Operating Guide | VLT® Compressor Drive CDS 803
PLC
PLC
Minimum 16 mm
equalizing cable
Control cables
Mains-supply
L1
L2
L3
PE
Reinforced protective earth
Illustration 9:
EMC-correct Electrical Installation
20 | Danfoss A/S © 2019.12
Panel
Status
Quick
Main
Menu
Menu
Menu
Com.
OK
On
Warn.
Alarm
Hand
Auto
Reset
On
On
(6 AWG)
2
Minimum 200 mm (7.87 in)
between control
cable, mains cable
and between mains
motor cable
Output con-
tactor
Grounding rail
Cable insula-
tion stripped
All cable entries in
one side of panel
Motor cable
Motor, 3 phases and
protective earth
AQ321748767627en-000101 / 130R0570
Installation
