Replacing Parts - Angelo Po 0G0FA0 Use And Installation Manual

To carry out this operation,
proceed as follows.
1 - Turn off the gas supply
tap.
2 - Pull off the knobs (A).
3 - Undo the screws (B) and
remove the control panel
(C).
4 - Undo the screws (D) and
extract the cap (E).
5 - Pull off the cone (F).
6 - Clean the cone (F) and its
seat.
7 - Coat the cone with grease
(F), fit it in its seat and turn it a few times.
8 - Pull off the cone (F) to remove the excess grease.
Before carrying out any replacement proce-
dure, activate all the safety devices provided and de-
cide whether staff at work and those in the vicinity
should be informed. In particular, turn off the gas sup-
ply tap and prevent access to all devices which might
cause unexpected health and safety hazards if turned
on.
IT
If work parts have to be replaced, use original spare
AUS
DE
To carry out this operation, proceed as follows.
FR
1 - Turn off the gas supply
tap.
ES
2 - Remove the grid (A).
3 - Extract the burner (B).
4 - Unscrew the nozzle (C)
and replace it with the one
suitable for the type of gas
in use (see table at back of
manual).
5 - Replace the burner and
the grid.
GREASING THE GAS TAP

REPLACING PARTS

RECOMMENDATIONS FOR REPLACING PARTS
REPLACING THE TOP BURNER NOZZLE
B
C
A
9 - Replace the cone (F), the cap (E), the control pan-
el (C) and the knobs (A).
parts only.
The manufacturer declines all responsibly for injury or
damage to components due to the use of non original
parts, or extraordinary work on the appliance which
may modify the safety requirements without the man-
ufacturer's authorisation.
When ordering components, follow the instructions
provided in the parts catalogue.
B
A
- 14 -
E F
D
IDM-39603612400.tif
9
8
C
IDM-39603612500.tif
