  • Page 1 ® Series 3500 Adjustable Frequency Drive Instruction Manual...
  • Page 2 ® Series 3500 ® Series 3500 Instruction Manual 175R5237 - Document Version 5.00 ® This manual applies to all VLT Series 3502-3800 Adjustable Frequency Drives with software version 3.02 and 3.12 or newer. To determine software version refer to Parameter 603, Name Plate. WARNING: Touching the electrical parts, even when the AC line has been disconnected, can cause serious...

  • Page 3: Table Of Contents

    ® Series 3500 Table of Contents Safety Guidelines ..............................4 Warnings Against Unintended Start ........................4 Specification Charts ............................... 5 Dimensions ................................10 General ................................. 23 VLT Type 3052-3562 ............................23 VLT Type 3575-3700 and 3542-3562 ........................23 Base for VLT Type 3625-3800 ........................23 Hinged Door on VLT Type 3575-3800 ......................
  • Page 4 ® Series 3500 Table of Contents Drive Setup ................................52 Return to Factory Defaults .......................... 52 Lockout ................................ 52 Standard HVAC Operation Parameters ....................... 53 Extended Menu Structure ............................ 54 Parameter Numbers ............................ 54 Accessing the Various Parameters ........................54 Changing the Parameter Data Value ........................
  • Page 5 ® Series 3500 Table of Contents Group 5 -- Serial Data Interface ........................85 Bytes 1 22 ..............................86 Control Word ............................87 Bit 00 - 04 ............................87 Bit 05 - 14 ............................88 Bit 15 ..............................89 Status Word ............................89 Bit 00 - 14 ............................

  • Page 6: Safety Guidelines

    ® and CE Marking components at or above line potential. Extreme care ® Danfoss CE marks our VLT Adjustable Frequency should be taken to protect against shock. Stand on an Drives (AFD) according to the Electro Magnetic insulating pad and make it a habit to use only one hand Compatibility (EMC) Directive 89/336/EEC and Low- when checking components.

  • Page 7: Specification Charts

    Immunity EN 50082-2, IEC 801-2, IEC 801-3, IEC 801-4, IEC 801-5, VDE 0160, SEN 361503 * If shielded cable is to be used, consult Danfoss for cable length. 1) In the range –10 to 0°C, the equipment can start and run; however, the display values and certain operating characteristics will not fulfill the specifications.
  • Page 8 Immunity EN 50082-2, IEC 801-2, IEC 801-3, IEC 801-4, IEC 801-5, VDE 0160, SEN 361503 * If shielded cable is to be used, consult Danfoss for cable length. 1) In the range –10 to 0°C, the equipment can start and run; however, the display values and certain operating characteristics will...
  • Page 9 Immunity EN 50082-2, IEC 801-2, IEC 801-3, IEC 801-4, IEC 801-5, VDE 0160, SEN 361503 * If shielded cable is to be used, consult Danfoss for cable length. 1) In the range –10 to 0°C, the equipment can start and run; however, the display values and certain operating characteristics will...
  • Page 10 Immunity EN 50082-2, IEC 801-2, IEC 801-3, IEC 801-4, IEC 801-5, VDE 0160, SEN 361503 * If shielded cable is to be used, consult Danfoss for cable length. 1) In the range –10 to 0°C, the equipment can start and run; however, the display values and certain operating characteristics will...
  • Page 11 Immunity EN 50082-2, IEC 801-2, IEC 801-3, IEC 801-4, IEC 801-5, VDE 0160, SEN 361503 * If shielded cable is to be used, consult Danfoss for cable length. 1) In the range –10 to 0°C, the equipment can start and run; however, the display values and certain operating characteristics will...

  • Page 12: Dimensions

    ® Series 3500 VLT 3502 Dimensions inches (mm) 0.33 (8.5) Add-On Module Ø0.57 (14.5) 0.98 (25) 0.33 (8.5) Ø0.57 (14.5) 0.98 (25) 11.18 7.01 (284) (178) 2.28 (58) 4.53 (115) 10.16 (258) Type Input Overall Dimensions Mounting Dimensions Chassis* Chassis* 11.81 (300) 11.18 (284) 7.01 (178)
  • Page 13 ® Series 3500 VLT 3504 Dimensions inches (mm) 0.33 (8.5) Add-On Module Ø0.57 (14.5) 0.98 (25) 0.33 (8.5) Ø0.57 (14.5) 0.98 (25) 11.18 7.01 (284) (178) 2.28 (58) 4.53 (115) 10.16 (258) Type Input Overall Dimensions Mounting Dimensions Chassis* Chassis* 11.81 (300) 11.18 (284) 7.01 (178)
  • Page 14 ® Series 3500 VLT 3505 Dimensions inches (mm) 0.33 (8.5) Add-On Module Ø0.57 (14.5) 0.98 (25) 0.33 (8.5) Ø0.57 (14.5) 0.98 (25) 11.18 7.01 (284) (178) 2.28 (58) 4.53 (115) 10.16 (258) Type Input Overall Dimensions Mounting Dimensions Chassis* 11.81 (300) 11.18 (284) 7.01 (178) 10.16 (258)
  • Page 15 ® Series 3500 VLT 3506 Dimensions inches (mm) 0.33 (8.5) Ø0.57 (14.5) 0.98 (25) 11.18 7.01 (284) (178) 2.28 (58) 4.53 (115) 10.16 (258) Add-On Module Type Input Overall Dimensions Mounting Dimensions Chassis* 17.32 (440) 11.18 (284) 7.01 (178) 10.16 (258) 12.99 (330) 2.17 (55) 2.17 (55) NEMA 1*...
  • Page 16 ® Series 3500 VLT 3508 Dimensions inches (mm) Drawing 1 Drawing 2 0.39 (10) 0.33 (8.5) 0.33 (8.5) Ø0.57 (14.5) 0.98 (25) 11.18 7.01 (284) (178) 2.28 (58) 4.53 (115) 10.16 (258) Add-On Module Drawing 1 Type Input Overall Dimensions Mounting Dimensions Chassis 25.98 (660)
  • Page 17 ® Series 3500 VLT 3511 Dimensions inches (mm) Drawing 2 Drawing 1 0.39 (10) 0.33 (8.5) 0.33 (8.5) Ø0.57 (14.5) 0.98 (25) 11.18 7.01 (284) (178) 2.28 (58) 4.53 (115) 10.16 (258) Add-On Module Drawing 1 Type Input Overall Dimensions Mounting Dimensions Chassis 25.98 (660)
  • Page 18 ® Series 3500 VLT 3516 Dimensions inches (mm) 0.33 (8.5) Ø0.57 (14.5) 0.98 0.39 (10) (25) 0.33 (8.5) Drawing 2 Drawing 1 Drawing 1 Type Input Overall Dimensions Mounting Dimensions Chassis 30.71 (780) 29.92 (760) Chassis 9.53 (242) 10.24 (260) 7.87 (200) 0.39 (10) 0.39 (10)
  • Page 19 ® Series 3500 VLT 3522 Dimensions inches (mm) 0.33 (8.5) 0.39 Ø0.57 (10) 0.33 (14.5) 0.98 (8.5) (25) Drawing 1 Drawing 2 Drawing 1 Type Input Overall Dimensions Mounting Dimensions Chassis 37.40 (950) 12.09 (307) 11.65 (296) 10.63 (270) 36.61 (930) Chassis 0.39 (10) 0.39 (10)
  • Page 20 ® Series 3500 VLT 3532 Dimensions inches (mm) 0.33 (8.5) Ø0.57 (14.5) 0.98 0.39 (10) (25) 0.33 (8.5) Drawing 1 Drawing 2 Drawing 1 Type Input Overall Dimensions Mounting Dimensions Chassis 37.40 (950) 12.09 (307) 11.65 (296) 10.63 (270) 36.61 (930) Chassis 0.39 (10) 0.39 (10)
  • Page 21 ® Series 3500 Dimensions VLT 3542, 3552, 3562, 380 and 460 V (for 230 V units refer to page 20) inches (mm) 0.33 (8.5) 0.39 Ø0.57 (10) (14.5) 0.98 0.33 (25) (8.5) Drawing 1 Drawing 2 Drawing 1 Type Input Overall Dimensions Mounting Dimensions Chassis...
  • Page 22 ® Series 3500 Dimensions VLT 3542, 3552, 3562, 230 V VLT 3575, 3600, 380 and 460 V inches (mm) (56) 17.6 (446) (25) 1.0 (25) 33.5 25.39 35.4 (645) (851) (900) 19.9 (505) NEMA 1 13.9 (353) NEMA 12 14.8 (376) Ø0.59 (15) Ø1.06...
  • Page 23 ® Series 3500 Dimensions VLT 3625, 3650, 3700, 380 and 460 V inches (mm) (56) 17.0 (432) (31) 1.3 (32) 57.2 59.6 (1453) (1515) 20.2 (513) 5.0 (127) NEMA 1 15.5 (394) Optional NEMA 12 16.4 (417) Pedestal Ø0.59 (15) Ø1.06 (27) (13)
  • Page 24 ® Series 3500 Dimensions VLT 3750, 3800, 380 and 460 V inches (mm) (56) 66.7 (1694) 20.2 (513) NEMA 1 20.0 (508) 5.0 (127) NEMA 12 20.9 (531) Pedestal 1.0 (25.4) (25.4) 19.5 Pedestal (495) (4– 1/2" holes 39.7 for bolting (1008) pedestal and Door...

  • Page 25: General

    ® Series 3500 General If the bracket is removed for installation, it must be The specific installation instructions may vary depending reinstalled to prevent overheating. The key slots in the upon the model of VLT Series 3500 being installed. When mounting bracket make it possible to fasten the this occurs, the model will be identified by a “VLT Type attachment bolts to the wall or in the panel before...

  • Page 26: Hinged Door On Vlt Type 3575-3800

    ® Series 3500 The drawing shows the base and its dimensions. Hinged Door on VLT Type 3575-3800 The door on the VLT Type 3575-3800 is hinged on the left-hand side. The table below gives the door radius and the necessary distance from the mounting surface for the door to be able to open freely: VLT type...

  • Page 27: Auxiliary Enclosures

    ® Series 3500 Cooling Floor Stand Kit Mounting For a free flow of cooling air, space is required both If a drive designed for wall mounting is mounted to a floor above and below the drive. The minimum space required stand kit or is not mounted directly to a wall, a solid panel depends on the drive model and the enclosure type.

  • Page 28: Input Power Wiring

    ® and CE Marking the bottom and the side of the drive. It is recommended ® Danfoss CE marks our VLT Adjustable Frequency that the larger, bottom wiring access plate be used for Drives (AFD) according to the Electro Magnetic conduit entry.

  • Page 29: Power Terminals

    ® Series 3500 The drive voltage is dangerous when connected to the Input Voltage Max. Drive Max. Fuse AC line and up to 14 minutes after the unit has been Output Current Rating 440 - 500 V 3502 10 A disconnected.
  • Page 30 ® Series 3500 Typical Line and Motor Connection VLT 3502, 3504, 230V units VLT 3502, 3504, 3505, 3508, 380V units VLT 3502, 3504, 3506, 3508, 460V units VLT 3508, 3511, 230V units VLT 3511, 3516, 3522, 3532, 380V units VLT 3511, 3516, 3522, 3532, 460V units VLT 3516, 3522, 3532, 230V units VLT 3542, 3552, 3562, 380V units VLT 3542, 3552, 3562, 460V units...
  • Page 31 ® Series 3500 Typical Line and Motor Connection VLT 3542, 3552, 3562, 230V units VLT 3575, 3600, 380V units VLT 3575, 3600, 460V units VLT 3625, 3650, 3700, 380V units VLT 3625, 3650, 3700, 460V units VLT 3750, 3800, 380V units VLT 3750, 3800, 460V units...

  • Page 32: Motor Connections

    ® Series 3500 Motor Connections All types of three-phase asynchronous standard motors can be used with the VLT Series 3500. Wire the motor for the proper voltage as shown on the motor nameplate. Wire the motor to terminals U, V, and W (96, 97 and 98) on the drive.

  • Page 33: Terminal Block Locations

    ® Series 3500 Terminal Block Locations VLT Type 3502 - 3511 Series, 380 V 3502 - 3504 Series, 208/230 V 3502 - 3508 Series, 460 V VLT Type 3511 - 3562 Series, 380 - 460 V VLT Type 3508 - 3532 Series, 208/230 V 3575 - 3800 Series, 380 - 460 V 3542 - 3562 Series, 208/230 V Programmable Terminal Functions...

  • Page 34: Control Card Terminals

    ® Series 3500 Control Card Terminals The drawing at the right shows the control card terminals on the VLT Series 3500 drive, and the parameters that control them. A description of the control signals and terminals is below. Terminal 39: Common for analog/digital outputs.

  • Page 35: Electrical Noise

    ® Series 3500 Electrical Noise If a shielded cable is used for serial communication and In general, electrical noise can be divided into two forms: signal interface, the shield must be connected at both wire-borne noise (EMI) and radiating noise (RFI). ends.

  • Page 36: Installation Of Units With Optional Emi Filter Module

    ® Series 3500 Installation of Units with Optional EMI Filter Module Control Wiring If an optional EMI filter module is supplied, it is normally The control wiring must be shielded. The shield must be mounted below the drive with its own mounting plate. mounted to the clamp supplied on the drive.

  • Page 37: Wiring And Setup Examples

    ® Series 3500 Typical Wiring and Setup Examples The following examples show some typical HVAC installations. The power and control connections, and the parameter settings for each example are shown. Details of the parameters are in the Drive Setup section. It may helpful to find the example closest to the requirements of your installation and use it as a guide.
  • Page 38 ® Series 3500 Example 2: In a ventilating system, the ability to reverse the fan in the case of fire is required. The control signal used is 4 to 20 mA, corresponding to 10 to 100% motor speed, typically 6 to 60 Hz. A remote indication of motor speed is required.
  • Page 39 ® Series 3500 Example 3: A fan is to be controlled manually by means of a 0 to 10 V DC potentiometer corresponding to 10 to 60 Hz. A thermistor is installed in the motor to obtain optimum motor protection. The thermistor is to be connected to the drive to shut down the drive in case of motor overtemperature.
  • Page 40 ® Series 3500 Example 4: Although three-wire “Start/Stop” is not commonly used for unattended operation, some installations may require it for operator safety. A pump is to be controlled by means of a 0 to 10 V control signal, corresponding to 18 to 60 Hz. "Start/Stop"...
  • Page 41 ® Series 3500 Example 5: The output frequency of the drive is to be controlled by means of digital signals from a PLC or floating point control. Whenever the output frequency is outside the 10 to 45 Hz range, the relay output is to be activated giving a signal to the PLC.
  • Page 42 ® Series 3500 Example 6: NOTE: A ventilation system is to be run at six preset speeds, A shield for control wires is to be connected in depending on the time of the day or night. accordance with the installation instructions. Maximum speed is 60 Hz.
  • Page 43 ® Series 3500 Example 7: The transmitter used is a 4 to 20 mA, 0 to 10 PSI type. In a pump system, a constant pressure of 5 PSI is to be Since a pressure of 5 PSI is required, this corresponds to maintained.
  • Page 44 ® Series 3500 Example 8: The transmitter used is a temperature sensor with a In a ventilation system the temperature is to be adjusted working range of 32 to 120°F, 4 to 20 mA. In order to by means of a 0 to 10 V potentiometer. The selected carry out inverse regulation, the drive is programmed to temperature must be kept constant, and the internal PID convert the temperature transmitter signal (4 to 20 mA)
  • Page 45 ® Series 3500 Example 9: Remote Hand/Off/Auto control is desired. The Local/Hand, and Remote/Hand switches are to provide these functions. The “Hand” reference is a 0 to 10 V signal from a potentiometer. The “Auto” signal is a 4 to 20 mA reference from a set point controller. NOTE: A shield for control wires is to be connected in accordance with the installation instructions.

  • Page 46: Control Panel

    ® Series 3500 Control Panel External Local/Hand and Remote/Auto References In parameter 420 it is possible to choose the reference to Local/Hand and Remote/Auto Control be used in the External Hand mode. The start/stop and speed reference functions of the drive are controlled by these controls.

  • Page 47: How To Operate Vlt Series 3500

    ® Series 3500 How to Operate the VLT Series 3500 The VLT Display In order to program and locally control the drive, use the The display is designed to be lit whenever the drive is control panel on the front of the drive. connected to the AC line.

  • Page 48: Keys For Local Operation

    ® Series 3500 Keys for Local Operation Shown below is the appearance of the display when in The following keys are used for local operation: local mode and the drive is ready to run. 0 Hz This key is used for starting up the VLT Series 0000000000000060 3500 .

  • Page 49: Display Mode

    ® Series 3500 Display Mode By default, the top display line shows the value of the In normal operation, the VLT Series 3500 starts up in selected readout and the second line displays a display mode. In the display mode, there is the ability to description of the readout.

  • Page 50: Functions Of The Keys

    ® Series 3500 Combinations of Control Panel Keys Functions of the Keys MENU AND DATA KEYS If these keys are pressed simultaneously, the The eight keys on the control system switches to Display mode from panel of the drive are used for any other mode.

  • Page 51: Display Mode

    ® Series 3500 Display Mode 15.0 Hz Shows value and unit FREQUENCY Direction of rotation Defines the display Status, and source of control RUN OK LOCAL. Setup number Quick Set Up Menu Enter from the Display mode by pressing the “Menu”...

  • Page 52: Extended Parameter Mode

    ® Series 3500 Extended Parameter Mode Enter from the Extended Menu mode Change the displayed by pressing the “Menu” key. parameter by pressing the “+” or the “-” key. 0.0 Hz Flashing parameter number 000 LANGUAGE 0 = Cursor flashes ENGLISH Selected data value Extended Data Mode...

  • Page 53: Menu Access Keys

    ® Series 3500 Menu Access Keys...

  • Page 54: Drive Setup

    ® Series 3500 Drive Setup When the drive is first powered up, the items in the Quick Setup menu should be viewed and changed as required. The Quick Setup menu items are shown below. If preferred, these items can be viewed and changed from the Extended menu.

  • Page 55: Standard Hvac Operation Parameters

    ® Series 3500 Standard HVAC Operation Parameters Functions and Timers Operation and Display 000 Language ENGLISH 301 Start Freq. 00.0 001 Setup Selection SETUP 1 302 Start Delay 002 Setup Copy DO NOT COPY 303 High Starting Torque Time 0.0 003 Local/Remote (HOA) KEY HOA w.

  • Page 56: Extended Menu Structure

    ® Series 3500 Extended Menu Structure Changing the Parameter Data Value VLT Series 3500 menu structure, referred to as the When a parameter has been selected and the data value Extended Menu, is divided into seven groups. These is to be changed, press the “Data” key and then “+” or contain parameters that allow performance to be “–”.

  • Page 57: Speed Control Signal -- Open Loop

    ® Series 3500 Speed Control Signal -- Open Loop...

  • Page 58: Speed Control Signal -- Closed Loop

    ® Series 3500 Speed Control Signal -- Closed Loop...

  • Page 59: Parameter Groups Table

    Many of the special features of 401 Binary Input 17 410 Relay Output 04 (4) the VLT 3500 Series drive are included in Group 1. One 402 Binary Input 18 411 Analog Ref. Type (4) of these is the “Automatic Energy Optimizer” (AEO), 403 Binary Input 19 412 Term.

  • Page 60: Programming

    No copying [0]. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 61: Parameters 003 - 008

    Data changes in param- eter 004 are blocked if parameter 010 is programmed as DISABLE. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 62: Parameters 009 - 014

    Reset starts when Data mode is exited. The hour meter cannot be reset via the serial bus. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 63: Parameters 015

    NOTE: If the setup being used is changed, the changes will take effect immediately. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 64: Group 1 -- Load And Motor Parameters 100 - 101

    The magnitude of the starting voltage is controlled by parameter 109. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 65: Parameters 102 - 104

    650. This is also chosen Quick Set Up Menu step 1. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 66: Parameters 105 - 114

    60 (parameter 413) must be used for the feedback signal. The same type of signal cannot be the reference signal. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 67: Parameters 115 - 119

    [38] m/s. [18] ft/min. [39] m/min. [19] [40] (no unit) [20] lb/in [41] = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 68: Parameters 120 - 125

    50% (25% x 200% = 50%). = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 69: Group 2 -- References And Limits

    Be sure that the system can be operated at this speed whenever the jog function is activated. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 70: Parameters 205 - 210

    The value set at the factory corresponds to the rated con- of f /analog reference tinuous output current of the VLT 3500 Series. If the current MAX. limit is to be used as motor protection, the rated motor cur- rent must be programmed. Parameter 310 determines the 208 Digital Reference 4 (REF.

  • Page 71: Parameters 211 - 216

    The desired decel time is programmed. This is also chosen in Quick Set Up Menu step 9. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 72: Parameters 217 - 224

    Frequency Modulation (ASFM), parameter 225 is Value: enabled. 0 to 120 Hz 120 Hz = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 73: Parameters 225 - 232

    = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 74: Group 3 -- Functions And Timers

    The motor begins to ramp down immediately following the Alternative Decel Time set in parameter 218. Function: VLT 3500 Series starts at the start frequency (parameter 305 Catch a Rotating Motor (FLYING STA) 301) and begins to ramp up when the start delay has Value: ended.

  • Page 75: Parameters 306 - 309

    The amount of braking Function: torque depends upon the DC braking voltage set by param- The VLT 3500 Series can be programmed for automatic eter 308. fault reset. From one to ten automatic reset attempts may be selected by this parameter.

  • Page 76: Parameters 310 - 314

    Function: Function: When the drive goes into current limit, as set by parameter VLT 3500 Series is able to check whether a motor has been 209, this timer determines how long the drive will run in cur- connected. rent limit before it fault trips. This is provided to prevent damaging a stalled or heavily overloaded motor.

  • Page 77: Parameters 315 - 317

    407 through 410. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 78: Group 4 -- Inputs And Outputs

    3 kΩ or the Klixon opens, the drive will trip and “MOTOR TRIP” will be displayed. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 79: Parameters 402 - 403

    = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 80: Parameters 403 - 404

    12 (24 V DC) to terminal 27 is broken, the drive decelerates to a stop as defined by parameter 216. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 81: Parameter 405

    Changes to the speed reference will have no effect on the drive’s operation until the voltage is removed from terminal 29. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 82: Parameter 406

    Terminal 32 parameters 215 and 216. Freeze reference (summarized) Increase reference Reduce reference Reduce reference = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 83: Parameter 407

    VLT is running (output frequency is > 0.5 Hz or has a start signal). = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 84: Parameters 408 - 409

    The output current from the drive is below the idle running current set in parameter 232. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 85: Parameters 410 - 412

    Used for deciding how the drive is to follow an analog refer- ence signal, see graphs in next column. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 86: Parameters 413 - 420

    If Speed Up/Down [2] is selected, digital speed up/down (floating point control) is used, which is programmed in pa- rameter 406. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 87: Group 5 -- Serial Data Interface

    Set the speed of transmission in parameter 501 and the address of each unit in parameter 500. Danfoss can provide a serial communication program “VLS Dialog”, which allows an IBM compatible personal com- Message (telegram) format (protocol)

  • Page 88: Bytes 1 22

    ® Series 3500 Byte 1: Byte 5 through 8: Start byte, which in this case must be the character "<" Control and status words, used to send commands to the (ASCII: 60). frequency converter and to send status from the frequency converter to the master.

  • Page 89: Control Word

    ® Series 3500 Control Word, bytes 5 through 8 in the message. The control word is used to send control commands from the controller to the drive. According to the data format, 1 byte consists of 8 databits, but in the control word only the 4 least significant bits of each byte are used, which means that ASCII characters from A to O can be used.

  • Page 90: Bit 00 - 04

    ® Series 3500 Bit 11, NO FUNCTION/SLOW DOWN: The function of bit 04 can be redefined to DC braking in pa- rameter 514; otherwise the function is as described. Note: Used for reducing the speed reference by the value of pa- In parameter 504 and 505 a choice is made as to how bit rameter 513.

  • Page 91: Bit 15

    ® Series 3500 Bit 15, NO FUNCTION/REVERSING: logical or or logical and has been selected ( logical and only Reversing of the direction of rotation of the motor. Bit 15 = in connection with terminal 19). “0” leads to no reversing; bit 15 = “1” leads to reversing. Please note that the original setting for reversing in para- Example: meter 507 is digital;...

  • Page 92: Bit 00 - 14

    ® Series 3500 Bit 00, CONTROLS NOT READY / READY: Bit 09, LOCAL CONTROL/BUS CONTROL: Bit 00 = “0” means that bit 00, 01 or 02 of the control word Bit 09 = “0” means that the drive has stopped by means of is “0”...

  • Page 93: Bit 15

    ® Series 3500 Bit 15, TIMERS OK/OVERSHOOT: Example: Bit 15 = “0” means that the timers for thermal motor protec- The status word below says that the motor is running on tion and thermal drive protection have not exceeded 100%. the desired speed reference, but outside the defined fre- Bit 15 = “1”...

  • Page 94: Response Message

    The shield should be insulated, to avoid contact with other circuitry. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 95: Parameters 500 - 502

    14 through 19. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 96: Parameter 502 (Continued)

    EEPROM fault 24 V fault Overcurrent Voltage warning, high Voltage warning, low Overvoltage Undervoltage = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 97: Parameters 503 - 510

    Active stop signal is “0”. Digital (DIGITAL) Bus (BUS) Logical and (AND) Logical or (OR) = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 98: Parameters 510 (Continued) - 517

    Bit 4 of the control word can be used either for quick-stop, or for DC braking. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 99: Group 6 -- Service And Diagnostics

    It is possible to scroll through the log values. NOTE: The data log is reset during power up. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 100: Parameters 602 - 603

    0 if another trip occurs. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.
  • Page 101 If a fault message ap- sistor, and wire. pears, the control card must be replaced. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 102: Parameters 605 - 650

    See the section on Display Mode. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 103: Status Messages

    Bit 05 of the serial control word is “0”. or decelerating. = ROM default setting. = Normal Danfoss setup. Text in ( ) = display text. Figures in [ ] are used when communicating with the bus.

  • Page 104: Warning Messages

    ® Series 3500 Warning Messages Reference Fault (REF FAULT): Warning messages also appear in the third line of the dis- An analog input signal with a “live zero” has been chosen play. such as 4 to 20 mA, 1 to 5 V or 2 to 10 V, for terminal 53 or 60.

  • Page 105: Reset Messages

    ® Series 3500 Reset Messages Ground Fault (GROUND FAULT): Error code 5 Reset messages appear in the second line of the display. There is a current path from the output phases to the ground, either in the wiring between the drive and the mo- ALARM tor, or within the motor.

  • Page 106: Fault Messages

    The heat sink of the drive is dirty or obstructed This message indicates a control card problem. Contact a • The fan(s) is not operating Danfoss service center. • The drive is not mounted vertically directly against a solid surface...

  • Page 107: Electrostatic Discharges

    ® Series 3500 Electrostatic Discharges Many electronic components are sensitive to static electricity. Even voltages so low that they cannot be felt, seen or heard may damage components or destroy them completely. Discharge of static electricity can damage components, shorten their life, and cause erratic operation. Suspect damage due to static electricity if faults occur periodically with varying temperature, varying load, or vibration.

  • Page 108: Troubleshooting

    Motor runs unevenly the cause can be incorrect setting of the VLT drive. Adjust the setting. If the new setting cannot make the motor run evenly, contact Danfoss. Is there backlight in the Symptom display? Motor does not run Are fault messages...
  • Page 109 Have the input fuses blown? No fault message or backlight in the display Check the drive’s input for shorts. Replace the fuses. Contact Danfoss Is the control card over- loaded? Disconnect all control signal plugs on the control card. Does the fault disappear?
  • Page 110 The drive must be set to run using local references. Activate the Local/Hand key and change the Local reference by means of – Is the motor running? Contact Danfoss. Check whether the control signals to the control card are OK.

  • Page 111: External Mounting Of Display

    ® Series 3500 Before opening the enclosure to install any components, be sure all power has been removed from the drive. Allow at least 14 minutes for the capacitors to discharge before touching any internal components. External Mounting of Display The control panel can be mounted remotely by means of an optional adapter and cable.

  • Page 112: Appendix 1 Field Terminal Connections

    ® Series 3500 Appendix 1 Field Terminal Connections All of the bolts on the field terminal blocks and other de- vices must be torqued according to the tables below. All connections must be made with 75 C rated copper wiring. All units are in inch pounds.

  • Page 113: Appendix 2 Pi Regulation

    PI Regulation Parameter 120: Appendix 2 Controls the bandwidth of the output from PID controller. Set at 100%. The following instructions will enable quick and easy set- up of the PI regulation and associated parameter Parameter 121: settings. Detailed information about each parameter can Controls the gain of the system.
  • Page 114 PI Regulation Example: Example: The set-point is 40%, and the min. speed is 50%. A pressure transmitter has range of 0-10 bar. A set-point of 4 bar is required. 1. Selecting a new set-point. Choose a value that will Set-point = 4/10 x 100 = 40% raise the set-point about 10% higher than the min.
  • Page 115 PI Regulation For inverse control; modification of the setpoint and External Setpoint feedback signal is required. Link Start/Stop Example: Parameter 402 (start) A transmitter has a 0-15 foot span equal to 0-20mA. The PID set-point must be set at 12 feet for inverse control. •...

  • Page 116: Index

    ® Series 3500 Index + KEY ................... 48 Bit 06 ................. 101 - KEY ..................48 bottom conduit entry plate ..........26 0 to 10 V DC ................ 83 bottom cover ............... 26 0 to 20 mA .............. 81, 82, 84 broken belt ................
  • Page 117 ® Series 3500 extended menu ............47, 48, 54 extended menu mode ............49 dampening ................66 extended menus ..............58 DATA KEY ................48 extended parameter mode ..........50 data log ................97 external H-O-A ..........76, 77, 78, 84 data mode ................
  • Page 118 ® Series 3500 loss of load ................69 low carrier frequency at low speed ........71 I (read index) ............... 86 low current warning ............102 increase or decrease the output frequency ...... 46 low frequency warning ............. 102 information packet ............. 24 low voltage warning ............
  • Page 119 ® Series 3500 open loop ................62 202 Maximum Frequency ........67 “Open Loop” ............... 59 203 Jog Frequency ..........67 operation OK ..............101 204 Digital Reference Type ........ 67 operation with deactivated inverter ........99 205 Digital Reference 1 ........68 option cards ..............
  • Page 120 ® Series 3500 508 Reset ............95 parameter 224 ............. 71 509 Selection of Setup ........95 parameter 225 ............. 70 510 Selection of Speed ........ 95, 96 parameter 301 ............. 72 511 Bus Jogging 1 ..........96 parameter 306 ..........72, 78 512 Bus Jogging 2 ..........
  • Page 121 ® Series 3500 pulse start hand ..............76 RUN@REF noWR ........... 81, 82, 83 pulses .................. 79 RUNinRANGE ............81, 82, 83 pumps .................. 69 RUNNING ............... 81, 82, 83 running above the frequency ..........81 running below the frequency ..........81 running hours .............
  • Page 122 ® Series 3500 STOP/RESET KEY .............. 48 UNIT RDY LOC..............101 strain relief ................26 UNIT READY ..........81, 82, 83, 101 supply voltage ..............32 unshielded motor wires ............33 switch pin 01 ..............104 unstable ................66 switch pin 01 ...............
  • Page 123 VLT3000-1095- IM-REV3.12A © 1995 Danfoss Inc. Part No. 175R5162...

This manual is also suitable for:

Vlt 3502Vlt 3504Vlt 3508Vlt 3511Vlt 3516Vlt 3522 ... Show all

Table of Contents
