Operating Guide | VLT® Compressor Drive CDS 803
3.2.3.3 Relays and Terminals on Enclosure Sizes H3–H5
1
2
U
V W
-DC +DC
2
3
1 Mains
3 Compressor
Illustration 7:
Enclosure Sizes H3–H5, IP20, 200–240 V, 6.0–10 kW (8.0–15 hp), IP20, 380–480 V, 6.0–22 kW (8.0–30 hp)
Danfoss A/S © 2019.12
4
2 Ground
4 Relays
Installation
AQ321748767627en-000101 / 130R0570| 17
