12 Installing the Transceiver
It is not recommended to use tie wraps or cable ties with optical cables. Over tightening
will damage the optic fibers
Note
Read the following guidelines before proceeding with the installation:
• Before installing a switch, take into consideration rack space requirements for cable
management and plan accordingly.
• It is recommended to use hook and loop style straps to secure and organize the cables.
• For easier management, label each fiber-optic cable and record its respective connection.
• Maintain a clear line of sight to the LEDs by routing the cables away from the LEDs.
Prior to connecting any cables, discharge the static charge on the cable. Before you
begin any installation procedures, ensure that proper grounding procedures are
followed, such as using an ESD wrist strap.
Caution
The following steps are instructions for installing a transceiver onto the switch:
1. Remove the new transceiver from its protective packaging.
2. Remove the protective plug from the transceiver port located on the transceiver.
3. Place the bail/bale handle (wire handle) into the unlocked position and align the
transceiver with the port.
4. Slide the transceiver into the port and apply gentle pressure to seat it in place. An audible
click sound should be heard when the transceiver is correctly installed into the port.
