Page 1
This document courtesy of: Data Weighing Systems, Inc. Contact Us For immediate assistance call 1-800-750-6842...
Page 2
I n d u s t r c h n o l o i n g T e W e i g h Economy Series EB Models Electronic Precision Scales for Use in Hazardous Areas/Locations Operating Instructions...
Contents Intended Use ..........3 Warning and Safety Information ......4 Getting Started ..........7 Control Drawing ........12 Operating Design ......... 14 Installing the Column ........19 Operating the Scale Basic Weighing Function ........ 25 Calibration/Adjustment ........28 Application Programs Counting ..........
– Excellent readability under any series have capacities ranging from lighting conditions 0.1 g to 150 kg. – Rugged, durable weighing system Economy Series scales save work and – IP-protection of the equipment speed up simple and complex routine housing: applications through: Weighing platform: IP54 –...
264 V. in installations and under ambient The explosion-protected equipment of conditions requiring higher safety the Economy Series meets the currently standards, you must comply with the valid, harmonized European standards provisions specified in the applicable in compliance with CENELEC: regulations for installation in your country.
Page 6
! Make sure that the voltage rating compatibility. printed on the AC adapter or power supply is identical to your ! Economy Series equipment may local AC power rating. Keep in only be operated in an ambient mind that there may be fluctuations temperature between 0°C and...
Page 7
! Clean the equipment in If you have any trouble with accordance with the instructions your scale: (see the section entitled ”Care and $ contact your local Sartorius office, Maintenance“). dealer or service center ! Have the equipment inspected at appropriate intervals for correct...
Getting Started Warranty Do not miss out on the benefits of our full warranty. Please contact your local Sartorius office or dealer for further information. If available, complete the warranty registration card, indicating the date of installation, and return the card to your Sartorius office or dealer.
Page 9
– Dust cover for display and control unit – Operating instructions Installation Instructions The Sartorius Economy scales are designed to provide reliable weighing results under normal ambient conditions. When choosing a location to set up your scale, observe the following so that you will be able to work with added speed and accuracy: –...
Page 10
(for example, as a result of damage to the scale, during transport or otherwise), disconnect the equipment from power and contact a Sartorius service technician. ! Use only original Sartorius AC adapters or power supplies: – YPS03-X.. (for use within a hazardous area/location) –...
Page 11
! YPS03-X... Flameproof AC Adapter (Power Supply): – Install both cables so that they are stationary – Flexible cables with threaded fasteners are available on request To operate the scale in a Zone 1 hazardous area or a Class I, Division 1 hazardous (classified) location, please comply with the following: –...
Page 12
Grounding (Earthing) Using an Equipotential Bonding Conductor § Connect the scale using a grounding cable (equipotential bonding conductor not part of the equipment supplied) to the main grounding terminal. In addition, the metal housing of the AC adapter (power supply) is grounded by the protective grounding conductor of the power cable.
Operating Design The Economy Series weighing instruments from Sartorius consist of a weighing platform and a display and control unit. In addition to the AC adapter, these weighing instruments also have an interface port for connecting a printer, computer, universal remote control switch, or other device.
Page 16
Display The display is divided into 5 sections: Busy symbol Busy-Zeichen Hinweise f r Plus/minus sign Application Vorzeichen Anwendungs- Stability symbol Parameter Stillstand programme Unit Einheiten- Me§wert pfeile indicator Basis-Einheiten + Measured value Basic unit + Zusatzkennungen additional information Busy Symbol, Plus/Minus Sign, Stability Symbol Symbols displayed here: –...
Page 17
Unit Indicator You can choose from several adhesive labels supplied to indicate the units selected in the operating menu; affix the corresponding label on the right, next to the display, and the arrows on the display will then point to the appropriate unit. Input In the scale operating menu, you can select operating parameters from lists.
Page 18
Output The scale is equipped with a data interface port, which you can use to connect – a printer, – a computer/PC, or – a universal remote control switch through a Zener barrier. Printer You can configure the print functions to meet your individual requirements by selecting the corresponding menu codes.
Page 19
Error Codes Error codes are displayed for 2 seconds in one of two formats: – Processing error: “E” and 2 digits – Hardware malfunction: “E” and 3 digits See the chapter entitled “Error Codes” for a detailed description of error codes.
Installing the Column EB..DCE-IX, EB..EDE-IX Models: Gently turn the scale over so that the pan support is on the bottom; place it on a soft surface. Sever the two cable retainers that hold the display cable Remove the strain relief clamp Remove the fastening screws from the display and control unit, and remove this unit.
Page 21
Gently turn the scale right side up. Use the Phillips screw supplied (4x20 mm) to attach the column to the flange on the base plate. Attach one of the two cap-shaped lock washers supplied to the bolt provided. Insert the fastener located on the rear panel of the display and control unit into the upper end of the column.
Page 22
Fasten the cable with the 3 cable retainers on the back of the column. Loop the surplus cable length and bind it with the cable ties provided. Replace the strain-relief clamp on the bottom of the scale. Note: Make sure that the cable does not come into contact with the pan support or the load plate.
Page 23
EB...FEG-IX: Gently turn the scale over so that the pan support is on the bottom; place it on a soft surface. Use an appropriate tool, such as a pair of side nippers, to sever the cable retainers. Detach the display and control unit from the base-mounted display flange.
Page 24
Use a 7-mm open-end wrench to fasten the 4 hexagonal nuts that attach the column retainer to the base plate of the scale. Gently turn the scale right side up. Use the Phillips screw supplied (4x20 mm) to attach the column to the retainer. The two raised metal buttons on the column retainer prevent the column from turning while you tighten the screw.
Page 25
Cap the free end of the bolt with the second lock washer. Fasten the cable with the 3 cable retainers on the back of the column. Loop the surplus cable length and fasten it under the base plate and the column with the cable ties provided.
Operating the Scale Basic Weighing Function Purpose The basic weighing function is always accessible and can be used alone or in combination with an application program (toggling between weight units, counting, weighing in percent, etc.). Available Features – Zeroing the scale Ambient influences may cause the scale readout to display a value other than zero even though the scale is unloaded.
Page 27
Preparation Turn on the scale: Press e > The scale runs a self-test $ To change menu code settings, see the chapter entitled “Configuring the Scale.” $ To load factory settings, see the chapter entitled “Configuring the Scale,” under parameter 9 - 1 >...
Page 28
6. Print values* EISENMUELLER GOETTINGEN 0.125 kg 0.015 kg 0.140 kg * The Sartorius Service Center or your Sartorius dealer can configure the scale to include 2 customer-specific lines on the printout. Software is available for setting this configuration with a PC.
Calibration/Adjustment Purpose Calibration is the determination of the difference between the weight readout and the true weight (mass) of a sample. Calibration does not entail making any changes within the scale. Adjustment is the correction of this difference between the measured value displayed and the true weight (mass) of the sample, or the reduction of the difference to an allowable level within the maximum...
Page 30
Example Calibrate the scale Configuration: Factory settings Step Key (or instruction) Display/Output 1. Turn on the scale 0.000 2. Zero the scale, if necessary 0.000 + 5.000 3. Begin calibration Calibration weight is dis- > 2 seconds played without weight unit 4.
Application Programs Counting Purpose With this application program you can determine the quantity of a number of parts that each have approximately equal weight. Available Features – Reference sample quantity can be changed either in the operating menu or during weighing –...
Page 32
Select the “Counting” menu item: Press the ) p p keys, ) repeatedly if needed, until Counting is displayed 2 1 4 Confirm selection: Press and hold the p key > o indicates the selected item To select counting parameters: Press p Select and confirm: –...
Page 33
Example Determine a piece count; save active weight value as a reference sample quantity Configuration (changes in the factory settings required for this example): Menu path: Application > Counting (2 1 4) Step Key (or instruction) Display/Output 1. Turn on the scale 2.
Toggle between Weight Units Purpose With this application program you can toggle the display of a weight value back and forth between two weight units. Available Features – Toggling the displayed weight – Other features as for the basic weighing function Factory Settings Weight unit 1: kg (1 7 3) Weight unit 2: kg (3 1 3)
Page 35
Select and confirm: – Weight unit 1: See next page (1 7 x) – Resolution 1: Standard 1 8 1 Increased resolution 1 8 3 – Weight unit 2: See next page (3 1 x) – Resolution 2: Standard 3 2 1 Increased resolution 3 2 3 See also the “Scale Operating Menu (Overview)”...
Page 36
You can choose from several adhesive labels supplied to indicate the units selected in the operating menu; affix the corresponding label on the right, next to the display, and the arrows on the display will then point to the appropriate unit. Menu item Unit Conversion factor...
Page 37
Example Toggle the display from kilograms [kg] (1st unit) to Troy ounces [ozt] (2nd unit) Configuration (changes in the factory settings required for this example): Menu path: Application > Toggle between weight units (2 1 2) Menu path: Weight unit 2 > Troy ounce (3 1 7) Step Key (or instruction) Display/Output 1.
Second Tare Memory Purpose With this application program you can save the active weight value as a tare compensation weight. Available Features – Save the active weight value as a tare compensation weight by pressing v – NET is displayed next to the weight readout if the scale has been tared or if there is a tare value in the second tare memory (on the printout: N indicates that the scale was tared by pressing...
Page 39
Select the “Second tare memory” application in the menu: Press the ) p p keys, ) repeatedly if needed, until Second tare memory or 2 1 3 2 1 10 Second tare memory with auto-taring is displayed Confirm selection: Press and hold the p key >...
Page 40
Example Fill containers to approximately identical weights (± 30 %) Configuration (changes in the factory settings required for this example): Menu path: Application > Second tare memory with auto-taring (2 1 10) Menu path: Weight unit 2 > Grams (3 1 2) Step Key (or instruction) Display/Output 1.
Weighing in Percent Purpose With this application program you can obtain weight readouts in percent which are in proportion to a reference weight. Available Features – Reference percentage can be changed either in the operating menu or during weighing – Save the active weight value to have it loaded as the preset reference percentage next time you initialize this application –...
Page 42
Select the “Weighing in percent” menu item: Press the ) p p keys, ) repeatedly if needed, until Weighing in percent without auto-tare or 2 1 5 2 1 11 Weighing in percent with auto-tare is displayed Confirm selection: Press and hold the p key >...
Page 43
Example Determine an unknown percentage; save active weight value as a reference percentage Configuration (changes in the factory settings required for this example): Menu path: Application > Weighing in percent (2 1 5) Menu path: Reference percentage > 100 % (3 3 5) Step Key (or instruction) Display/Output 1.
Calculation by a Factor Purpose With this application program you can multiply the weights of samples by a defined factor. Available Features – Calculate a weight value using one of the following factors: 0.25; 0.50. 0.75; 1.0; 1.5; 2.0; 2.5; 3.0; 3.5; 4.0; 4.5; 5.0 –...
Page 45
Select the “Calculation by a factor” menu item: Press the ) p p keys, ) repeatedly if needed, until Calculation by a factor is displayed 2 1 7 Confirm selection: Press and hold the p key > indicates the selected item To select calculation parameters: Press p Select and confirm:...
Page 46
Example You have a formula requiring several different components for a total amount of 1,000 g. You want to use this recipe to make a 500-g batch (factor: 0.5). The scale shows the amounts called for in the formula, although only half the amounts (in this case) are placed on the scale.
Totalizing Purpose This application program acts as a cumulative memory function. Available Features – The active weight value is saved as a net value when the scale stabilizes – A value indicated as negative (–) on the display is saved as a positive (+) value in the totalizing memory –...
Page 48
Preparation Select the “Totalizing” application in the operating menu: $ Turn off the scale: Press e Turn on the scale: Press e; while all segments are lit, press the ) key briefly Select the “Totalizing” menu item: Press the ) p p keys, ) repeatedly if needed, until Totalizing is displayed 2 1 8...
Page 49
Example Total weight values Configuration (changes in the factory settings required for this example): Menu path: Application > Totalizing (2 1 8) Step Key (or instruction) Display/Output 1. Turn on the scale 2. Zero the scale, if necessary 0.000 + 0.380 3.
Gross/Net Toggling Purpose With this application program you can toggle between net and gross values. Available Features – Toggle the display between gross and net weights when there is data in the tare memory – Press w to toggle between weight unit 1 and weight unit 2 Factory Settings Weight unit 1: kg (1 7 3)
Page 51
To select gross/net toggling parameters: Press p Select and confirm: – Weight unit 1: (see also “Toggle between Weight Units”) 1 7 2 Grams 1 7 22 lb / oz – Weight unit 2: (see also “Toggle between Weight Units”) 3 1 2 Grams 3 1 22 lb / oz –...
Averaging Purpose Use this program to determine the weights of unstable samples (e.g., live animals) or to determine weights under unstable ambient conditions. In this program, the scale calculates the weight as the average value from a defined number of individual weighing operations.
Page 53
Factory Settings Resolution: Standard (3 2 1) Number of subweighs for averaging: 10 (3 3 2) Preparation Select the “Averaging” application in the operating menu: $ Turn off the scale: Press e Turn on the scale: Press e; while all segments are lit, press the ) key briefly Select the “Averaging”...
Page 54
Additional Functions In addition to the functions for: – Turning off the scale (e key) – Zeroing the scale (( key) – Tare the scale () key) – Printing (p key) you can also access the following functions from this application: –...
Page 55
Example Determine the weight of a sample in extremely unstable ambient conditions from the average result of 5 subweighing operations. Enter the number of subweighs while in the weighing mode Configuration (changes in the factory settings required for this example): Menu path: Application >...
Data Output Functions There are 3 options for data output: – Output to the display and control unit – Output to a printer – Output to a peripheral device (e.g., computer) via the interface port Output to the Display and Control Unit Busy symbol The display is divided into 5 sections.
Page 57
Measured Value Line This section shows: – Current weight (digits bordered with a broken line are invalid in use for legal metrology) – Calculated values (e.g., piece counts) – Application parameters during configuration (e.g., reference sample quantity, etc.) – Software version (r = release; in this example: 19 = scale program;...
Page 58
The printout can be configured to include 2 user- defined header lines of 14 characters each. These text lines are entered either at the Sartorius factory or on location with a special program that uses the BPI interface command sequence.
Page 59
GOETTINGEN defined header lines. The software required for configuring these lines via your PC is available from Sartorius in Goettingen or your local Sartorius office or dealer. Printout without Data ID Codes: The value currently Weight in grams 1530.0 g...
Page 60
Printout with Data ID Codes: The current value Current net weight 1.530 kg displayed can be printed Current net weight 1.530 kg with a data ID code Value in tare memory 0.234 kg of up to 6 characters Value in 2nd tare memory 0.102 kg at the beginning of the Current gross weight...
Interface Port Purpose Your Economy scale comes equipped with an interface port for connection to a computer or other peripheral device. You can use an on-line computer to change, start and/or monitor the functions of the scale and the application programs. Available Features Type of interface: Serial interface Operating mode: Full duplex...
Page 62
Factory Settings: Transmission rate: 1200 baud (5 1 4) Parity: Odd (5 2 3) Stop bits: 1 stop bit (5 3 1) Handshake: Hardware, 1 character after CTS (5 4 3) Operating mode: Standard SBI (5 5 1) Print manually/automatically: Manual after stability (6 1 2) Preparation See the “Pin Assignment Chart”...
Page 63
Output Format With 16 Characters Display segments that are not activated are output as spaces. Characters without a decimal point are output without a decimal point. The following characters can be output, depending on the characters displayed on the scale: Normal Operation Position 1 9 10 11 12 13 14 15 16...
Page 64
Example: Data output example + 1255.7 g Position 1 9 10 11 12 13 14 15 16 * CR LF Position 1: Plus or minus sign or space Position 2: Space Position 3–10: Weight with a decimal point; leading zeros = space Position 11: Space Position 12–14: Unit symbol or space...
Page 65
Output Format with 22 Characters When data with an ID code is output, the ID code consisting of 6 characters precedes the data with the 16-character format. These 6 characters identify the following value. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 + * D D D D D D D D * U U U CR LF * * * * * –...
Page 66
ID code characters I Meaning Status Stat Gross G/B Gross – calculated value Tare T Tare T1 Net N Net N1 Counting: quantity Weighing in percent: percentage Calculation, averaging: result Totalizing: net total Automatic printout: reference sample quantity wRef Automatic printout: reference sample percentage Wxx%...
Page 67
Data Input Format You can connect a computer to your scale to send commands via the scale interface port to control scale functions and applications. The commands sent are control commands and may have different formats. Control commands consist of up to 4 characters. Each character must be transmitted according to the settings configured in the operating menu for data transmission.
Page 68
If you do not plug a peripheral device into the scale interface port, this will not generate an error message. Handshake The scale interface (Sartorius Scale Interface = SBI) has transmit and receive buffers. You can define the handshake parameter in the Setup menu: – Hardware handshake (CTS/DTR) –...
Page 69
Software Handshake The software handshake is controlled via XON and XOFF. When a device is switched on, XON must be transmitted to enable any connected device to communicate. Activating Data Output You can define the data output parameter so that output is activated either when a print command is received or automatically and synchronous with the scale display or at defined intervals (see application...
Connecting Cables RS-232 cables purchased from other manufacturers often have incorrect pin assignments for use with Sartorius scales. Be sure to check the pin assignment against the chart below before connecting the cable, and disconnect any lines marked “Internally Connected” (e.g., pin 6). Failure to do so may damage or even completely ruin your scale and/or peripheral device.
Page 71
Pin Assignment Chart: Scale: Zener barrier YDI02-Z: 14-pin 12 pin RS-232 signal (SBI) round barrier connector Data output (TxD) Data input (RxD) Data terminal ready (DTR) Signal GND Clear to send (CTS) – Universal remote control key – SBI/BPI – Reset out Connect low-ohmic shielding to the connector case.
Cabling Diagram (adapter cable: 12-contact round – 25-pin D-Sub; order no YCC01-0016M3) Female interface connector: 25-contact D-Submini DB25S with screw-lock hardware The pins are numbered as shown here: Connector – front view Male connector used (please use connectors with the same specifications): 25-pin D-Submini DB25 with integrated shielded cable clamp assembly (Amp 826 985-1C) and fastening screws (Amp type 164868-1)
Page 73
Pin Assignment Chart: Pin 1: Shield Pin 2: Data output (TxD) Pin 3: Data input (RxD) Pin 4: Not connected Pin 5: Clear to send (CTS) Pin 6: Internally connected Pin 7: Internal ground (GND) Pin 8: Internal ground (GND) Pin 9: Not connected Pin 10: Not connected Pin 11: +12 V...
Page 74
Wiring Diagram (for connecting a PC) YCC01-03ISM5 adapter cable <– > round DB25-PC for connecting a PC to the scale via a Zener barrier using the RS-232-C/ V24 protocol. Wiring diagram: Pin assignments for the cable from the Zener barrier to an RS-232 PC interface. 12-pin round connector 25-pin D-Sub female connector Shield...
Page 75
Ex-area Protected area 25 pin 9 pin Important: ! Only electrical equipment with a maximum voltage rating U of no more than 250 V is permitted to be connected to the Zener barrier. The voltage rating U of this Zener barrier is 12 V.
Page 76
Example Hazardous area/location Protected area AC adapter or AC adapter YPS03-X 609308-..1 ib (max. 20 m) Power cable Power cable T Connector Zener barrier YTE02-X YDI02-Z Precision scale Foot switch Printer EB6DCE-IX YPE05-X YDP03-0CE...
Configuring the Scale Setting Parameters in the Scale Operating Menu Purpose You can configure your Economy scale to meet individual requirements by selecting from the parameters available in the scale operating menu. Available Features The parameters are divided into the following groups (1st menu level): 1 Weighing parameters 2 Application programs...
Page 78
Factory Settings The factory-set parameters are marked by an “o” in the list starting on page 68. Preparation Turn off the scale: Press e Turn on the scale: Press e; while all segments are displayed, press ) briefly > Measured value line: 1 (1st menu level) $ To go to another item at the same level: Press the ) key briefly;...
Page 79
Example Adapt the scale to “very unstable ambient conditions:” Menu code 1 1 4 Step Display 1. Turn the scale off 2. Turn the scale back on; while all segments are displayed ) briefly 3. Confirm menu item at the (1st menu level: weighing parameters) p 4.
Scale Operating Menu (Overview) ο Factory setting √ User setting Menu 1. Weighing 1.1. Adapt filter 1.1.1 Minimum vibration parameters 1.1.2 o Normal vibration 1.1.3 Strong vibration 1.1.4 Extreme vibration 1.2. Application filter 1.2.1 o Final readout 1.2.2 Filling mode 1.3.
Page 81
Menu 1. Weighing 1.1. through 1.6. see previous page parameters 1.7. Weight unit 1 1.7.2 Grams 1.7.3 o Kilograms 1.7.4 Carats 1.7.5 Pounds 1.7.6 Ounces 1.7.7 Troy ounces 1.7.8 Hong Kong taels 1.7.9 Singapore taels 1.7.10 Taiwanese taels 1.7.11 Grains 1.7.12 Pennyweights 1.7.13...
Page 82
Menu 1. and 2. see previous pages 3. Application 3.1. Weight unit 2 3.1.2 Grams parameters 3.1.3 o Kilograms 3.1.4 Carats 3.1.5 Pounds 3.1.6 Ounces 3.1.7 Troy ounces 3.1.8 Hong Kong taels 3.1.9 Singapore taels 3.1.10 Taiwanese taels 3.1.11 Grains 3.1.12 Pennyweights 3.1.13...
Page 83
Menu 5. Interface 5.1. through 5.3. see previous page 5.2. Parity 5.2.1 Mark 5.2.2 Space 5.2.3 o Odd 5.2.4 Even 5.3. No. of stop bits 5.3.1 o 1 stop bit 5.3.2 2 stop bits 5.4. Handshake mode 5.4.1 Software 5.4.2 Hardware, 1 char.
Error Codes Error codes are shown in the main display for approx. 2 seconds, after which the program automatically returns to the weighing mode. Display Cause Solution No segments appear on No AC power Check the AC the display is available power supply The AC adapter is not Plug in the AC adapter...
Page 85
The weight readout The scale has not Calibrate/adjust is obviously wrong been calibrated/adjusted the scale The scale was not Tare or zero the scale zeroed before weighing before weighing If any other errors occur, contact your local Sartorius Service Center!
Care and Maintenance Cleaning Service ! Unplug the AC adapter from the Regular servicing by a Sartorius wall outlet (mains supply). If you technician will extend the service life of have a data cable connected to your scale and ensure its continued the interface, unplug it from the weighing accuracy.
Page 87
If there is any indication that safe are authorized by Sartorius and who operation of the scale with the AC adapter or power supply is no longer – have access to the required service...
Instructions for Recycling the Packaging To ensure safe shipment, your scale has been packaged using environmentally friendly materials. After successful installation of the scale, you should return this packaging for recycling. For information on recycling options, including recycling of old weighing equipment, contact your municipal waste disposal center or local recycling depot.
Overview General View of the Scale No. Designation Order no. No. Designation Order no. replacement replacement Main grounding 10 Clear function key terminal 11 On/off/standby Level indicator Interface port 12 Toggle key DC jack 13 Leveling foot Set: 69EA0020 Print key 14 Load plate Function key –...
Description of the Keys e key: w key: Toggle ) key: Tare On/Off/Standby Switch For toggling the display For taring the weight of between weighed and containers so that the Switches the display on/ calculated values scale readout shows the off.
Accessories (Options) Product Order No. AC adapter/power supply for use outside the hazardous area/location 609308-..1 AC adapter/power supply for use within the hazardous area/location YPS03-X.. ! Install the cable so that it is protected from damage. Connect the terminal of the housing to a terminal for equipotential bonding (PE = protective earthing or grounding conductor) Zener barrier for use outside...
Page 94
Accessories for use outside the hazardous area/location: Data Printer YDP 03-0CE for printouts that include date and time, statistical evaluation and transaction counter; with LCD Please note: only operable with an external AC adapter/power supply (use the YCC01-0016M3 adapter cable to connect it to a model YDI02-Z or YDI03-Z Zener barrier;...
Important Note: The operator shall be responsible for any modifications to Sartorius equipment and for any connections of cables or equipment not supplied by Sartorius and must check and, if necessary, correct these modifications and connections. On request, Sartorius will provide information on the minimum operating specifications (in accordance with the Standards listed above for defined immunity to interference).
Page 105
All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior written permission of Sartorius AG. The status of the information, specifications and illustrations in this manual is indicated by the date given below.
