4. To steal the loco address press
selection press

4.7 Status Edit, changing speed step settings

To Change the Speed Step Settings for a Decoder:
1. Select the loco address you want to status
edit.
2. Press once to enter loco selection
mode, the large numbers in the Loco Info
Area will begin to blink black and gray.
The soft keys will also change to give you
the options "MU", "Recall" and "MORE".
3. Press the
will bring up the additional loco selection
tasks of "Disptch" and "Stat.Edit" above
the A and B Soft Keys.
4. Press the
The Status Edit Loco# menu will appear
and display the available speed step set-
tings.
5. Press the number on the keypad to select the corresponding speed step
setting. The menu will exit and you will see the corresponding speed selec-
tion in the Additional Loco Selection Info area.
6. Once the speed step setting you want to use is in the display, press the
key to complete the selection and speed step setting change. Once this
change is made, the Digitrax command station will send DCC commands
to the edited decoder in the speed step setting you entered.

4.8 Multiple Unit [MU] or Consist operations

It is not uncommon to see two, three or even four diesel locos pulling in consist
at the front of a train. Sometimes, there is a locomotive added in the middle of
the train or at the end of the train to give "helper service" to the head end loco-
motives. This is called Multiple Unit Operation or MU operation. With DCC,
each locomotive is separately controlled. But in the case of MUing we would
like to have more than one locomotive address controlled by a single throttle to
simplify MU operation.
Your DT602 uses universal consisting to make MU operations simple and easy
to do. This is the most flexible and realistic method of MUing available. You
can add any locomotive to your MU, no matter what kind of DCC decoder
is in your loco. You can even add an analog loco to your MU.
You can add a locomotive to an MU in either orientation and in any physical
location in the train. When you send commands to the MU you use the address
of the TOP locomotive to control the entire MU and the command station
handles the rest of the commands to the other locomotives in the MU. As the
© 2020 Digitrax, Inc.
key marked "NO".
key labeled "MORE": This
key below "Stat.Edit" text.
key marked "YES", to cancel the
Status Edit Loco#:
Decoder modes
0-
1- 28: 28step
2- reserved 1
3- reserved 2
4- 128: 128step
5- 28A: 28step/CV19
6- reserved 5
7- reserved 6
8- 128A: 128step/CV19
9-
12
12
