2 Preparation
2.1
Installation Tools
Screwdriver (Phillips head #2)
Philips screwdriver
Crimping Tool
Grounding Lug
Wire Stripping Tool
•
Desktop or laptop with terminal emulation software. Refer to section 11, for details.
•
Baud rate: 115200 bps
•
Data bits: 8
•
Parity: None
•
Stop bits: 1
•
Flow control: None
Insula on
Wire Lead
Ground Wire
(size #6 AWG)
6-AWG wire for grounding
Stripping Tool
S9705-48D Hardware Installation Guide | 2
0.5 +/- 0.02"
(12.7 +/- 0.5 mm)
