Operating Guide | VLT® Compressor Drive CDS 803

6.5.12 Relay Outputs, Enclosure Size H6

Programmable relay output
Relay 01 and 02
Maximum terminal load (AC-1)
Maximum terminal load (AC-15)
Maximum terminal load (DC-1)
Maximum terminal load (DC-13)
Maximum terminal load (AC-1)
Maximum terminal load (AC-15)
Maximum terminal load (DC-1)
Maximum terminal load (DC-13)
Minimum terminal load on 01–03 (NC), 01–02 (NO), 04–06 (NC), 04–05 (NO)
Environment according to EN 60664-1
2
Overvoltage Category II.
3
UL applications 300 V AC 2 AC.

6.5.13 Control Card, 10 V DC Output

Terminal number
Output voltage
Maximum load

6.5.14 Ambient Conditions

Enclosure protection rating
Enclosure kit available
Vibration test
Maximum relative humidity
Aggressive environment (IEC 60721-3-3), coated (standard), enclosure sizes
H3–H5
Aggressive environment (IEC 60721-3-3), non-coated enclosure size H6
Test method according to IEC 60068-2-43 H2S (10 days)
Ambient temperature, enclosure sizes H3–H5
Ambient temperature, enclosure size H6
Minimum ambient temperature during full-scale operation
Minimum ambient temperature at reduced performance, enclosure sizes H3–
H5
Minimum ambient temperature at reduced performance, enclosure size H6
Temperature during storage/transport
Maximum altitude above sea level without derating
Maximum altitude above sea level with derating
Danfoss A/S © 2019.12
(1) on 04–05 (NO) (resistive load)
(1) on 04–05 (NO) (Inductive load @ cosφ 0.4)
(1) on 04–05 (NO) (Resistive load)
(1) on 04–05 (NO) (Inductive load)
(1) on 04–06 (NC) (Resistive load)
(1) on 04–06 (NC) (Inductive load @ cosφ 0.4)
(1) on 04–06 (NC) (Resistive load)
(1) on 04–06 (NC) (Inductive load)
(1)
01–03 (NC), 01–02 (NO), 04–06 (NC), 04–05 (NO)
(2) (3)
5–95% (IEC 60721-3-3; Class 3K3 (non-condensing)
Specifications
24 V DC 10 mA, 24 V AC 20 mA
Overvoltage category III/pollution degree 2
during operation)
-30 to +65/70 °C (-22 to +149/158°F)
1000 m (3281 ft)
3000 m (9843 ft)
AQ321748767627en-000101 / 130R0570| 49
2
400 V AC, 2 A
240 V AC, 0.2 A
80 V DC, 2 A
24 V DC, 0.1 A
240 V AC, 4 A
240 V AC, 0.2 A
50 V DC, 2 A
24 V DC, 0.1 A
50
10.5 V ±0.5 V
25 mA
IP20
IP21, TYPE 1
1.0 g
Class 3C3
Class 3C2
50 °C (122 °F)
45 °C (113 °F)
0 °C (32 °F)
-20 °C (-4 °F)
-10 °C (14 °F)
