall using Countersunk screws ST4.2×30 (07). Do not tighten the screws. Leave the Center cover loose on the wall. See Fig. 13 for details. . 13 10. Apply the sealant to the back of the left Back panel (02).
  • Page 23 11. Slide the right edge of the left Back panel (02) all the way behind the Center cover (05) and push the Back panel against the wall. You can adjust the position of the Back panel before the sealant sets. Apply equal pressure to the whole surface of the Back panel from top to bottom.
  • Page 24 13. Align both Back panels at the top and tighten the screws on the Center cover (05) to secure this assembly in place. See Fig. 17 and Fig. 18 for details. . 17 . 18 Rev 1.1...
  • Page 25 14. Determine the position of both Side panels (01). D -1” D -1” NOTE: a) Narrow side of the Side panel cannot be trimmed and should face the corner of the side wall. b) Wide side of the Side panel can be trimmed size your...
  • Page 26 D -1” D -1” . 21 16. Place the marks on the Side panel (01) which is going to the side wall with the fixtures according to the taken measurements in Fig. 4. Drill the holes in the Side panel. Mind using the proper diameter saw bit or a handheld jig saw.
  • Page 27 . 23 17. Apply the sealant to the back surface of the Side panel (01). Apply the sealant around the drilled holes and to the whole back side of the Side panel. See Fig. 24 for details. . 24 Rev 1.1...
  • Page 28 18. Slide the edge of the Side panel (01) behind the Corner cover (04) and push the Side panel against the wall. Align the top of the Side panel with the Back panel before sealant sets. Apply equal pressure to the whole surface of the Side panel from top to bottom.
  • Page 29 19. Apply the sealant to the back surface of the Side panel (01) for another side wall installation. See Fig. 27 for details. . 27 20. Repeat Step 18 to install the second Side panel. See Fig. 28 and Fig. 29 for details.
  • Page 30 . 29 21. Fasten tight the Corner covers (04) and the Center cover (05) to secure the Side panels (01) and the Back panels (02) in place. See Fig. 28 for details. . 28 Rev 1.1...
  • Page 31 22. Use decorative plugs to cover the screw holes in the Corner covers (04) and the Center cover (05). See Fig. 29 for details. . 29 23. Apply caulk along the top edge of panels along connection of the bottom edges of the panels with the tub.
  • Page 32 Tub Glass Shelves Installation Instruction 24. Find the desirable height for the Glass shelves (09) and mark the locations on the wall. NOTE: The Glass shelves can be installed either two in one corner, or one in each. See Fig. 31 for details. .
  • Page 33 10. Mount the Glass brackets (10) to the wall using the Countersunk screws ST4.2×30. NOTE: padded set screw of the Glass bracket should be facing down. Slide the upper Glass shelf (09) into the Glass brackets and tighten the set screws at the bottom of the brackets. Then slide the bottom Glass shelf in place.

  • Page 34: Product Maintenance

    Product maintenance To insure long lasting life for your acrylic back walls, wipe them off after each use with a soft cloth. To clean the acrylic back walls use non-abrasive sprays or cream based cleaners. Never use abrasive cleansers, metal brushes or scrapers that could scratch or dull the surface. Acrylic cleaning procedure: Acrylic should be cleaned with warm water and a clean, nonabrasive cloth.
